Roland FR-1X Brochure & Specs page 4

FR-1x SPECIFICATIONS
Keyboard, Bass & Bellows
Right hand
Left hand
Treble Modes (only FR-1x button)
Bass&Chord Modes
Free Bass Modes
Bellows
Bellows curve
Sound source
Max polyphony
Tones (Accordion Set)
Reed Footages
Additional sounds
Orchestral sounds
Strings, JazzScat1, JazzDoos, Str&Choir, Twin Trump, Trombone, FrenchHorn, Brass, Flute1, Tenor Sax2, Clarinet, Oboe, Ac Piano, Ac Guitar, Mandolin, HarpsStr.
Organ sounds
Jazz Slow/Fast, Latin Slow/Fast, HousPerc Slow/Fast, Theatre Slow/Fast.
Orchestral Bass sounds
Acoustic, Fingered, Bowed, Jazz Pedal VTW, Tuba Mix, Tuba, Fretless.
Orchestral Chord sounds
Strings, JazzDoos, Jazz VTW, R&B VTW, Steel Gtr, Ac Guitar, Ac Piano.
Orchestral Free Bass sounds
Strings, JazzDoos, Jazz VTW, Clarinet, Ac Guitar, Ac Piano, Oboe.
PBM (Physical Behaviour Modelling)
Noises
Individual Reed Simulation
Switching Reed Sound Wave
Bellows opening/closing sound change
Musette Tuning
Micro-Tuning Presets
Effects
Reverb/Chorus
Rotary for Organ sound
Panel Controls
Knob controls & Registers
Other switches
Operation mode
User Programs
Orchestra/Organ Mode
Octave
Metronome
Bass&Chord with drum/percussion sounds
Audio Player
Bass to Treble mode
Other
Display
Rated Power Output
Speakers
Wave Expansion
Power supply
Onboard Connectors
Supplied Accessories
Optional Accessories
Colour variation
Size and Weight
Size
Weight
Download a QR scanner
application for your
Smartphone and scan this
image to instantly access
the relevant web page.
www.roland.com
Piano type 26 Keys velocity sensitive (starting at B key), button type 62 buttons velocity sensitive.
Piano type/button type 72 bass buttons velocity sensitive.
C Griff Europe, C Griff 2, B Griff Bajan, B Griff Fin, D Griff 1, D Griff 2.
2 Bs Rows, 3 Bs Rows A-7th, 3 Bs Rows A-5dim, 3 Bs Rows B-7th, 3 Bs Rows B-5dim, 3 Bs Rows Bx-7th , 3 Bs Rows Belgium.
Minor 3rd (37 notes Eb-Eb), Bajan (37 notes D-D), Fifth (36 notes C-C), North Europe (37 notes D-C#), Finnish (37 notes D-D).
New pressure sensor for better sensitivity and Advanced Physical Behaviour Modelling such as detection of bellows
opening/closing, Bellows Resistant Regulator wheel with fine adjustment.
Fixed Low, Fixed Med, Fixed High, X-Light, Light, Standard, Heavy, X-Heavy.
128 voices.
16 Accordion Sets (including 4 User Sets), each one including: 14 Treble Registers, 7 Bass/Chord registers,
7 Free Bass registers, 7 Orchestra Free Bass registers, 7 Orchestra Bass registers, 7 Orchestra Chord registers.
7 Treble, 5 Bass, 3 Chord, 2 Free Bass.
Uploadable from USB memory and saved on 4 User sets.
Stopping-reed growl, Closing valve noise, Left button noise.
Hysteresis threshold, Expression curve, Pressure variant filter, Pressure variant pitch deviation.
By bellows acceleration, by note repetition speed.
By bellows opening/closing detection.
16 Types: Off, Dry, Classic, F-Folk, American L/H, North Europe, German L/H, D-Folk L/H, Alpine, Italian L/H, French,
Scottish.
8 types, 8 types.
Slow/Fast.
Volume, 4x Treble/Orchestra/Organ + Set.
Drum On/Off, Orchestra On/Off, Organ On/Off, Free Bass On/Off, Orchestra Bass On/Off,
Orchestra Chord/Free Bass On/Off, User Programs On/Off, Wave/MP3 player: Reset/Stop, Play/Pause, Power.
8 memories.
Solo, Dual .
Down, 0, Up for Treble, Orchestra/Organ.
On/Off.
On/Off for Bass/Orch Bass 2 rows, Chord/Orchestra Chord 4 rows.
mp3/Wave player from USB memory.
On/Off.
7 segments, 3 characters (LED).
2x 7W RMS.
2x 9 cm.
2 internal areas (8Mb each) to load new sounds.
Supplied AC adaptor PSB-1U, Batteries (not included) AA-type rechargeable. Ni-MH x 8 Expected battery life under
continuous use (using Ni-MH 2000mAh batteries 5-hours speaker ON mode, 8-hours speaker OFF mode.
OUTPUT jacks L/Mono (Treble), R/Mono (Bass): ¼" phone type, PHONES jack: ¼" phone type, MIDI OUT connector, USB
MEMORY connector type A, USB COMPUTER connector type B, DC IN connector (use Roland PSB-1U AC adaptor only).
PSB-1U Ac Adaptor, Power cord (for connecting the AC adaptor) Owner's Manual, Reference caps for the bass buttons,
Reference caps for the treble buttons (only for FR-1xb button type), Straps, Strip for securing the adapter,
MIDI and/or audio cables.
Accordion soft bag, USB flash memory (M-UF-series), AMC-3 Audio-Midi cable, AAP-1 Music Rest and Throne,
Headphones RH-200, RH-300, AA-type rechargeable Ni-MH from third-party suppliers.
Black, Red.
Piano type: 405 (H) x 365 (W) x 195 (D) mm; 16 (H) x 14-3/8 (W) x 7-11/16 (D) inches.
Button type: 380 (H) x 365 (W) x 195 (D) mm; 15 (H) x 14-3/8 (W) x 7-11/16 (D) inches.
Piano type: 6,5 Kg, 14 lbs 6 oz without straps and without optional battery.
Button type: 6,4 Kg, 14 lbs 2 oz without straps and without optional battery.
and promotes development of environment-conscious
electronic musical instruments that incorporate such
technologies in any of the product categories.
Roland regards technologies
that make effective use of
Note: in the interest of product improvement, the specifications
limited energy resources as
and/or appearance of this unit are subject to change without
"Energy Saving Technology"
prior notice.
RAM 4750 RAMRES 816-11 605.00.0251
