Effective distance/location for remote control
(Figure 11)
Horizontal (left and right from center-point): Approximately 45
degrees
Vertical (left and right from center-point): Approximately 45
degrees
Distance from remote control to receiver: 3 meters max.
o
o
45
45
3 meters
o
45
o
45
3 meters
Figure 11. Effective distance/location of remote control
11
