RF Coaxial cable to cable connector or antenna
RF Coaxial cable to
TV signal out jack
Antenna
Adapter
Cable
Figure 3. Configuration with TV Tuner and Routed Signal
Items included in Remote Control Package
Before using the remote control, make sure the following items are
included in the remote control package (Figure 4). Be sure to have
these items at hand before proceeding with use of Media Center
Edition:
■
Remote control
■
Two size AA alkaline batteries
■
Optical remote control receiver
■
IR Blaster cable (infrared control cable for set-top box users)
To designated
USB port
Remote
Control
Set-top box
Infrared
Blaster
Remote Control
IR Receiver
3
