Controls at a Glance

Step 1
Select Temperature
In order to select the correct temperature, turn the
temperature control to one of four choices; Regular,
Medium, Low or Air Fluff.
DRYER TEMPS
Sturdy
Regular
marked "Tumble Dry."
For wrinkle free/permanent
press synthetics, lightweight
Medium
cottons labeled "Tumble Dry
Medium."
For
Low
labeled "Tumble Dry Low" or
"Tumble Dry Medium."
Items which need freshening.
Air Fluff
Load tumbles with room
temperature air.
Step 2
Select Options
Extended Wrinkle Out
Wrinkle Out is provided to minimize wrinkles in the
IntelliDry Wrinkle Free Fabrics cycle. This feature pro-
vides an extra 60 minutes of unheated tumble action at
the end of the cycle. Clothes can be removed any time
during this portion of the cycle. The additional 60 min-
utes of unheated tumbling can be cancelled by turning
the selector knob to OFF.
End of Cycle Signal
When the cycle is complete, a signal will sound several
times. The End of Cycle Signal volume is adjustable. To
adjust the volume, select any setting between Off and
Loud.
Remove load immediately to reduce wrinkling.
3
LOAD TYPE
cottons or labels
heat sensitive items
Step 3
Select Cycle
To select a cycle, rotate the control dial to the desired
setting. When using an IntelliDry cycle, the control dial
should point between "More Dry" and "Less Dry" for
most loads.
Loads of larger or bulkier size may require the "More
Dry" setting to completely dry the load. The "Less
Dry" setting is best suited for lightweight fabrics or for
leaving some moisture in the clothing at the end of the
cycle.
IntelliDry Regular Fabrics
The IntelliDry Regular Fabrics cycle is designed to dry
most cottons and linens. At the end of the cycle, the
load is cooled for approximately 10 minutes to reduce
wrinkling.
IntelliDry Wrinkle Free Fabrics
The IntelliDry Wrinkle Free Fabrics cycle is designed to
dry wrinkle free cottons, synthetic fabrics, double knits
and permanent press fabrics automatically. At the end
of the cycle, the clothes are cooled for approximately 20
