TP-Link TD-8840T Installation Manual

Installation
The product model shown in this QIG is TD-8840T, as an example.
Note
Turn off all of your network devices, including your computer(s) and the
Modem Router. If you currently use a modem, disconnect it now - the Modem
Router will replace your current modem.
Connect your computer to the Port
labeled "1~4" on the Modem
Router with an Ethernet cable.
Connect the LINE port of the
splitter to the wall jack using a
telephone line, then connect the
MODEM port of the splitter to the
LINE port of the modem with
another telephone line, also have
the PHONE port of the splitter
connected to a telephone.
If no telephone is needed,
Note
please connect the LINE port of
the Modem Router to the wall jack
using the telephone line directly.
Plug the provided Power Adapter
into the POWER jack on the back
of the Modem Router and the other
end to a standard electrical wall
socket.
1
