1 1 Description

Description

Server Board Features

Table 1. Server Board Features
Feature Description
Processors Dual processor slots supporting Intel
604 package
Chipset Intel
Supports 533 MHz Front Side Bus (FSB)
MCH memory controller (Northbridge)
ICH3 I/O controller (Southbridge)
P64H2 64-bit I/O hub
Memory Six dual inline memory module (DIMM) slots support:
• DDR 266 compliant, ECC, registered, 72-bit, 168-pin, DIMMs
• From 256 MB to 12 GB of memory
Graphics Integrated onboard ATI RAGE XL PCI SVGA controller
Video Memory 8 MB SDRAM of video memory
PCI bus Two PCI riser slots capable of supporting either of the following configurations:
• 1U configuration: one full-length, full-height 64-bit PCI riser slot and one Low Profile
• 2U configuration: three full-length, full-height 64-bit PCI riser slots and three LP 64-bit
Network Dual on-board 10/100/1000 Network Interface Controller (NIC)
System I/O One PS/2 keyboard/mouse port (6 pin DIN connectors)
One VGA video port (15 pin connector)
Two external USB ports, internal connector providing two additional USB
One external serial port (RJ-45), one internal COM 1 header
One external SCSI port (SCSI server board only), one internal
Two NIC ports (RJ-45)
Form Factor Server ATX form factor
MAXDATA PLATINUM Server Board
chipset E7501:
®
(LP) 64-bit PCI riser slot
PCI riser slots
Xeon™ processors in an INT3/FCPGA Socket
®
7
