Windster LINER WS-69TB30 User Manual
18/22" liner series
Hide thumbs
Also See for LINER WS-69TB30:
- User manual (20 pages) ,
- User manual (10 pages) ,
- User manual (20 pages)
Table of Contents
Advertisement
Quick Links
See also:
User Manual
User's Manual
WS-69TB30 (22")
WS-69TB36 (22")
WS-69TS30 (18")
WS-69TS36 (18")
NOTE: This unit was designed for
indoor residential use and
DUCTED operation only.
DO NOT USE OVER A WOOD
GRILL OR MOUNT OUTDOOR
ENVIRONMENT.
Please read this operation manual thoroughly before
using your range hood. Store it in a safe location for
when you need to reference it in the future.
www.windsterhood.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Windster LINER WS-69TB30
Summary of Contents for Windster LINER WS-69TB30
- Page 1 User’s Manual WS-69TB30 (22”) WS-69TB36 (22”) WS-69TS30 (18”) WS-69TS36 (18”) NOTE: This unit was designed for indoor residential use and DUCTED operation only. DO NOT USE OVER A WOOD GRILL OR MOUNT OUTDOOR ENVIRONMENT. Please read this operation manual thoroughly before using your range hood.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Table of Contents Safety Information .............. 2 – 3 Content Checklist ..............4 Measurements ................5 Preparation ................6 Installation ................. 7 Installation Diagram ..............8 Operation & Features ............9 – 11 Cleaning & Maintenance ............12 Troubleshooting .............. -
Page 3: Safety Information
SAFETY INFORMATION SAFETY INFORMATION TO REDUCE THE RISK OF A FIRE, ELECTRICAL SHOCK, AND/OR INJURY OBSERVE THE FOLLOWING: Unit is intended for indoor residential use only. If you should have questions, contact the manufacturer at the address or telephone number listed in the warranty. -
Page 4: Safety Information
SAFETY INFORMATION TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE: Regardless of heat level, never leave any surface materials unattended while operating an open flame. Always turn hood ON when cooking at high heat or when flambéing food (i.e. Crepes Suzette, Cherries Jubilee, Peppercorn Beef Flambé). -
Page 5: Content Checklist
CONTENT CHECKLIST CONTENT CHECKLIST CONTENTS INCLUDED (1) WS-69 series (30” or 36”) hood assembly (1) User’s manual (1) 6” to 7” conversion collar (2) Baffle filters w/ handles & (2) stainless steel filler (30” model only) (2) Baffle filters w/ handles & (2) stainless steel filler (36” model only) (1) Screw packet CONTENTS NOT INCLUDED WS-69CFMR (CFM reducer) -
Page 6: Measurements
MEASUREMENTS... -
Page 7: Preparation
PREPARATION PREPARATION BEFORE YOU START Be sure you have all the content of your purchase and required tools for this installation. Installation may take at least 1 to 2 hours from start to finish. Plan to use as few elbows or turns as possible for more efficient air flow. Collar size may need to be increased if utilizing a long duct run. -
Page 8: Installation
INSTALLATION INSTALLATION 1. DUCTED INSTALLATION Make sure all preparation steps are completed. Determine where you would like to mount the hood. Lift the unit up flush against the wall. Be sure the unit is leveled and parallel. Using the screws and washers provided, tightly secure the unit against the wall and the cabinet frame. -
Page 9: Installation Diagram
INSTALLATION DIAGRAM... -
Page 10: Operation & Features
OPERATION & FEATURES OPERATION & FEATURES EASY ACCESS KNOB CONTROL Knob 1 – Light ON / OFF Knob 2 – Speed i. 1 – Low speed ii. 2 – Medium speed iii. 3 – High speed BAFFLE FILTERS (2) 14-3/8” x 12-3/4” baffle filters and (2) fillers (30” model only) (2) 14-3/8”... - Page 11 OPERATION & FEATURES...
-
Page 12: Operation & Features
OPERATION & FEATURES... -
Page 13: Cleaning & Maintenance
CLEANING & MAINTENANCE CLEANING & MAINTENANCE WARNING!!! To prevent the possibility of a fire and explosion, do not use flammable liquids or solvents to clean the unit or any of its parts. Check to make sure all power sources are disconnected before servicing or taking unit apart for cleaning. -
Page 14: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING WARNING!!! Check to make sure all power sources are disconnected before starting any troubleshooting. Safety gloves and glasses should be worn when working on the unit. Serious injury or death may occur if safety precautions are not followed. WS-69 Series Light Issue (One light 1. -
Page 15: Parts List / Replacement
PARTS LIST / REPLACEMENT PARTS LIST / REPLACEMENT Description Description 6” round collar Control knob Hood body assembly Motor Halogen / LED lights Oil tray Light cover Baffle filters Capacitor... -
Page 16: Warranty / Contact Us
For a period of one (1) year from the date of purchase, if the product is determined to be defective, Windster will attempt to repair the product, at its option, at no charge. After the warranty period, customer must pay for all labor charges. During the "labor"... -
Page 17: Warranty / Contact Us
CONTACT US Windster Hoods, Inc. 5101 Commerce Dr. Baldwin Park, CA 91706 TEL: (626) 962 – 8600 FAX: (626) 962 – 8669 Toll Free: (877) 350 – 5215 E-mail: Support@windsterhood.com © Windster Hoods, Inc. Information subject to change without notice...
