Contents Important safety information Description of the appliance Visual signal Control panel Washing programmes When the appliance is first installed The water softener Filling with salt Filling with rinse aid Daily use Loading cutlery and dishes Use of detergent Multi tab function Select and start a washing programme Unloading the appliance Maintenance and cleaning...
If you are unsure of the meanings of paragraphs. these warnings contact the John Lewis branch from which you purchased the appliance. Child safety Installation •...
– By clients in hotels, motels and other • The water in your appliance is not for residential type environments drinking. Detergent residue may still be present in the appliance. – Bed and breakfast type environments. • Ensure that the appliance door is always •...
rinsing phases during the washing programme, depending on the degree of soil on the dishes. This helps to reduce energy and water consumption on lightly soiled loads. Environmental information The packaging materials are environmentally friendly and can be recycled. The plastic components are identified by markings (e.g.
Description of the appliance 1. Upper spray arm • When the washing programme is completed, the red visual signal goes off. 2. Lower spray arm • When a malfunction of the appliance occurs, 3. Filters the red visual signal flashes on the floor 4.
Control panel The controls are on the top on the control panel. To operate with the controls, keep the appliance door ajar. A B C D E On/off button • The countdown of the delay start. Display • The alarm codes related to a malfunction of the appliance.
Switch on the appliance. The appliance is Salt The indicator comes on when the salt not in setting mode when: has run out. • Only one programme indicator comes on. The salt indicator can remain on for a • The display shows the time of the washing few hours after that salt has been programme or of the delay start.
Page 9
To activate the acoustic signals again, do steps (1) through (6). Dishwasher user manual...
Washing programmes Programme Degree of soil and type of load Programme description Rinse hold Any soil. Rinse Partial load (to be completed later in the day). This programme does not require the use of detergent. Any soil. Prewash Automatic Crockery, cutlery, pots and pans. Wash 45 °C or 70 °C Rinses 70°...
Page 11
The consumption values are intended as a guide. They depend on the pressure and the temperature of the water, on the variations of the power supply and on the quantity of dishes. Dishwasher user manual...
When the appliance is first installed The water softener Before using the appliance for the first time The appliance is equipped with a water softener 1. Ensure that the electrical and water designed to remove minerals and salts from the connections comply with the installation water supply, which would have a detrimental instructions...
5. To change the level, go on pressing function The water softener must be set in two button (A) until the display shows the ways, manually and electronically. required level. Refer to the water hardness table. Setting manually 6. Switch off the appliance to confirm the operation.
5. Screw on the cap of the salt container by 2. Fill the rinse aid dispenser (1) with rinse aid. turning it clockwise until it stops with a click. The maximum level for filling is indicated by Make sure that there is no trace of salt on 'max'.
Daily use 1. Check if it's necessary to refill with • Soften remnants of burnt food in pans. dishwasher salt or rinse aid. • Dishes and cutlery must not impede the 2. Open the door, slide out the baskets and rotation of the spray arms.
The lower basket The lower basket is designed to take pots, pans, lids, dishes, salad bowls and cutlery. Serving dishes and large lids should be arranged around the edge of the basket, ensuring that the spray arms can turn freely. The cutlery basket Warning! Knives with long blades, stored in an upright...
Mix spoons with other cutlery to prevent them Glasses with long stems can be placed upside from sticking together. down in the cup racks. For best results we recommend you use the For taller items, the cup racks can be folded cutlery grid.
Moving back the upper basket to the lower position 1. Pull out the basket until it stops. 2. Carefully lift both sides upwards and then allow the mechanism to drop back down slowly, keeping hold of it. Caution! Never lift or lower the basket on one side only.
Fill with detergent 1. Press the release button (2) to open the lid (3) of the detergent dispenser. 2. Put the detergent in compartment (1). 3. If the washing programme has a prewash phase, put a small quantity of detergent on the inner side of the appliance door.
Multi tab function This appliance is equipped with the Multi tab 2. Adjust the water hardness to the highest function, that allows the use of combi detergent level. tablets. 3. Perform a washing programme without These products are detergents with a combined loading any dishes.
Select and start a washing programme Starting the washing programme Cancelling a delay start in progress without delay start Press and hold at the same time, function buttons (B) and (C) until all the programme 1. Switch on the appliance. Make sure that the indicators come on.
Make sure that there is detergent in the detergent dispenser before you start a new washing programme. End of the washing programme When the washing programme is completed, an intermittent acoustic signal sounds. • The display shows a zero. Switch off the appliance. If you do not switch off the appliance, after three minutes from the end of the washing programme, all the...
Unloading the appliance • Hot dishes are sensitive to knocks. The dishes • Water may appear on the sides and the door should therefore be allowed to cool down of the appliance as the stainless steel will before removing from the appliance. eventually become cooler than the dishes.
Maintenance and cleaning Cleaning the filters The filters must be checked and cleaned from time to time. Dirty filters will degrade the washing result. Warning! Before cleaning the filters ensure that the appliance is switched off. 1. Open the appliance door and remove the lower basket.
solvents, since these can damage the surfaces and plastic parts of the appliance. Internal cleaning Ensure that the seals around the door, the detergent and rinse aid dispensers are cleaned regularly with a damp cloth. We recommend every 3 months you run the washing programme for heavy soiled dishes using detergent but without dishes.
Something not working The appliance does not start or it stops during • - The appliance does not drain the water operation. • - The anti-flood device is on. Certain problems are due to the lack of simple maintenance or oversights, which can be solved Warning! Switch off the with the help of the indications described in the appliance before you carry out...
Page 27
Malfunction Possible cause Possible solution The mains plug is not connected in Connect the mains plug. the mains socket. The fuse in the fuse box is Replace the fuse. damaged. The delay start is set. • Cancel the delay start. •...
Page 28
The washing and drying results are not satisfactory The detergent can be the cause. Use a different brand of detergent. The dishes are wet. The washing programme was Set a programme with the drying without a drying phase. phase. The dishes are wet and matt. The rinse aid dispenser is empty.
Technical data Dimensions Width 446 mm Height 818 - 898 mm Depth 550 mm Water supply pressure Minimum 0.5 bar (0.05 MPa) Maximum 8 bar (0.8 MPa) Electrical connection Information on the electrical connection (voltage, overall power and fuse) is given on the rating plate on the inner edge of the appliance door. Capacity Place settings Power consumption...
Installation Warning! Caution! Carefully follow the instructions on the enclosed • It is dangerous to alter the template for building in the specifications or attempt to appliance and fitting the modify the appliance in any furniture panel. way. • This appliance is heavy. Care Insert the appliance after the adjustment of the should be taken when moving appliance level.
Water connection Water inlet connection Caution! Do not use inlet and drain hoses which have This appliance may be fed with either hot previously been used on another (maximum 60 °C) or cold water. Nevertheless appliance. we advise you use a cold water supply. A hot water supply is not always efficient with heavily Water drain connection soiled crockery as it shortens the washing...
Page 32
The sink plug must not be in place when the membrane will result in food particles building appliance is draining as this could cause the up over time eventually blocking the appliance water to syphon back into the appliance. drain hose spigot. If you use a drain hose extension, the internal diameter must be no smaller than the diameter of the hose provided.
Electrical connection • If necessary, have the domestic wiring system Warning! The manufacturer socket replaced. In case that the electrical accepts no liability for failure to cable has to be replaced, contact your local observe the following safety repair agent. precautions.
An authorised service engineer should service and information contained within this instruction this product, and only genuine spare parts manual, the next step is to contact John Lewis should be used. Under no circumstances should technical support on: you attempt to repair the appliance yourself.
Page 35
John Lewis, Stratford (Opening 2011) John Lewis, Cribbs Causeway 0117 959 1100 John Lewis at home, Swindon 01793 733180 John Lewis at home, Croydon 020 8662 4730 John Lewis, Trafford 0161 491 4040 John Lewis, Edinburgh 0131 556 9121 John Lewis at home, Turnbridge Wells...
Page 36
117933783-A-402012 (Subject to change without notice)
