Figure 3-15 Orienting A Simm - Sun Microsystems Ultra Enterprise 6000 System Manual

6. Lock the SIMM in place by pushing both ejector levers into the upright
position.
See Figure 3-16.
7. Install the CPU/Memory board and detach the wrist strap.
See Section 3.4.2, "Installing a Board."
8. As you reboot the system, watch for the system banner to verify that the
new memory is recognized by the system.
Figure 3-15 Orienting a SIMM
CPU/Memory Boards and Components
3
Notch alignment
3-23
