MultiSync 100 GPS Clock
Chapter 4: Interfaces
Front panel interface

LED Indicators

GE Clock Configuration Tool software interface

MULTISYNC 100 GPS CLOCK – INSTRUCTION MANUAL

Interfaces

This chapter explains the GE Clock Configuration Tool software interface and the front
panel interface. For additional configuration setting information, check the configuration
hints embedded in the GE Clock Configuration Tool software.
This section explains use of the front panel.
The front panel of the MultiSync 100 contains three LEDs:
Label Off
PWR Not Powered
SYN Not Powered
ALM No Alarm
The MultiSync 100 can be configured by running the GE Clock Configuration Tool software
on any PC connected to the same network as the MultiSync 100. Before starting the GE
Clock Configuration Tool software, check that you have the following:
• Administrative rights on your PC.
• UDP exceptions in your firewall for the GE Clock Configuration Tool software, and for
ports 9992 and 9999.
Flashing On
- Powered
Holdover (No Sync) Locked (Synced to GPS)
Alarm -
23
