1 INTRODUCTION ......................................................................................... 1
1.1 Minimum System Requirements............................................................ 1
1.2 Hardware Installation ............................................................................. 2
Jacks on your Creative DSL 7410 ............................................................... 2
Indicator LEDs ............................................................................................ 3
Hardware Installation ................................................................................. 4
1.3 Installation CD......................................................................................... 5
1.4 Before Installation ................................................................................... 5
2 INSTALLATION IN WINDOWS 98 .......................................................... 7
2.1 Installing the Creative DSL 7410 Device Driver .................................. 7
2.2 Uninstalling the Creative DSL 7410 .................................................... 16
3 APPENDIX .................................................................................................. 19
3.1 Appendix A - DSL Status Icon ............................................................. 19
3.2 Appendix B - Troubleshooting ............................................................. 21
4 FCC REGISTRATION INFORMATION FOR USERS......................... 23
5 CONTACT INFORMATION .................................................................... 25
6 WARRANTY INFORMATION ................................................................ 27
7 REGISTRATION CARD ........................................................................... 29
Installation Guide
Creative DSL USB 7410
RFC 2364
Advertisement
Table of Contents
Related Manuals for Creative RFC 2364
Summary of Contents for Creative RFC 2364
-
Page 1: Table Of Contents
1.3 Installation CD..................5 1.4 Before Installation ................... 5 2 INSTALLATION IN WINDOWS 98 ............7 2.1 Installing the Creative DSL 7410 Device Driver ........7 2.2 Uninstalling the Creative DSL 7410 ............ 16 3 APPENDIX ....................19 3.1 Appendix A - DSL Status Icon ............. 19 3.2 Appendix B - Troubleshooting ............. -
Page 2: Creative Dsl Usb
Creative DSL USB 7410 RFC 2364 1 INTRODUCTION Creative DSL USB 7410 is developed to bring modem users into the digital era by providing high-speed Internet connections using their current phone lines. An interface via USB connection and extremely simple hardware installation allows Creative DSL 7410 users to quickly setup and configure their DSL network. -
Page 3: Hardware Installation
Creative DSL 7410. Line jack: Using the provided phone cable, connect your telephone line to the wall jack and the line jack, located at the back of your Creative DSL 7410. USB jack: The USB connector allows you to connect your Creative DSL 7410 to a PC while the system is still on. -
Page 4: Indicator Leds
Installation Guide Creative DSL USB 7410 RFC 2364 Indicator LEDs Your Creative DSL 7410 features Indicator LEDs which provides your DSL line’s connection status. Refer to the following illustration and table for the definition of each LED. Descriptions POWER On when your Creative DSL 7410 is... -
Page 5: Hardware Installation
Installation Guide Creative DSL USB 7410 RFC 2364 Hardware Installation Simply connect your Creative DSL 7410 (to the devices shown) as follows: Your Creative DSL 7410 is required to be connected with a DSL service subscribed line. From the Phone jack to a... -
Page 6: Installation Cd
Your Creative DSL 7410 comes with an installation CD. Make sure you have this CD with you when you are ready to install the driver. The device driver for your Creative DSL 7410 can be found under the folder named Driver. - Page 7 Installation Guide Creative DSL USB 7410 RFC 2364 6 of 32...
-
Page 8: Installation In Windows 98
Uninstalling the Creative DSL 7410 2.1 Installing the Creative DSL 7410 Device Driver Connect the Creative DSL 7410 to the PC via the USB connector. The Windows 98 Plug-and-Play feature will automatically detect your Creative DSL 7410 as a new device and start an installation dialog box similar to the one shown below. - Page 9 Installation Guide Creative DSL USB 7410 RFC 2364 A dialog box similar to the one shown below appears. Select Search for the best driver for your device. (Recommended) and click on Next to continue. 8 of 32...
- Page 10 RFC 2364 A dialog box such as the one below appears. At this time, insert the provided Creative DSL USB 7410 Installation CD. Select Specify a location and type in the path for the drivers, for example E:\Driver or D:\Driver.
- Page 11 Installation Guide Creative DSL USB 7410 RFC 2364 A dialog box similar to the one shown below will appear. Click on Next. At this time, your PC may ask you to insert the Microsoft Windows 98 CD. A dialog box such as the one below will appear. Insert your Windows 98 CD into the CD-ROM drive and click OK to continue.
- Page 12 During this process, your PC will display the message The file adslusb.sys on (Unknown) cannot be found. At this time, re-insert the provided Creative DSL USB 7410 Installation CD and click OK to continue. At this time, a dialog box will appear for you to enter the specific VPI and VCI values provided by your DSL Service Provider.
- Page 13 Depending on your DSL Service Provider, your VPI/VCI settings may already by preset. In this case, the VPI/VCI window, as shown below, will not appear. Continue to the next page to complete your Creative DSL USB 7410 installation. 12 of 32...
- Page 14 RFC 2364 A dialog box similar to the one below appears confirming your successful installation of the Creative DSL USB 7410 device driver. Click Finish to complete the installation. To complete your setup, Windows 98 will now prompt you to restart the computer.
- Page 15 Installation Guide Creative DSL USB 7410 RFC 2364 10. Once your computer has restarted in Windows 98, you will notice a DSL dial-up icon on your desktop. 14 of 32...
- Page 16 12. Enter your User name and Password to log on the subscribed DSL service. To disconnect, just simply right-click the DSL dial-up icon on the bottom right-hand corner of your screen. Congratulations! You are now ready to surf the Internet with your Creative DSL USB 7410 at very high speeds! 15 of 32...
-
Page 17: Uninstalling The Creative Dsl 7410
Creative DSL USB 7410 RFC 2364 2.2 Uninstalling the Creative DSL 7410 This section provides you with instructions on how to uninstall your Creative DSL 7410. From the Windows desktop, click Start -> Programs -> Creative -> Dsl -> Remove. 16 of 32... - Page 18 Installation Guide Creative DSL USB 7410 RFC 2364 A dialog box similar to the one below will appear confirming the uninstallation of the Creative DSL 7410 driver and utilities. Click Yes to finalize the uninstallation. 17 of 32...
- Page 19 Installation Guide Creative DSL USB 7410 RFC 2364 18 of 32...
-
Page 20: Appendix
Creative DSL USB 7410 RFC 2364 3 APPENDIX Purpose of this section This section provides additional information in regards to your Creative DSL 7410. The Appendix is organized as follows: Appendix A - DSL Status Icon Appendix B - Troubleshooting 3.1 Appendix A - DSL Status Icon... - Page 21 Installation Guide Creative DSL USB 7410 RFC 2364 To confirm whether your Creative DSL 7410 is connected, right-click the DSL Status icon and click CPE Status. DSL installation is confirmed when ‘Show Time’ is observed. Due to the variation of the line’s condition from time to time, you may experience low connection rates over your DSL line.
-
Page 22: Appendix B - Troubleshooting
Your Creative DSL 7410 is not properly powered by an external power source, check both ends of your Creative DSL 7410 USB cable connection to see if the USB cable is firmly plugged into both the PC and your Creative DSL 7410. - Page 23 Creative DSL USB 7410 RFC 2364 If you continue to see the sign beside the Creative DSL USB 7410 device, contact Technical Support for further assistance. The HS Light is off or keeps blinking - When the HS light is flashing, the modem is attempting to connect to your local Central Offic (CO) to establish a DSL connection.
-
Page 24: Fcc Registration Information For Users
Installation Guide Creative DSL USB 7410 RFC 2364 4 FCC REGISTRATION INFORMATION FOR USERS This product is compliant and registered with the CFR47-Part 68 of the Federal Communications Commision (FCC). The FCC requires us to provide you with the following information: •... - Page 25 Installation Guide Creative DSL USB 7410 RFC 2364 24 of 32...
-
Page 26: Contact Information
You may also send your questions and comments to the following e-mail address: E-Mail: info@broadxent.com or phone@terril.com Reach us by Mail: Broadxent, Inc. - A Creative Company 188 Topaz Street Milpitas, CA 95035 General Line: (408) 719-5100 General Fax: (408)262-1390... - Page 27 Installation Guide Creative DSL USB 7410 RFC 2364 26 of 32...
-
Page 28: Warranty Information
Installation Guide Creative DSL USB 7410 RFC 2364 6 WARRANTY INFORMATION Broadxent, Inc. warrants that equipment furnished will be free from defects in material and workmanship for a period of three (3) years from the confirmed date of purchase of the product new from retail location. Upon... - Page 29 Installation Guide Creative DSL USB 7410 RFC 2364 28 of 32...
-
Page 30: Registration Card
Installation Guide Creative DSL USB 7410 RFC 2364 7 REGISTRATION CARD Creative DSL USB 7410 Product Registration Name: Company: Address: City/State/Zip: Phone: E-Mail: Serial Number: Purchased From: Date of Purchase: Please cut our the above Product Registration Card and send in with a self- addressed stamped enbelope to: BROADXENT, INC. - Page 31 © 2000 Broadxent, Inc. All Rights Reserved Broadxent logo is a registered trademark of Broadxent, Inc. in the United States and/or other countries. Creative logo and brand name are trademarks or registered trademarks of Creative Technology Ltd. in the United States and/or other countries. Pentium is a registered trademark of Intel Corporation.
- Page 32 Installation Guide Creative DSL USB 7410 RFC 2364 31 of 32...
- Page 33 Installation Guide Creative DSL USB 7410 RFC 2364 32 of 32...
