Black Box VSC-VGA-TV User Manual

Black Box VSC-VGA-TV User Manual

Multi-format video scan converter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Multi-Format Video Scan Converter
Converts PC and HDTV to interlaced NTSC/PAL
and Component output.
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
Customer
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax
Support
724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence,
Information
PA 15055-1018 • Web site: www.blackbox.com • E-mail: info@blackbox.com
BLACK BOX
July 2010
VSC-VGA-TV
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VSC-VGA-TV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Black Box VSC-VGA-TV

Summary of Contents for Black Box VSC-VGA-TV

  • Page 1 Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) Customer FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax Support 724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, Information PA 15055-1018 • Web site: www.blackbox.com • E-mail: info@blackbox.com...
  • Page 2 Multi-Format Video Scan Converter FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause inter ference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference...
  • Page 3 NOM Statement Normas Oficiales Mexicanas (NOM) Electrical Safety Statement INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
  • Page 4 Multi-Format Video Scan Converter 12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada. 13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.
  • Page 5 Trademarks Used in this Manual Trademarks Used in this Manual Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.

  • Page 6: Table Of Contents

    Multi-Format Video Scan Converter Table of Contents 1. Specifications ....................7 2. Overview..................... 8 Introduction ..................8 2.2 Features ..................... 8 2.3 What’s Included ................. 8 2.4 Hardware Description ................ 9 2.4.1 Front Panel ................9 2.4.2 Back Panel ................10 3.

  • Page 7: Specifications

    Chapter 1: Specifications 1. Specifications Output System: NTSC or PAL interlaced video, YCbCr Component Resolution: PC: VGA @ 60 Hz up to 140 Hz refresh rate, SVGA @ 60 Hz up to 120 Hz refresh rate, XGA @ 60 Hz up to 85 Hz refresh rate, SXGA @ 60 Hz refresh rate, UXGA @ 60 Hz refresh rate;...

  • Page 8: Overview

    Multi-Format Video Scan Converter 2. Overview 2.1 Introduction The VSC-VGA-TV is a high-performance, Multi-Format Video Scan Converter. It converts not only PC but also HDTV images to interlaced NTSC/PAL and component output. Use it for videoconferencing, home theaters, business presentations, lecturing rooms, or viewing PC/HDTV images on TV.

  • Page 9: Hardware Description

    Chapter 2: Overview • (1) 3-ft. (0.9-m) VGA cable • RS-232 Control Software • (1) IR remote control (includes batteries) • (1) power supply • This user’s manual 2.4 Hardware Description 2.4.1 Front Panel Figure 2-1 shows the front panel of the converter. Table 2-1 describes its components.

  • Page 10: Back Panel

    Multi-Format Video Scan Converter Table 2-1 (Continued). Front panel components. Number Component Description Up arrow button Push the button to adjust the picture upward under Position, Pan, or Zoom mode. Right arrow button Push the button to adjust the picture rightward under Position, Pan, or Zoom mode.
  • Page 11 Chapter 2: Overview Table 2-2 (continued). Back panel components. Number Component Description (3) RCA connectors YCbCr Component output connector 4-pin mini DIN connector S-Video output (3) RCA connectors HDTV (YPbPr) input HD15 connector PC input Slide switch Selects input source resolution type Barrel 5-VDC, 2-A power supply NOTE: You can select output video format between Composite/S-Video and...

  • Page 12: Remote Control Functions

    Multi-Format Video Scan Converter 3. Remote Control Functions Figure 3-1 shows the remote control. Table 3-1 describes its components. Figure 3-1. Remote Control. Table 3-1. Remote Control Components. Number Component Description Power Turn remote control ON/OFF Video setting adjustments Adjust picture contrast, brightness, color, and sharpness V-Reset button Press the button to reset the picture...
  • Page 13 Chapter 3: Remote Control Functions Table 3-1 (Continued). Remote Control Components. Number Component Description Color bar pattern ON/OFF Press the button to show color bar pat- tern on the screen. Press again to close the color bar. Image freeze ON/OFF Press the button to freeze an image.
  • Page 14 Multi-Format Video Scan Converter Table 3-1 (Continued). Remote Control Components. Number Component Description Size/Exp When a picture is in underscan mode, press the button to do size adjustment. When a picture is in overscan mode, press the button to do expand adjustment.

  • Page 15: Rs-232 Software Operation

    Chapter 4: RS-232 Software Operation 4. RS-232 Software Operation System requirements: PC OS: Windows 98/Me/2000/XP/7 4.1 Software Installation 1. Place the installation CD in the CD-ROM drive. 2. Run setup.exe on the installation CD. 3. OS might need to update some files. Restart the PC.
  • Page 16 1. Connection Status: Gray icon means the Multi-Format Video Scan Converter is disconnected. Colored icon means the VSC-VGA-TV unit is connected. 2. Power: Power on/off. 3. System reset: Reset VSC-VGA-TV settings to the default value. 4. Zoom: Turn zoom on. Number Component Zoom area: Zoom area selection: 1–9...
  • Page 17 Chapter 4: RS-232 Software Operation 5. Magnifier: Turn the magnifier on. Only for PC-INPUT. X1.5 X2.0 Close Small frame Refresh Big frame Figure 4-3. Magnifier screen. Page 17 724-746-5500 | blackbox.com...
  • Page 18 Multi-Format Video Scan Converter 6. Under/overscan: TV overscan adjustments are “pan” and “expand”; underscan adjustments are “position” and “size.” 7. Prompt: Operation message. 8. Option: TV system options, including panel skin, test pattern, and window on top. TV System Panel skin Test pattern Window on top Figure 4-4.
  • Page 19 Chapter 4: RS-232 Software Operation 12. About: Display the software version. Application software version Firmware version Figure 4-6. Software version: application software version; Firmware version: Multi-Format Video Scan Converter firmware version. 13 . Aspect: Select the screen aspect: Full>Pan & Scan>Letterbox. 14/15.
  • Page 20 Multi-Format Video Scan Converter 16. Output format: Select output format for C-V/S-V, or YCbCr. 17. Screen freeze: Still screen. 18. Video settings: Brightness/Contrast/Color/Sharpness adjustments. Reset Figure 4-8. Reset: Reset settings to default values. 19. RS-232 Communication Port: COM1: or COM2:. Page 20 724-746-5500 | blackbox.com...

  • Page 21: Connection And Installation

    Chapter 5: Connection and Installation 5. Connection and Installation HDTV LCD or Monitor RS-232 control DVHS, DVD NTSC or PAL TV AC Adapter Figure 5-1. Typical application. Table 5-1 shows the connection between the Multi-Format VideoScan Converter and remote controller with RS-232 modem cable. Page 21 724-746-5500 | blackbox.com...
  • Page 22 Multi-Format Video Scan Converter Table 5-1. Modem cable pin definitions. VSC-VGA-TV Remote Controller Definition Definition • RS-232 transmission format: Baud rate: 9600 bps Data bits: 8 bits Parity: None Stop bit: 1 bit • RS-232 transmission Command/Response codes: - Command/Response codes are the combination of 6 bytes.
  • Page 23 Chapter 5: Connection and Installation Table 5-2. Code descriptions. Code Ready State Comment Description PWR000 RDY005 POWER power off PWR001 power on PWR999 inquire status NPO000 N/P output NTSC output NPO001 PAL output NPO999 inquire status FRZ000 FREEZE freeze image off FRZ001 freeze image on FRZ999...
  • Page 24 Multi-Format Video Scan Converter Table 5-2 (continued). Codes descriptions. Code Ready State Comment Description SZL000 Size LEFT narrower width image button release SZL001 narrower width image button release SZR000 Size RIGHT wider width image button release SZL001 wider width image button release RST000 RDY000...
  • Page 25 NOTES Page 25 724-746-5500 | blackbox.com...
  • Page 26 NOTES Page 26 724-746-5500 | blackbox.com...
  • Page 27 NOTES Page 27 724-746-5500 | blackbox.com...
  • Page 28 724-746-5500 or blackbox.com. About Black Box Black Box Network Services is your source for more than 118,000 networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 20 seconds or less.
