Summary of Contents for Black Box VS-2001-DEC
- Page 1 USER MANUAL VS-2001-DEC HDMI OVER IP H.264 DECODER 24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM POWER STATUS...
-
Page 2: Table Of Contents
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TABLE OF CONTENTS TECHNICAL SUPPORT 1.877.877.2269 SAFETY PRECAUTIONS ..................................3 1. SPECIFICATIONS ................................... 4 2. OVERVIEW ...................................... 6 2.1 Introduction .......................................6 2.2 Features ........................................6 2.3 What’s Included ......................................7 2.4 Hardware Description ....................................7 2.4.1 Front Panel ........................................... -
Page 3: Safety Precautions
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 SAFETY PRECAUTIONS TECHNICAL SUPPORT 1.877.877.2269 To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Š Do not expose this unit to rain, moisture, dripping or splashing liquids. Do not place objects filled with liquids, such as vases, on the Š... -
Page 4: Specifications
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 1: SPECIFICATIONS TECHNICAL SUPPORT 1.877.877.2269 TABLE 1-1. SPECIFICATIONS SPECIFICATION DESCRIPTION Video Input Video Port (1) LAN (PoE), 10/100/1000BASE-T Input Video Type H.264/MPEG–4 AVC Video: Encoding: H.264/MPEG-4 AVC; Bitrate: < or = 30 Mbps Resolution: 640 x 480 , 800 x 600... - Page 5 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 1: SPECIFICATIONS TECHNICAL SUPPORT 1.877.877.2269 TABLE 1-1 (CONTINUED). SPECIFICATIONS SPECIFICATION DESCRIPTION General Operating Temperature 32 to 113° F (0 to 45° C) Storage Temperature -4 to +140° F (-20 to +70° C) Operating Humidity 10 to 90%, noncondensing Storage Humidity...
-
Page 6: Overview
2.1 INTRODUCTION VS-2001-DEC works with a live streaming media encoder (VS-2001-ENC) that interfaces with HDMI signals for delivering media over IP networks. With this decoder and matching encoder, the user can build a system to deliver an A/V signal over a LAN or WAN. -
Page 7: What's Included
TECHNICAL SUPPORT 1.877.877.2269 2.3 WHAT’S INCLUDED Your package should contain the following items. If anything is missing or damaged, contact Black Box Technical Support at 877-877-2269 or info@blackbox.com Š (1) HDMI over IP H.264 Decoder (VS-2001-DEC) Š Š (1) Power Adapter (12 VDC, 1 A) Š... -
Page 8: Top Panel
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 2.4.2 TOP PANEL Figure 2-2 shows the top panel of the decoder. Table 2-2 describes its components. POWER STATUS FIGURE 2-2. TOP PANEL TABLE 2-2. TOP-PANEL COMPONENTS NUMBER IN COMPONENT STATUS... -
Page 9: Back Panel
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 2.4.3 BACK PANEL Figure 2-3 shows the back panel of the decoder. Table 2-3 describes its components. L R G TX RX G DC 12V LAN (POE) AUDIO OUT HDMI OUT... -
Page 10: Hardware Installation
Before the installation, disconnect the power supplies from all the devices. During the installation, do not connect the VS-2001-DEC to a PoE power source equipment and its power adapter at the same time. The following illustration describes a common application, which is for your reference only. You may connect them as required. After connection is complete, use a VS-2001-ENC or third-party encoder to view the intended application. - Page 11 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 3: HARDWARE INSTALLATION TECHNICAL SUPPORT 1.877.877.2269 2. Point to multi point extension Video Source Encoder VS-2001-DEC Video Sink RS-232 The 3 System Control System FIGURE 3-3. POINT-TO-MULTIPOINT EXTENSION Video Source Switch...
-
Page 12: Operation Via Web-Based Configuration Page
SUPPORT 1.877.877.2269 The Web UI designed for the VS-2001-DEC allows basic controls and advanced settings of the device. The web UI presented in this chapter is for reference only and subject to actual software change without notice. 4.1 LOGGING IN TO THE WEB-BASED CONFIGURATION PAGE 1. -
Page 13: Device Name
Input a new device name. This name can be: • Displayed on the browser tab. Device Name field • Displayed and used after bonjour automatic discovery of VS-2001-DEC. NOTE: The name must contain 1–30 characters, numbers, hyphen (-) or underscore (_), or their combinations. Apply Saves the current settings and applies them to the VS-2001-DEC. -
Page 14: Device Info
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 4: OPERATION VIA WEB-BASED CONFIG PAGE TECHNICAL SUPPORT 1.877.877.2269 4.2.2 DEVICE INFO FIGURE 4-3. DEVICE INFO PAGE TABLE 4-2. DEVICE INFO PAGE COMPONENTS GUI ELEMENT DESCRIPTION Version Info Indicates the device version and when the device software was built. Indicates the network page where you can set the network parameters: IP mode (static or DHCP), gateway, device IP Network address, subnet mask, and gateway. -
Page 15: Update Firmware
Browse Browses for an upgrade file on your local computer. Saves the current settings and applies them to the VS-2001-DEC. Apply NOTE: The VS-2001-DEC will reboot automatically to make the settings take effect after upgrade process has completed. 1.877.877.2269 BLACKBOX.COM... -
Page 16: Utilities
GUI ELEMENT DESCRIPTION Commands Indicates the commands where you can reboot and restore the VS-2001-DEC to its factory defaults. Locates the device. Locate Device When you can’t locate the device, click the ”Locate Device” button to find which one will be shown when the Status indicator blinks for 10 seconds. -
Page 17: Video Wall
Determine and input which column the device is located within. (The number of columns ranges from 1 to 16.) Apply Saves the current settings and applies them to the VS-2001-DEC. 4.3 INTRODUCTION TO THE NETWORK PAGE The Network page includes the following three submenus: Š... -
Page 18: Ip Setup
IP Setup IP address: 192.168.10.253 Subnet mask: 255.255.0.0 Gateway: 0.0.0.0 Apply Saves the current settings and applies them to the VS-2001-DEC. NOTE: If the network parameters are changed, reboot the VS-2001-DEC decoder for the changes to take effect. 1.877.877.2269 BLACKBOX.COM... -
Page 19: Password
New Password NOTE: The password must contain 4–16 letters, numbers or their combinations. Apply Click to save the current settings and apply them to the VS-2001-DEC. 4.4 INTRODUCTION TO THE FUNCTION PAGE The Function page includes the following four submenus: Š... -
Page 20: Output
Sets HDCP in the HDMI output port to meet different applications. Output HDCP support • Enable: Output HDCP encrypted signals. • Disable: Output non-HDCP encrypted signals. Apply Saves the current settings and applies them to the VS-2001-DEC. 4.4.2 STREAM FIGURE 4-11. STREAM SCREEN 1.877.877.2269 BLACKBOX.COM... -
Page 21: Idle Image
Preferred Transport Mode The default mode is UDP. When stream media can’t be received, change to TCP. Apply Saves the current settings and applies them to VS-2001-DEC. 4.4.3 IDLE IMAGE FIGURE 4-12. IDLE IMAGE SCREEN TABLE 4-11. IDLE IMAGE SCREEN COMPONENTS... -
Page 22: Serial Over Ip
Serial over IP Indicates the Serial over IP section where you can set serial port parameters. Baudrate Set the serial port baudrate for VS-2001-DEC to 9600/57600/115200. Default setting is 115200. Data Bits Set the serial port data bit for VS-2001-DEC to 8/7/6/5. -
Page 23: Appendix A: Regulatory Information
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 APPENDIX A: REGULATORY INFORMATION TECHNICAL SUPPORT 1.877.877.2269 A.1 FCC STATEMENT Class B Digital Device. This equipment has been tested and found to comply with the limits for a Class B computing device pursuant to Part 15 of the FCC Rules. -
Page 24: Nom Statement
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 APPENDIX A: REGULATORY INFORMATION TECHNICAL SUPPORT 1.877.877.2269 A.3 NOM STATEMENT 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura. 3. -
Page 25: Appendix B: Disclaimer/Trademarks
B.1 DISCLAIMER Black Box Corporation shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or cost of cover damages, resulting from any errors in the product information or specifications set forth in this document and Black Box Corporation may revise this document at any time without notice. - Page 26 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ _________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________\ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ _________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ _______ 1.877.877.2269 BLACKBOX.COM...
- Page 27 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ _________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________\ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ _________________________________________________________________________________________________ __________________________________________________________________________________________________ __________________________________________________________________________________________________ _______ 1.877.877.2269 BLACKBOX.COM...
- Page 28 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL SUPPORT 1.877.877.2269 © COPYRIGHT 2019. BLACK BOX CORPORATION. ALL RIGHTS RESERVED. VS-2001-DEC_USER_REV1.PDF...
