Black Box VSP-HDMI1X8-4K User Manual

HDMI Splitter 4K User's Manual
output signals causing elevated noise levels. Use the proper cable
and make sure the display device can handle the resolution and
refresh rate selected. Interference from nearby electrical devices
can adversely affect signal quality.
Table 4-1. LED indicator functions.
LEDs 1–8 Status
Flashing green Power ON to Port 1, 2, 3, 4, 5, 6,
7, or 8
Steady green Port 1, 2, 3, 4, 5, 6, 7, or 8 is
outputting the video

5. Troubleshooting

Symptom: Video does not display
Possible Cause: Wrong installation process.
Solution: The video splitter requires at least one monitor
connection before powering on the source device.
Symptom: Erratic behavior
Possible Cause: Splitter may not receive enough power.
Solution: Check the power adapter attached to the splitter to
make sure it matches the system specifications, and is functioning
properly.
Symptom: Not receiving picture.
Possible Cause: The signal source may require a display device that
is HDCP compliant.
Solution: Check if the display monitor is HDCP compliant. HDCP
prevents the transfer of digital content to unauthorized HDMI
devices.
Possible Cause: The display monitor is added to the unit by
hot-plug, but the video source may not support hot-plug.
Solution: Check if the video source supports hot-plug. If it doesn't,
shut down the source device and reboot it again.
Possible Cause: The attached devices are not connected properly.
Solution: Check if you connected your components correctly.
724-746-5500 | blackbox.com
HDMI Splitter 4K User's Manual
Disclaimer:
Black Box Network Services shall not be liable for damages of any
kind, including, but not limited to, punitive, consequential or cost
of cover damages, resulting from any errors in the product
information or specifications set forth in this document and
Black Box Network Services may revise this document at any time
without notice.
© Copyright 2015. Black Box Corporation. All rights reserved.
Black Box and the Double Diamond logo are registered trademarks of
BB Technologies, Inc. Intel is a trademark of Intel Corporation in the U.S.
Any other trademarks mentioned in this manual
and/or other countries.
are acknowledged to be the property of the trademark owners.
vsp-hdmi1x8-4k_rev1
724-746-5500 | blackbox.com
Page 5
1 x 8 HDMI Splitter 4K
Distribute HDMI video out
to eight displays.

1. Specifications

Enclosure
Video
Resolution
(Maximum)
User Controls
Connectors
Indicators
Power
Dimensions
Weight
NOTE: The splitter is not 4K compatible when using
Intel HD 4400 based services.
®
724-746-5500 | blackbox.com
Page 6
VSP-HDMI1X8-4K
Metal
4K x 2K (3840x 2160);
Full HD 1080p (1920 x 1080)
(1) EDID Copy button
Input: (1) HDMI female,
Output: (8) HDMI female
(1) Power Input Status LED;
(8) Video Output LEDs
Consumption:
9–12 VDC, 130 mA
1.8"H x 8.6"W x 4.6"D
(4.5 x 22 x 11.8 cm)
1.889 lb. (0.859 kg)
