SRM350v3 & SRM450v3
The most widely used portable speakers ever; the all-new
SRM450 and SRM350 deliver the unparalleled ease-of-use,
professional sound quality and indestructible portability that
made SRM a live sound legend. Now packed with 1000W of
power, the widest selection of truly useful sound-enhancing
DSP and setup-friendly audio tools, SRM is ready for your
high-output application.
SRMs feature modern tools like application-specific
speaker modes and an automatic feedback destroyer,
each with a single-button interface that gets you optimized
performance in just seconds. And with the integrated
2-channel mixer, you can easily mix multiple sources.
Only SRMs deliver this level of power and sound quality
in such an indestructible, portable package.
Like us
Follow us
Watch our dang videos
SRM350v3
SRM450v3
FEATURES:
1000W system power paired with custom transducers
deliver gig-level volumes with room to spare
10" high-output LF driver [SRM350v3]
12" high-output LF driver [SRM450v3]
1.4" titanium dome compression driver
High-Definition Audio Processing for professional
sound with unmatched clarity
Patented acoustic correction developed with
touring geniuses at EAW
Precision 2-way crossover
Driver time alignment and phase correction
Quick one-button Speaker Mode selection
for application-specific voicing (PA, DJ, Monitor
and Soloist)
Effortlessly eliminate nasty feedback with one-button
automatic Feedback Destroyer
Integrated 2-channel mixer featuring dual Wide-Z
inputs
Handles anything from mics to guitars to mixers
with a single twist of the gain knob
Includes stereo RCA inputs for easy connection
to music source
Perfect for the singer/songwriter, plug in and leave
the mixer at home
Smart Protect
DSP kicks in to protect your
investment when things get pushed a little too hard
Monitor-specific angle and voicing mode perfect
for cutting through on stage
Flyable for permanent install
Proven highly-durable, portable design
23.0 lb / 10.4 kg [SRM350v3]
37.0 lb / 16.8 kg [SRM450v3]
1000W High-Definition
Powered Loudspeakers
®
1/9 PAGES

Advertisement

loading
Need help?

Need help?

Do you have a question about the SRM350v3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mackie SRM350v3

  • Page 1 ■ for cutting through on stage Flyable for permanent install ■ Like us Proven highly-durable, portable design ■ Follow us 23.0 lb / 10.4 kg [SRM350v3] ■ 37.0 lb / 16.8 kg [SRM450v3] ■ Watch our dang videos 1/9 PAGES...
  • Page 2 Powered Loudspeakers SRMv3 LOUDSPEAKER SPECIFICATIONS Acoustic Performance Input / Output Channel 1 Frequency Response (–3 dB) 55 Hz – 20 kHz [SRM350v3] 47 Hz – 20 kHz [SRM450v3] Mic-Line balanced Frequency Response (–10 dB) 50 Hz – 23 kHz [SRM350v3] ™...
  • Page 3 SRM450v3 Powered Loudspeakers SRMv3 LOUDSPEAKER SPECIFICATIONS CONT... Mounting Methods Options SRM350v3: Floor mount, pole mount or fly via optional bracket. SRM350v3 Loudspeaker Bag P/N 093-024-00 SRM450v3 Loudspeaker Bag P/N 0002843 SRM450v3: Floor mount, pole mount or fly via three integrated...
  • Page 4 SRM350v3 1000W High-Definition SRM450v3 Powered Loudspeakers SRM350v3 LOUDSPEAKER DIMENSIONS NOTES: 1. SYMBOL INDICATES CENTER OF BALANCE. 2. WEIGHT APPROX. 23.0 lb [10.4 kg]. 3. SHIPPING WEIGHT APPROX. 29 lb [13.2 kg]. UNLESS OTHERWISE SPECIFIED: THIRD ANGLE PROJECTION ALL DIMENSIONS ARE IN INCHES...
  • Page 5 SRM350v3 1000W High-Definition SRM450v3 Powered Loudspeakers SRM450v3 LOUDSPEAKER DIMENSIONS NOTES: 1. SYMBOL INDICATES CENTER OF BALANCE. 2. WEIGHT APPROX. 37.0 lb [16.8 kg]. 3. SHIPPING WEIGHT APPROX. 43 lb [19.5 kg]. UNLESS OTHERWISE SPECIFIED: THIRD ANGLE PROJECTION ALL DIMENSIONS ARE IN INCHES...
  • Page 6 SRM350v3 1000W High-Definition SRM450v3 Powered Loudspeakers SRMv3 LOUDSPEAKER REAR PANEL SPEAKER FEEDBACK SPEAKER FEEDBACK MAIN MAIN MODE DESTROYER MODE DESTROYER LIMIT LIMIT HOLD TO HOLD TO SOLO SOLO CLEAR CLEAR SIG/OL SIG/OL SIG/OL SIG/OL GAIN GAIN GAIN GAIN LINE LINE...
  • Page 7 SRM350v3 1000W High-Definition SRM450v3 Powered Loudspeakers SRMv3 BLOCK DIAGRAM 7/9 PAGES...
  • Page 8 SRM350v3 1000W High-Definition SRM450v3 Powered Loudspeakers SRM350v3 INSERTS SRM450v3 FLY POINTS M5 inserts for mounting optional hanging bracket MP = Mounting Point SPEAKER FEEDBACK MAIN MODE DESTROYER LIMIT HOLD TO LOGO SOLO CLEAR SIG/OL SIG/OL GAIN GAIN LINE LINE CH 1...
  • Page 9 Owner’s Manual SRMv3_OM.PDF “Mackie” and the “Running Man” figure are registered trademarks of LOUD Technologies Inc. All other brands mentioned are trademarks or registered trademarks of their respective holders, and are hereby acknowledged.
