Mackie SRM350v2 Product Overview

SRM350v2
The Mackie SRM350v2 is a full-range, portable, powered
loudspeaker system providing high-output, ultra-wide
dispersion and low-distortion performance in a compact,
lightweight design. Two Fast Recovery™ amplifiers
independently power a 10-inch lightweight woofer and a
precision titanium compression driver. Mackie's sophisticated
Active electronics provide phase correction, crossover, time
correction, equalization and protection circuitry.
A heat-treated titanium compression driver directs pristine
highs through an exponential high-frequency waveguide,
allowing for ultra-wide dispersion. This allows the SRM350v2
to deliver clear, smooth sound to audience members up to
45° off axis.
The 10-inch lightweight woofer provides a greater magnetic
field with far less material, making the woofer extremely
lightweight without sacrificing performance. The 2-inch voice
coil allows the driver to run cooler, delivering consistent
performance even after long hours of use.
Mackie-designed Active electronics provide equalization,
crossover, time alignment, and phase correction to
enhance sonic performance. Protective circuitry includes
over-excursion protection, low-line voltage shut-down,
thermal protection, dynamic low-frequency bass boost and
independent LF and HF limiters.
The SRM350v2 features a number of dedicated controls
including a mic/line switch, a single microphone and line
input level control, and a contour switch for low-level sound
reinforcement applications.
The center of gravity, handle locations, handle design,
position of fly-points and ease of use have been
ergonomically designed. There is also an integrated
pole mount cup and a weather-resistant steel grille. The
asymmetrical trapezoidal cabinet has been designed to
provide an ideal floor monitoring position.
The cabinet is constructed of high-pressure injected
polypropylene. The enclosure features reinforcement ribbing
and structural strengthening resulting in a strong, super-rigid
design providing ideal acoustical characteristics.
APPLICATIONS
Small club/band PA systems, houses of worship,
DJs, vocal/band monitor wedges, gymnasiums, banquet
halls, conference rooms and many, many more.
SRM350v2
FEATURES:
2-way bi-amplified, optimized powered
■
loudspeaker system
165W RMS Class-D, Fast Recovery
■
30W RMS HF amp
10" lightweight long-throw low-frequency transducer
■
with 2" voice coil
High-output precision titanium compression driver
■
Ultra-wide, smooth dispersion via HF waveguide
■
Mackie Active electronic time alignment, phase
■
correction and EQ for studio quality sound
Phase-accurate 24 dB/octave Linkwitz-Riley
■
electronic crossover
Mic/line input and pass-thru connector
■
Lightweight for ultimate portability (24 lb / 10.9 kg)
■
Asymmetrical trapezoidal cabinet for floor monitor
■
positioning
Stand / Pole-mountable
■
Flyable via optional hanging bracket kit
■
PRECISION ACTIVE
LOUDSPEAKER
LF amp /
™
