Page 1 OPERATOR’S MANUAL SWEEP STAR Gas and Diesel Sweep Star 60 Models 76-000-C and 77-100-C High Lift Sweep Star 48 Models 48-000-C July, 2004 SMITHCO PRODUCT SUPPORT 1-800-891-9435 Hwy SS and Poplar Avenue, Cameron WI 54822 E-mail: productsupport@smithco.com...
Page 2: Table Of Contents
CONTENTS Introduction .........1-10 Introduction ................1-9 Introduction ................1 Symbols ................2-3 Safe Practices ................4 Specifications ................ 5-6 Setup ..................7 Controls & Instruments ............8-9 Service ................. 10-12 Operation ................10-11 Battery ..................12 Other ..................13-14 Declaration of Conformity-English .......... 13 Declaration of Conformity-German .........
Page 3: Introduction
Serial Number and Model Number. Both numbers are needed when ordering parts. The serial number plate on the Sweep Star 60 is located on the left front main frame, in front of the en- gine. The serial number plate on the Sweep Star 48 is located on the right main frame, in front of the oil and gas tanks.
Page 4: Symbols
SYMBOLS Read Electrical Power No Electrical Operator’s Power Manual Engine - Stop Engine - Start Engine - Run Temperature Water Engine Oil Light Temperature Gasoline Diesel Glow Plug - On Glow Plug - Off Glow Plug Hour Meter Hour Meter Fuse Hand Throttle Choke - Closed...
Page 5 SYMBOLS Up/Down Arrow Down/Lower Up/Raise Manual No Smoking Moving Parts Operation Step Hot Surface Pinch Point Hydraulic Fluid Lift Arm Tractor Penetration Engage Disengage Ground Speed Fast Slow Forward High Warning Danger Reverse Neutral Caution...
Page 6: Safe Practices
19. Stop engine before making repairs/adjustments or checking/adding oil to the crankcase. 20. Use parts and materials supplied by SMITHCO only. Do not modify any function or part. 21. Do not remove the radiator cap when the engine is hot. When cooled, loosen cap slightly to the stop to relieve any pressure before removing the cap completely.
Page 7: Specifications
SPECIFICATIONS FOR SWEEP STAR 60 GAS & DIESEL WEIGHTS AND DIMENSIONS Length 129" (328 cm) Width 74.5" (179 cm) Height with Hopper Down 66" (168 cm) Height with Hopper Up 127" (323 cm) Wheel Base 68.5" (174 cm) Weight 2200 lb (998 kg)
Page 8: Specifications
SPECIFICATIONS FOR SWEEP STAR 48 HIGH LIFT WEIGHTS AND DIMENSIONS HIGH LIFT Length 121" (307 cm) Width 60" (153 cm) Height with Hopper Down 63" (160 cm) Height with Hopper Up 126" (320 cm) Wheel Base 70" (179 cm) Weight 1900 lb (862 kg) SOUND LEVEL At ear level...
Page 9: Setup
1. Set park brake. 2. Check the tire pressure. Sweep Star 60: The front tire and castor wheels are 20 psi (1.4 bar) and the rear tires are 18 psi (1.3 bar). Sweep Star 48: All tires and castor wheels are 20 psi (1.4 bar). All are maximum pressures.
Page 10 CONTROLS & INSTRUMENTS SWEEP STAR 60 GAS SWEEPER & 48 HIGH LIFT CONTROLS & INSTRUMENTS SWEEP STAR 60 DIESEL SWEEPER...
Page 11: Controls & Instruments
CONTROLS & INSTRUMENTS A. Circuit Breaker - The circuit breaker is a re-settleable fuse. To reset push down on it. B. Hour Meter - The hour meter indicates hours of machine operation. It operates only when the ignition switch is on. C.
Page 12: Operation
3. Tire pressure should be 20 psi (1.4 bar) on all Sweep Star 48 tires and castor wheels. Tire pressure should be 20 psi (1.4 bar) on Sweep Star 60 front tire and castor wheel, 18 psi (1.3 bar) on rear tires.
Page 13: Battery
BATTERY BATTERY Batteries normally produce explosive gases which can cause personal injury. Do not allow flames, sparks or any ignited object to come near the battery. When charging or working near battery, always shield your eyes and always provide proper ventilation.
Page 14 NOTES...
Page 15: Other
(Full address of the manufacture - authorized representative established in the Community must also give the business name and address of the manufacture) declare under our sole responsibility, that the product Gas Sweep Star 60 / 76-000-B Diesel Sweep Star 60 / 77-100-B Sweep Star 48 High Lift / 48-000-C...
Page 16 (vollständige Anschrift der Firma - bei in der Gemeinschaft niedergelassenen Bevollmächtigten ebanfalls Angabe der Firma und Anschrift des Herstellers) erklären in alleiniger Verantwortung, daß das Produkt Gas Sweep Star 60 / 76-000-C Diesel Sweep Star 60 / 77-100-C Sweep Star 48 High Lift / 48-000-C (Fabrikat, Typ) auf das sich diese Erklärung bezieht, den einschlägigen grundlegenden Sicherheits- und...
Page 17: Other
Batteries. Wheels and tires. A copy of the warranty for the above items is furnished if necessary with each SMITHCO product. Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitations of incidental or consequential damages, so the above limitations or exclusions may not apply to you.

This manual is also suitable for:

76-000-c 77-100-c Sweep star 48 48-000-c
