Parts & Service SweepStar 60 Gas and Diesel 76-000-C and 77-100-C SN: 1803 April 2005 Revised June 2006 Product Support: Hwy SS & Poplar Ave; Cameron WI 54822 1-800-891-9435 productsupport@smithco.com...
INTRODUCTION Thank you for purchasing a product. Read this manual and all other manuals pertaining to the Sweep Star 60 carefully as they have safety, operating, assembly and maintenance instructions. Failure to do so could result in personal injury or equipment damage. Keep manuals in a safe place after operator and maintenance personnel have read them.
19. Stop engine before making repairs/adjustments or checking/adding oil to the crankcase. 20. Use parts and materials supplied by SMITHCO only. Do not modify any function or part. 21. Do not remove the radiator cap when the engine is hot. When cooled, loosen cap slightly to the stop to relieve any pressure before removing the cap completely.
SPECIFICATIONS FOR SWEEP STAR 60 GAS & DIESEL WEIGHTS AND DIMENSIONS Length 129" (328 cm) Width 74.5" (179 cm) Height with Hopper Down 82" (208 cm) Height with Hopper Up 127" (323 cm) Wheel Base 68.5" (174 cm) Weight 2200 lbs (998 kg) ROLL OVER PROTECTION BAR Standard on all Machines SOUND LEVEL...
MAINTENANCE LUBRICATION Use No. 2 General Purpose Lithium Base Grease and lubricate every 100 hours. The Sweep Star 60 has ten grease fittings. One on the outside of each tower. One on the center of park brake relay on rear axle. One on hydrostatic pedal under the floorboard.
Page 7
MAINTENANCE (CONTINUED) TIRE PRESSURE Caution must be used when inflating a low tire to recommended pressure. Over inflating can cause tires to ex- plode. Front tires and castor wheel should be 20 psi (1.4 bar), rear tires should be 18 psi (1.3 bar) maximum. Improper inflation will reduce tire life considerably.
Page 8
MAINTENANCE (CONTINUED) WHEEL MOUNTING PROCEDURE REAR WHEELS 1. Set park brake. Turn machine off and remove key. 2. Block one of the other wheels. 3. Loosen nuts slightly on wheel to be removed. 4. Jack up machine being careful not to damage underside of machine. 5.
SERVICE CHART KOHLER COMMAND 25 HP Before servicing or making adjustments to the machine, stop engine, set park break, block wheels and remove key from ignition. Follow all procedures and ONLY use parts prescribed by the manufacturer. Read the engine manual before maintenance.
SERVICE CHART KUBOTA DIESEL 18.8 HP Before servicing or making adjustments to the machine, stop engine, set park break, block wheels and remove key from ignition. Follow all procedures and ONLY use parts prescribed by the manufacturer. Read the engine manual before maintenance.
ADJUSTMENTS PARK BRAKE ADJUSTMENT By turning knob on end of park brake lever you can tighten or loosen brake a small amount. To tighten turn the knob clockwise. To loosen turn counter clock- wise. If this is not enough turn clevis on brake cable to adjust length of cable. STEERING CHAIN ADJUSTMENT Steering Sprockets (A) should be level with each other.
GAS WIRING DIAGRAM Color Code Chart Blue Brown Yellow Green Orange Black Purple White...
Page 17
GAS WIRING PARTS LIST REF# PART# DESCRIPTION QUANTITY 22-003 Ammeter 76-269 Power Wire to Hour Meter 12-017 Hour Meter 76-259 Ground Wire for Hour Meter 76-260 Ground Wire for Ignition Switch 34-146 Panel Mount Circuit Breaker 34-145 Circuit Breaker Boot 13-288 Key Switch with Hardware (Kohler #25 099 04)
BODY AND FRAME DRAWING When Filtration System is to be installed, Ref. 9 Hopper Screen Cover is to be removed. When Filters are used, 76-262 Tailgate Screen is replaced by 76-249 Tailgate Filter Screen. 76-261 Hopper Screen is replaced by 76-248 Hopper Filter Screen.
Page 21
BODY AND FRAME PARTS LIST REF# PART# DESCRIPTION QUANTITY 1§ 60-130 Tire and Wheel 60-130-01 Tire 18 x 9.50 - 8 60-130-02 Wheel 8839 Windshield Washer Fluid or Equivalent 28 pints 76-264 Nose Cone 76-354 # ABC Dry Chemical Fire Extinguisher 76-372 Inclinometer 76-373...
Page 23
76-375 ROLLOVER PROTECTION PARTS LIST REF# PART# DESCRIPTION QUANTITY 76-377 Right Seat Belt Bracket HB-38-16-200 Bolt - 16 x 2 HWL-38 Lockwasher HN-38-16 - 16 HB-716-14-100 Bolt - 14 x 1 HNTL-716-14 Lock Nut - 14 76-198-03 Seat Belt 76-379 Right Support 76-381 Roll Bar...
Page 37
FUEL TANK AND OIL TANK PARTS LIST REF# PART# DESCRIPTION QUANTITY 15-491 Fuel Tank HB 14-20-075 Bolt - 20 x HWL-14 Lockwasher HW-14 Washer 15-492 Gas Cap with Gauge 77-179 Diesel Fuel Cap with Gauge 15-039 Fuel Valve 18-042 Reducer Bushing 76-221 Tank Mount 18-140...
Page 49
ELECTRIC CLUTCH DRIVEN BELT DRIVE PARTS LIST REF# PART# DESCRIPTION QUANTITY 48-038 Spring Bracket HMB-100-10 Machine Bushing 1 x 10GA 21-445 Spring 76-337 Electric Clutch 16-013 Idler Pulley 76-217 Idler Arm 76-298 Spacer HB-12-13-300 Bolt - 13 x 3 HW-12 Washer HNTL-12-13 Lock Nut...
Page 63
76-197 EATON GEAR PUMP PARTS LIST REF# PART# DESCRIPTION QUANTITY Body 76-197-01 Front Plate Washer 76-197-06 Cap Screw 76-197-07 Retaining Ring Shaft Seal 33-061-15 Washer O-Ring Backup Gasket Seal Wear Plate 76-197-04 Shaft (comes with Idler Gear) 76-197-02 Back Plate Plug 76-197-08 Seal Kit...
Page 65
76-238 REAR WHEEL MOTOR PARTS LIST (14.5 CI) REF# PART# DESCRIPTION QUANTITY Water & Dirt Seal 2† 13-615-05 Service Housing Assembly Inner Seal 4† 13-032-27 Thrust Bearing 5† 13-032-28 Inner Bearing 13-032-29 Thrust Bearing 76-238-03 Drive Link Ring Seal 13-032-31 Manifold 13-032-32 Commulator Assembly (matched...
Page 67
76-023 3 -BANK HYDRAULIC VALVE PARTS LIST REF# PART# DESCRIPTION QUANTITY 76-023-03 Mounting Bracket HN-516-18 Hex Nut - 18 HW-14 Washer 76-023-06 Tie Rod 18-188 Elbow 45° 18-168 Elbow 90° Linkage (comes with handle) 76-309 Valve Handle (sold as a set of 3) 76-125-01 Knob 1 per handle...
Technical Assistance Main Frame 25-362 Danger Fire Hopper 27-093* Hydraulic Oil Level Console Back Above Hydraulic Tank 34-147 Smithco Star Front Nose Cone 75-651 Hopper Lift Safety Hopper Lift Safety Bar 75-865 Sweep Star 60 One each Side of Hopper...
Page 73
SMITHCO purposes.) All warranty claims must be handled through a authorized dealer or by SMITHCO, Inc. All transportation charges must be paid by the purchaser. There is no further express warranty. All implied warranties, including those of merchantability and fitness for a particular purpose, are limited to one year, (60 days if product is used for rental purposes) from the date of purchase by the original user, and to the extent permitted by law any and all implied warranties are excluded and disclaimed after the expiration of such period.
