GV-FD2410
2MP H.264 3x zoom WDR Pro IR Fixed IP Dome
Active Tampering Alarm
Tampered
Introduction
The GV‐FD2410 is an indoor camera designed with 3‐axis mechanism for easy and flexible installation. The Fixed IP Dome contains an
automatic IR‐cut filter and IR LEDs for night surveillance. The camera allows the user to remotely adjust the zoom and focus through
the Web interface with its motorized varifocal lens. Equipped with WDR Pro, the camera can process scenes with contrasting
intensity of lights and produce clear image. The camera can be installed on various types of locations including wall surface, wall
corner, pole and ceiling using optional accessories.
Overview
GV-FD2410
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
* No Memory card slot & local storage function for
Argentina.
Focus Change
- 1 -
1/3.2" progressive scan CMOS
Dual streams from H.264 and MJPEG
Up to 30 fps at 1920 x 1080
3‐axis mechanism (pan / tilt / roll)
Motorized varifocal lens for remote
focus/zoom adjustment
Intelligent IR
2‐way audio
One sensor input and alarm output
TV‐out support
Built‐in Micro SD (SDHC / SDXC) card slot
for local storage
DC 12V / AC 24V / PoE
Wide Dynamic Range Pro (WDR Pro)
Defog
Motion detection
Tampering alarm
Privacy mask
Removable IR‐cut filter for Day/Night
function
IP address filtering
Supports iPhone, iPad, Android & 3GPP
31 languages on Web interface
ONVIF (Profile S) conformant
Camera Shift
August 8, 2013
Advertisement
Table of Contents
Related Manuals for GeoVision GV-FD2410
Summary of Contents for GeoVision GV-FD2410
- Page 1 GV-FD2410 2MP H.264 3x zoom WDR Pro IR Fixed IP Dome • 1/3.2" progressive scan CMOS • Dual streams from H.264 and MJPEG • Up to 30 fps at 1920 x 1080 • 3‐axis mechanism (pan / tilt / roll) • Motorized varifocal lens for remote focus/zoom adjustment • Intelligent IR • 2‐way audio • One sensor input and alarm output • TV‐out support • Built‐in Micro SD (SDHC / SDXC) card slot for local storage ...
- Page 2 Ø 14 mm Image Format 1/2.7” Focus Auto Focus Operation Zoom 3X Optical Zoom Iris DC drive Max. Torque (Focus/ Zoom Screws) 0.049 N.m IR LED Quantity 10 IR LEDs Max. IR Distance 15 m (50 ft.) Operation Video Compression H.264, MJPEG Video Streaming Dual streams from H.264 and MJPEG 30 fps at 1920 x 1080 Frame Rate * The frame rate and the performance may vary depending on the number of connections and data bitrates (different scenes). Brightness, Contrast, Sharpness, Gamma, White Balance, Flicker‐less, Image Orientation, Shutter Speed, Image Setting Backlight Compensation, D/N Sensitivity, WDR, Defog - 2 - GV-FD2410 August 8, 2013...
- Page 3 PoE Power Output Per Port 48V DC, 350mA. Max. 15.4 watts Web Interface Installation Management Web‐based configuration Maintenance Firmware upgrade through Web Browser or Utility Camera Live View, Video Recording, Change Video Quality, Bandwidth Control, Image Snapshot, Digital Access from Web Browser I/O Control, Audio, Picture in Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Text Overlay, Digital PTZ Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian /Japanese / Lithuanian / Norwegian / Persian / Polish / Portuguese / Language Romanian / Russian / Serbian / Simplified Chinese / Slovakian / Slovenian / Spanish / Swedish / Thai / Traditional Chinese / Turkish Applications Network Storage GV‐NVR, GV‐System, GV‐Backup Center, GV‐Recording Server GV‐Eye for Android smartphone, tablet, iPhone, and iPod Touch Smart Device Access GV‐Eye HD for iPad Live Viewing IE, mobile phone CMS Server support GV‐Control Center, GV‐Center V2, GV‐VSM - 3 - GV-FD2410 August 8, 2013...
- Page 4 Wall Pendant Tube (8.9’’ x 5.5’’ x 9.8”) Weight: 900 g (1.98 lb) Dimensions: 315 x 195.5 x 225 mm Wall Pendant Tube and Junction Box GV‐Mount203 (12.4’’ x 7.7’’ x 8.9”) Kit Weight: 2.95 Kg (6.5 lb) Dimensions: 238.6 x 409.5 mm GV‐Mount300 Convex Corner Adapter Kit (9.4’’ x 16.1”) Weight: 4.27 Kg (9.41 lb) Dimensions: 238.6 x 409.5 mm GV‐Mount310 Concave Corner Adapter Kit (9.4’’ x 16.1”) Weight: 4.27 Kg (9.41 lb) Bracket: 241 x 161 mm (9.5’’ x 6.3’’) Pole Mount Bracket Kit GV‐Mount400 Weight: 1.70 Kg (3.75 lb) (Ø 4" ~ 6") Steel Strap Diameter: Ø 4" ~ 6" - 4 - GV-FD2410 August 8, 2013...
- Page 5 GV‐Mount902 GV‐FD Series Dome Housing (Ø 7.3’’ x 3.8”) Weight: 600 g (1.32 lb) Dimensions: ø 103.7 x 55 mm (4.08’’ x 2.16”) 41‐81053‐HK2 Smoked Cover Weight: 30g (0.07 lb) Vandal Resistance: IK7 The GV‐PA191 is a Power over Ethernet (PoE) adapter designed to GV‐PA191 Power over Ethernet (PoE) Adapter provide power to the IP device through a single Ethernet cable. The GV‐Relay V2 is designed to expand the voltage load of GV IP devices. It provides 4 relay outputs, GV‐Relay V2 GV‐Relay V2 and each can be set as normally open (NO) or normally closed (NC) independently as per your requirement. Power Adapter Power adapters are available in 4 regions: U.S.A., Australia, U.K and Europe. - 5 - GV-FD2410 August 8, 2013...
