Quick Start Guide

GV-Fisheye IP Camera
GV-FE421 / GV-FE111
Thank you for purchasing GV-Fisheye IP Camera. This guide is designed to
assist the new user in getting immediate results from the GV-Fisheye IP
Camera. For advanced information on how to use the GV-Fisheye IP Camera,
please refer to GV-Fisheye IP Camera User's Manual on Software DVD.
© 2010 GeoVision Inc. All rights reserved.
1
Introduction
Welcome to the GV-Fisheye IP Camera Quick Start Guide. In the following
sections, you will learn the basic installations and configurations of
GV-Fisheye IP Camera. For the detailed user manual, see the GV-Fisheye
IP Camera User Manual on the GV-Fisheye IP Camera Software DVD.
Packing List
• Camera Body
• Support Bracket x 3
• Screw
(Hard Ceiling Mount) x 3
• Screw
(In-Ceiling Mount) x 3
• Security Torx
2010/12
English
FE111421-QA-A
• Camera Cover
(Hard-Ceiling Mount)
• Camera Cover
(In-Ceiling Mount)
• Plastic Screw Anchor x 3
• 3-Pin Terminal Block
• GV-Fisheye IP Camera
Software DVD
• DC 12V Power Adaptor
• Installation Sticker
• GV-NVR Software DVD
• GV-NVR Quick Start Guide
