USER'S MANUAL
Model No. WESY87100
Serial No.
(Write the serial number in the space
above for reference.)
Class H C
Fitness Product
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you have
questions, or find that there are
missing or damaged parts, we
will guarantee you complete sat-
isfaction through our Customer
Service Department.
Please CALL:
0345-089009
Or WRITE:
ICON Fitness Lifestyle Ltd.
Greenwich House
223 North Street
Sheepscar
Leeds LS7 2AA
West Yorkshire
CAUTION
Visit our website at
Read all precautions and instruc-
www.weiderfitness.com
tions in this manual before using
this equipment. Save this manual
new products, prizes,
for future reference.
fitness tips, and much more!

Advertisement

Table of Contents
loading

Summary of Contents for Weider WESY87100

  • Page 1 ® USER’S MANUAL Model No. WESY87100 Serial No. (Write the serial number in the space above for reference.) Class H C Fitness Product Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS .............3 BEFORE YOU BEGIN .
  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precautions before using the home gym system. 1. It is the responsibility of the owner to ensure 9. Always stand on a foot plate when perform- that all users of the home gym system are ing an exercise that could cause the home adequately informed of all precautions.
  • Page 4: Before You Begin

    Whether your goal is number before calling. The model number is to tone your body, build dramatic muscle size and WESY87100. The serial number can be found on a strength, or improve your cardiovascular system, the decal attached to the WEIDER 8510 (see the front ®...
  • Page 5: Assembly

    ASSEMBLY Before beginning assembly, carefully read the • As you assemble the home gym system, be sure following information and instructions: that all parts are oriented as shown in the drawings. • Place all parts of the home gym system in a cleared area and remove the packing materials;...
  • Page 6 2. Slide the Front Upright (42) onto the 5/16” x 2 1/2” Carriage Bolts (1) in the Base (4). Hand tighten a 5/16” Nylon Locknut (3) onto each Carriage Bolt. Do not tighten the Nylon Locknuts yet. Press a 1” Square Inner Cap (65) into the Front Upright (42).
  • Page 7 5. Press the Weight Tube Bumper (64) into the end of the Weight Tube (63). Insert the Holes Weight Tube into the stack of Weights (25). Be sure that the pins on the Weight Tube are resting in the pin grooves in the upper Weight.
  • Page 8 8. Press a 1 3/4” Square Inner Cap (44) into the top of a Press Arm (46). Press a 1” Round Inner Cap (49) into each end of the handle on the Press Arm. Attach the Press Arm to one side of the Press Frame (17) with two 5/16”...
  • Page 9 11. During steps 11 through 25, refer to the CABLE DIAGRAM on page 21 of this manual to verify proper cable routing. Before begin- ning this section, identify the Long Cable (23) and the Short Cable (58) by comparing the lengths and ends of the cables.
  • Page 10 15. Route the Long Cable (23) around the “V”- Pulley (6) on the Right Arm (48). Be sure that the Cable is in the groove of the “V”- Pulley and that the Long Cable Trap (50) is turned to hold the Cable in place. Tighten the 3/8”...
  • Page 11 19. Note: This assembly step shows how to complete the assembly of several pre- attached parts. The 5/8” x 9/16” Spacer (73) has been pre- attached on the outside of the 3 1/2” Low Pulley (77) for shipping purposes. Remove the 3/8”...
  • Page 12 21. If the indicated 3 1/2” Pulley (15) is pre- attached to the Front Upright (42), remove it. Route the Short Cable (58) around the Pulley. Attach the Pulley and two Pulley Covers (78) to the lower hole in the Front Upright with the 3/8”...
  • Page 13 24. Attach the end of the Short Cable (58) to the Long “U”-Bracket (57) with a 1/4” Nylon Lock- nut (2) and a 1/4” Flat Washer (10). Do not completely tighten the Nylon Locknut. It should be threaded onto the end of the Cable so only a couple of threads are showing above the nut, as shown in the inset drawing.
  • Page 14 26. Attach the Backrest (41) to the Front Upright (42) with two 1/4” x 2 1/2” Screws (43) and two 1/4” Flat Washers (10). 27. Press a 1 1/2” Square Inner Cap (32) into the Seat Frame (36). Insert the 1/4” x 2” Carriage Bolt (38) into the centre hole in the Seat Plate (37).
  • Page 15 29. Rest the Seat Frame (36) on the indicated pin in the Front Upright (42). Attach the Seat Frame to the Front Upright with a 5/16” x 2 3/4” Carriage Bolt (14) and the Seat Knob (40). 30. Press 3/4” Round Inner Caps (34) into the ends of both 12 1/2”...
  • Page 16 31. Make sure that all parts have been properly tightened. The use of the remaining parts will be explained in ADJUSTMENT, beginning on page 17 of this manual. Before using the home gym system, pull each cable a few times to be sure that the cables move smoothly over the pulleys.
  • Page 17: Adjustment

    ADJUSTMENT The instructions below describe how each part of the home gym system can be adjusted. IMPORTANT: When attaching the lat bar or nylon strap, make sure that the attachments are in the correct starting position for the exercise to be performed. If there is any slack in the cables or chain as an exercise is performed, the effectiveness of the exercise will be reduced.
  • Page 18 ATTACHING AND REMOVING THE SEAT Set the bracket on the Seat Frame (36) onto the indi- cated pins on the Front Upright (42). Attach the Seat Frame to the Front Upright with the 5/16” x 2 3/4” Carriage Bolt (14) and the Seat Knob (40). For some exercises, the Seat (13) must be removed.
  • Page 19 WEIGHT RESISTANCE CHART This chart shows the approximate weight resistance at each station. “Top” refers to the 6,5 lb. top weight. The other numbers refer to the 12,5 lb. weight plates. Weight resistance shown for the butterfly arm station is for each butterfly arm.
  • Page 20: Trouble-Shooting And Maintenance

    TROUBLE-SHOOTING AND MAINTENANCE Inspect and tighten all parts each time you use the home gym system. Replace any worn parts immediately. The home gym system can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents. TIGHTENING THE CABLES Woven cable, the type of cable used on the home gym system, can stretch slightly when it is first used.
  • Page 21: Cable Diagram

    CABLE DIAGRAM The cable diagram below shows the proper routing of the Short Cable (58) and the Long Cable (23). Use the diagram to be sure that the two cables and the cable traps have been assembled correctly. If the cables have not been correctly routed, the home gym system will not function properly and damage may occur.
  • Page 22: Part List

    PART LIST—Model No. WESY87100 R0200A Key No. Qty. Description Key No. Qty. Description 5/16” x 2 1/2” Carriage Bolt Front Upright 1/4” Nylon Locknut 1/4” x 2 1/2” Screw 5/16” Nylon Locknut 1 3/4” Square Inner Cap Base 10” Pad...
  • Page 23: Exploded Drawing

    EXPLODED DRAWING—Model No. WESY87100 R0200A...
  • Page 24: Ordering Replacement Parts

    3. The SERIAL NUMBER OF THE PRODUCT (see the front cover of this manual). 4. The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST on page 22 of this manual.) Part No. 142905 R0200A Weider is a registered trademark of ICON Health & Fitness, Inc. © 2000 Printed in Canada...
  • Page 25 2) press and butterfly arm assembly, 3) cable and pulley assembly, and 4) seat and backrest assembly. The hardware for each stage is packaged separately. Wait until you begin each assembly stage to open that parts bag. WESY87100 R0200A...
  • Page 26 1/4” Nylon Locknut (2)–3 1/4” x 2” Screw (24)–1 5/16” Nylon Locknut (3)–17 3/8" Nylon Jam Nut (81)–2 1/4” x 2 1/2” Screw (43)–2 3/8” Nylon Locknut (21)–10 5/16” x 1 3/4” Bolt (72)–1 1/4” Flat Washer (10)–6 5/16” x 2 1/2” Bolt (22)–4 5/16”...
  • Page 27 1 1/8” x 2 1/2” Plastic Bushing (74)–2 1” Retainer (69)–4 1” x 7/8” Plastic Bushing (75)–2 3/8” x 2” Bolt (12)–3 Cable Clip (53)–2 3/8” x 2 1/2” Bolt (7)–3 5/16” x 2 1/4” Bolt (33)–1 3/8” x 3 1/2” Bolt (16)–1 3/8”...
  • Page 28 3/4” Round Inner Cap (34)–4 1” Round Inner Cap (49)–6 1” Round Cover Cap (70)–2 5/8” x 9/16” Spacer (73)–1 1/2” x 3/4” Spacer (61)—2 5/16” x 2” Eyebolt (35)—1 1 3/4” Square Inner Cap (44)–6 1 1/2” Square Inner Cap (32)—2 2”...
