Dear customer, Please read these operating instructions carefully and pay particular attention to the safety notes indicated below. We recommend that you keep this instruction manual for future reference and pass it on to any future owners. This instruction manual was prepared for various models of washing machine, and they vary in function and design.
(the environment is protected too!). laundry being washed. • The machine works more economically if it is fully loaded. Technical specifications 45 S 508 D 45 S 551 D 45 S 651 D DIMENSIONS Height 85 cm...
Installation Unpacking 5. Set the machine upright and remove the remaining rear screw. Slide out the relevant pin. 6. Plug all the holes with the plugs which you will All transit bolts and packing must be removed find in the envelope containing the instruction before using the appliance.
The inlet hoses must not be lengthened. If they are The drain hose must not be kinked. Run it along the too short and you do not wish to move the taps, you floor; only the part near the drainage point must be will have to purchase new, longer hoses specially raised.
• The special wool programme with its new delicate wash system treats your woollens with extreme care. • The balance control device ensures the machine is stable during the spin. Detergent dispenser drawer 45 S 508 D 45 S 551 D - 45 S 651 D The detergent dispenser is divided into three compartments (fig.).
Control panel Model 45 S 508 D Cotton/Whites ° - 90° Cotton/Whites + Pre Wash 60° - 90° TEMPERATURE PROGRAMS Cotton/Colours ° - 60° Cotton/Colours + Pre Wash 40° - 60° Cotton-Colours Rinses + Spin ° - 40° Long Spin...
Page 9
Control panel Model 45 S 551 D Cotton/Whites ° - 90° Cotton/Whites + Pre Wash 60° - 90° TEMPERATURE PROGRAMS Cotton/Colours ° - 60° Cotton/Colours + Pre Wash 40° - 60° Cotton-Colours ° - 40° Rinses + Spin Long Spin Synthetic 40°...
Page 10
Control panel Model 45 S 651 D Cotton/Whites Cotton/Whites + Pre Wash 60° - 90° ° - 90° TEMPERATURE PROGRAMS Cotton/Colours ° - 60° Cotton/Colours + Pre Wash 40° - 60° Cotton-Colours ° - 40° Rinses + Spin Long Spin FAST Synthetic Synthetic + Pre Wash...
Maximum loads Washing hints Recommended loads are indicated in the programme charts. Sorting the laundry General rules: Follow the wash code symbols on each garment Cotton, linen: drum full but not too tightly packed; label and the manufacturer’s washing instructions. Synthetics: drum no more than half full;...
Rust: oxalic acid dissolved in hot water or a rust The washing machine incorporates a recirculation removing product used cold. Be careful with rust system which allows an optimal use of the stains which are not recent since the cellulose concentrate detergent.
, without exceeding the «MAX» mark. Before washing your first load of laundry, we 45 S 508 D 45 S 551 D - 45 S 651 D recommend that you run a cotton cycle at 60°C, with the machine empty, in order to remove any manufacturing residue from the drum and tub.
Page 14
7. At the end of the programme machine The machine stops automatically. 45 S 508 D - 45 S 551 D Turn the programme selector dial clockwise to the required programme and press the ON/OFF button If you have selected a programme which ends with...
International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature temperature temperature temperature 95°C 60°C 40°C 30°C Hand wash Do not...
5.5 kg (45 S 551 D) 6.5 kg (45 S 651 D) Options Dispenser- Programme Temp. Type of fabrics washing agents 45 S 508 D 45 S 551 D 45 S 651 D FAST FAST FAST WHITES + PREWASH, for example 60°-90° WASH WASH WASH...
Page 17
• On models 45 S 508 D and 45 S 551 D the water of the last rinse of these programmes remains in tub to prevent fabrics from creasing. To drain water, select programme J or N.
To remove the drawer from the machine, press the Before any maintenance or cleaning is carried button in the rear left-hand corner. out you must DISCONNECT the appliance 45 S 508 D 45 S 551 D - 45 S 651 D from the electricity supply. After each wash Leave the door open for a while.
Drain filter Emergency emptying out The drain filter collects threads and small objects If the water is not discharged (drain pump is blocked, inadvertently left in the laundry. Check regularly that filter or drain hose are clogged), proceed as follows the filter is clean.
• The drain hose is squashed or kinked. • A programme which ends with water in the drum does not spin: has been selected (45 S 508 D - 45 S 551 D). • Option has been selected (45 S 651 D).
Page 21
Problem Possible cause • Spinning starts late or the laundry is • The electronic unbalance detection device has cut in because the laundry is not evenly distributed in not spun enough: the drum. The laundry is redistributed by reverse rotation of the drum. This may happen several times before the unbalance disappears and normal spinning can resume.
Commonwealth or State legislation. Such rights cannot be changed by the conditions in this warranty. Subject to the conditions below, this Simpson appliance is warranted by the Electrolux Home Products Pty. Ltd. A.B.N. 51 004 762 341, (the “Company”), to be free from defects in materials and workmanship for a period of 24 months following the date of purchase (the “Warranty Period”).
APPLIANCE WARRANTY – NEW ZEALAND This appliance is warranted by Electrolux Home Products (NZ) Ltd (“the Company”) from the date of purchase. The following terms and conditions apply: The Company or its Authorised Service Centre will pay the cost of repairing or replacing all parts of the appliance which the Company or its Authorised Service Centre find defective for a period of 24 months following the date of purchase (the “Warranty Period”).
