OWNER'S AND
OPERATOR'S MANUAL
Sound Proof
Diesel Engine Generator
DG150MI
DG250MI
CAUTION : Do not operate the Generator, or any other appliance,
before you have read and understood the instructions for use.
Table of Contents
1
2
3
4
5
6
7
8
9
- 1 -
and water leakage
Page
2
5
5
6
6
6
6
7
8
8
11
14
15
15
16
17
17
18
21
23
23
24
26
27
28
28
29
29
30
31
31
32
33
38
39
41
45
71000-94011
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Shindaiwa DG150MI
Summary of Contents for Shindaiwa DG150MI
-
Page 1: Table Of Contents
2.1 Specification Matrix 2.2 Ambient Condition Sound Proof Parts 4.1 External View Diesel Engine Generator 4.2 Control Panel Equipment 5.1 Monitor Display DG150MI 5.2 Gauges 5.3 Fuel Line Changeover Valve Transportation and installation 6.1 Transportation DG250MI 6.2 Installation Connection 7.1 Selecting Cable 7.2 Connecting Cable... - Page 2 Introduction Thank you for purchasing Shindaiwa Sound Proof Diesel Engine Generator. This user manual was created to ensure the safe operation of this equipment. Therefore, the manufacturer of this equipment strongly recommends that the user follow the instructions herein, to avoid unnecessary accidents and repairs.
-
Page 3: Safety Guidelines
1 Safety Guidelines Danger :Suffocation from exhaust fume Exhaust fume from the engine contains many elements harmful to human. Do not operate this equipment in poorly ventilated area, such as inside a room or in a tunnel Danger :Electrical Shock Do not touch the output terminals during operation. - Page 4 Caution :Injuries to eyes and skin Battery fluid contains diluted sulfuric acid. Avoid contact with eyes, skin or on clothing. If the acid comes in contact, especially with eyes, flush with a lot of water, and contact your physician immediately. Caution :Fire This equipment uses Diesel Oil as a fuel.
- Page 5 Location of Warning labels When the warning labels become unreadable or damaged, place new labels on the appropriate location, as specified in the following figure. When ordering the label, use following part numbers. Safety guidelines Part Number 19402-00188 Suffocation from exhaust fume Part Number 19402-00161 Electrical Shock Part Number 19402-00163...
-
Page 6: Specifications
2 Specifications 2.1 Specification Matrix Name of Generator DG150MI DG250MI Blushless, Rotating Field, 3-Phase, 4-Pole, Type Unit Synchronous AC Generator 12.5 Rated Output Rated Voltage (or the below) Rated Current (or the below) 36.1 39.4 57.7 65.6 Rated Voltage Rated Current 19.7... -
Page 7: Ambient Condition
Ambient Condition Use the equipment under the following ambient condition. The other condition may cause trouble, insufficient output power or deterioration of durability. ■ Ambient Temperature: -15ºC ～ 4 0ºC ■ Humidity : less than 80% ■ Altitude : less than 300m 3 Use Power source for construction –use equipment, such as submersible pump Power source for lighting... -
Page 8: Control Panel
4.2 Control panel [DG150MI] [DG250MI] Name Name 3-Phase Circuit Breaker Monitor Indication Lamp Pilot Lamp Water Temperature Gauge Tachometer Single-Phase Circuit Breaker (Hour Meter incorporated) Earth Leakage Relay Oil Pressure Gauge Voltage Meter Preheat Lamp Amp. Meter Emergency Stop Button... -
Page 9: Equipment
FUEL LEVEL DG250MI is equipped with monitoring function for water/coolant temperature, oil pressure, battery charge, air filter flow, battery fluid level, and fuel level. DG150MI is equipped with monitoring function for water/coolant temperature, oil pressure and battery charge. When the equipment is started under normal condition, Oil Pressure and Battery Charge lamps will flash when the Starter Switch is turned from STOP to OPERATING, and all lamps will go off, immediately after the engine is started. - Page 10 When the water temperature reaches 110 degrees Celsius during operation, the water temperature-monitoring lamp will flash, and the automatic shutoff will be engaged. When this occurs, check the Coolant reservoir tank, and replenish if needed (refer to 8-2 Checking coolant / water level). If the water level is normal, check for loose fan belt or possible water leak in the cooling system, after the engine is cooled down.
- Page 11 5.1.3 Battery Charge Monitoring Lamp (charge lamp) When the battery is unable to be charged during operation, the battery charge-monitoring lamp will flash. Check the belt for damages or cut, and replace if needed. <Caution> For changing the belt, refer to the User Manual for Engine. Battery Charge Monitor cannot detect the degradation of battery life nor the battery fluid level (refer to 8-6 Checking Battery) 5.1.4 Air Filter Monitoring Lamp (clogged filter element) [DG250MI only]...
-
Page 12: Gauges
When the battery fluid level is low, Battery Fluid Monitoring Lamp will flash. If the lamp is flashing, quickly add some distilled water. (refer to 8.6 Checking Battery) 5.1.6 Fluid Level Monitoring Lamp [DG250MI only] Caution : Fire This equipment uses Diesel fuel as a fuel. When refueling, always stop the engine, and keep away from fire. - Page 13 5.2.3 Water Temperature Gauge [DG250MI only] Water Temperature Gauge displays the temperature of engine coolant. Normal temperature may vary depending on the environment, but it should be between 75 to 90 degree Celsius. <Caution> If the temperature exceeds normal value, disconnect the load, idle the engine at 1000min , and wait until the reading falls to the normal temperature range.
- Page 14 2.2.6.2 Pilot Lamp [DG250MI only] Pilot Lamp indicates whether or not the generator is generating electricity, when the engine is driving. 5.2.7 Switch 5.2.7.1 Starter Switch S TOP ① ① ① ① When the switch is set to this position, all power will be off. The switch must be set to this position to remove the key.
-
Page 15: Fuel Line Changeover Valve
5.2.8 Voltage Regulator and Throttle Handle 5.2.8.1 Voltage Regulator The dial adjusts output voltage. By turning the dial clockwise, an operator can increase voltage. By turning the dial counter-clockwise, an operator can decrease voltage. 5.2.8.2 Throttle Handle This handle controls the engine revolution. By turning the throttle clockwise, engine speed slows down;... -
Page 16: Transportation And Installation
5.3.1 Using fuel from built-in fuel tank The lever for 3-way valve is set to A when the equipment is shipped. In addition, both the external fuel intake and the external fuel return are safeguarded with PT-3/8 plugs. Do not remove the plugs, when using the built-in fuel tank. -
Page 17: Installation
6.1.2 Transportation When transporting this equipment, make sure that the equipment is secured properly with ropes tied to the Side Rope Through. <Caution> Always use extreme care when loading, unloading, and transporting the equipment. Failure to do so may result in damages and malfunction of the equipment. 6.2 Installation Danger :Suffocation from exhaust fume... -
Page 18: Connection
Do not block the airflow from radiator vent or muffler exhaust. It may result in reduced engine performance, overheating, or damage to the electrical parts. Operating in dusty area or salty air (by the ocean), or any other particulate environment may result in clogged radiator, which may cause overheating, other malfunctions and insulation deterioration. -
Page 19: Connecting Cable
■ S election of cable Example) 220V and Voltage Drop 11V 3-Phase 3-Wire Cap Tire Cable, Single Core (Unit: mm Length 50m or 100m 125m 150m 200m below Current (Example) 100V and Voltage Drop 5V 1-Phase 2-Wire Cap Tire Cable, Single Core (Unit: mm Length 50m or... - Page 20 7.2.1 Load Connection Terminal Plate (3-Phase / 1-phase) ■ For 3-Phase Load Terminal Voltage ： 200V / 220V (or 400V / 440V) at 50Hz / 60Hz Ｒ Ｓ Ｔ Ｏ ◯ ◯ ◯ ◯ Load ■ For 1-Phase Load (1) Terminal Voltage ：...
- Page 21 7.2.2.1 200 / 220V The terminal Voltage: 100V/110V at 50Hz/60Hz only In the case of no use of 3-Phase output power, refer to the following drawings and charts. [DG150MI] (Max 3kVA) [DG250MI] (Max 6kVA) ○ ○ ○ ○ less than...
-
Page 22: Earth Leakage Relay And Grounding
7.3 Earth Leakage Relay and Grounding Danger :Electrical Shock Ground the every earth grounding terminal to the earth as set out in the manual. If even one no of all is unconnected by mistake or accident, it will be much more dangerous for human body than the –relay case, because leaking current inevitably goes through the body. - Page 23 7.3.2 Operation Check Danger : Electrical Shock Before turning the 3-Phase circuit breaker to ON Position, ensure that the breaker or the switch of loads are positioned to OFF. Operate the 3-Phase circuit breaker, well-communicating with The electrician by the load side.
-
Page 24: Initialization And Pre-Check
① Push the reset button or stop the engine. ② Restore (Push-down) the 3-Phase circuit breaker (lever) and the 1-Phase circuit breaker (lever) to OFF position. By the above procedure, you can reset the breakers to ON positions. 8 Initialization and pre-check Danger :Electrical Shock Injuries... -
Page 25: Checking Coolant/Water
2 0W - 40 ・ ・ ・ ・ 8.1.3 Engine Oil Capacity (Unit : L) Lubrication Oil (including the oil in filter) DG150MI 7.4 (0.4) ＊ V alue in ( ) shows the oil in filter DG250MI 8.5 (0.4) 8.2 Checking Coolant / Water Also refer to the User’s Manual for Engine... - Page 26 Install the cap back and tighten ③ <Caution> With respect to DG150MI, check and add water, after unscrewing the bolt holding the radiator cap. 8.2.2 Checking Coolant reservoir tank / Adding coolant Check to see if the coolant level is between MIN and MAX line ①...
-
Page 27: Checking Fan Belt
8.2.3 Coolant Capacity (Unit : L) Total Coolant Volume (including reservoir tank) DG150MI 7.4 (0.4) DG250MI 8.5 (0.4) ＊ V alue in ( ) shows the reservoir tank’s volume 8.3 Checking Fan Belt Also refer to the user’s manual for Engine separately ✳... -
Page 28: Checking Fuel
8.4 Checking Fuel Caution :Fire Always wipe any drip of Diesel fuel or oil. Do not use this equipment when a leak is found. Repair the equipment before use. Check for the fuel level in the tank. Add if necessary. <Caution>... -
Page 29: Checking Fuel, Engine Oil
8.5 Checking Fuel, Engine Oil, and Water leakage Caution :Fire Do not use this equipment when a leak is found. Repair the equipment before use. Be sure to check for any fuel leak at the hose connection, and oil and coolant leak by opening side doors. 8.6 Checking Battery Caution :Injuries to eyes and skin... -
Page 30: Operation
9 Operation 9.1 Initializing / preparation Danger :Suffocation from exhaust fume Exhaust fume from the engine contains many elements harmful to human. Do not operate this equipment in poorly ventilated area, such as inside a room or in a tunnel . Caution :Suffocation from exhaust fume Do not point the exhaust fume toward pedestrians or building. -
Page 31: During Operation
And then adjust the speed by speed control knob and adjust to the No-load revolution. No-load revolution 50 Hz Operation 1575 min (52.5 Hz) 60 Hz Operation 1890 min (63.0 Hz) <Caution> By adjusting the speed to the above revolutions, the frequency will be 50Hz or 60Hz. Lock the Speed Control handle with locknut ⑧... -
Page 32: Stopping Generator
9.2.2 Adjustment During operation Make minor adjustment to voltage and speed using the Speed Control Knob and Voltage Regulator, by monitoring Tachometer, frequency meter, and voltage meter Vacuuming the air out of the fuelling system in event of no fuel ■... -
Page 33: Connecting To External Fuel Tank
Protection Feature List Action Circuit Automatic Alarm Lamp Symptoms Cause Breaker Engine Flash Shutoff Engine coolant High Coolant temperature is too ○ ○ ○ ○ ○ ○ ○ ○ temperature high (default at 110 degrees Celsius) Engine oil pressure Oil pressure dropped (default at ○... -
Page 34: Maintenance
Turn the lever for 3-way valve to B position. ③ Vacuum out the air from connected hoses. This will allow the use of the fuel from an external ④ fuel tank <Caution> To vacuum out the air from the fuel line, refer to <9.2 During Operation>... - Page 35 <Caution> The authorized technicians should perform all maintenance work, except for the pre-startup checks. Request for the maintenance items with ● mark to the authorized dealer or our engineering section. This chart only covers the simple checks and maintenance for the engine. For more detailed guide, please refer to the User’s Manual for the engine.
-
Page 36: Oil Change
Add oil and install filler cap ⑤ <Caution> If an oil filter wrench is not available, contact our authorized distributor or our engineering section.. Oil filter: Model ISUZU Part No. DG150MI 8944567412 DG250MI 8944567411 - 36 -... - Page 37 ① Clean or replace the filter element, and reinstall it in ② reverse order ※ W ith respect to DG150MI, unfasten clip in cleaner cap and remove before unscrewing the wingnut. <Caution> Clean more frequently, if used in dusty environment...
- Page 38 Reassemble it back ④ The fuel strainer in DG150MI has the water separating feature as well. ※ When the float (red) in the strainer comes up by 20mm from the bottom, drain the water <Caution> Be sure to check for any contaminants on the O-ring,...
-
Page 39: Long-Term Storage
Install the reservoir tank back, and fill the coolant/water to the MAX level. ⑤ Fill the radiator with coolant/water to the top ⑥ Reinstall the radiator cap ⑦ <Caution> For the types of engine oil to use, refer to <8-2 Checking Coolant/Water> Long-term Storage Danger :Electrical Shock ●... -
Page 40: Troubleshooting
11.2 Stacking Danger : Injuries If you have to stack two generators in warehouse, always proceed with the following steps. Ensure that there is no dent on bonnet, loosing bolt or no bolt in the generators. Always place the generators on a flat and stable surface, to keep the equipment from sliding, And to be endurable for the total weight. - Page 41 Caution :Injuries When performing equipment check and maintenance, always stop the engine. Caution :Fire ● Burns Battery may emit some combustible gas, so keep it away from fire and sparks. Temperature around muffler and exhaust can get extremely high. Keep any inflammable items (such as fuel, gas, paint, etc.) away from the equipment.
-
Page 42: Generator Wiring Diagram
13 Generator Wiring Diagram - 42 -... - Page 43 - 43 -...
