Page 1: Table Of Contents
5-1. Eco Welding 5-2. Display DIESEL ENGINE 5-3. Monitor Lamp 5-4. Remote Control GENERATOR/WELDER 5-5. Earth Leakage Relay Grounding DGW300MS/UK 5-6. Auto Idle Feature 5-7. Emergency Stop Switch 6.Initialization and Pre- operation check 6-1.Checking Engine Oil Water-Cooled 6-2.Checking Coolant/Water 4-Cycle Diesel Engine 6-3.Checking Fuel...
Page 3 Introduction Thank you for purchasing Shindaiwa Sound Proof Diesel Engine Welder/Generator. This operation manual has been created to ensure the safe operation of this equipment. Therefore, the manufacturer of this equipment strongly recommends that the user follow the instructions herein, to avoid unnecessary accidents and repairs.
Page 4: Safety Guidelines
1. Safety Guidelines Danger: Suffocation from exhaust fumes Exhaust fumes from the engine contain many elements harmful to human. Do not operate this equipment in poorly ventilated area, such as inside a room or in a tunnel. Danger: Electric Shock Close and lock all equipment doors during operation.
Page 5 Caution: Explosion Do not use the equipment or charge the battery, if the battery fluid level is below the LOWER level. Battery may emit combustible gas, so keep it away from fire and sparks. Caution: Fire The equipment uses Diesel as a fuel. When inspecting the equipment or refueling, always stop the engine and keep away from fire, always wait until the engine cools down before refueling.
Page 6 Location of Warning labels When the warning labels become unreadable or damaged, place new labels on the appropriate locations, as specified in the following figure. When ordering labels, use the following part numbers. ① Suffocation from exhaust fumes (No. X505-006400) ②...
Page 7: Specifications
2. Specifications Model DGW300MS/UK Generating Method Rotating Field Rated Current (A) Duty Cycle Current Adj. Range (A) 30 – 200 Welding Rod (mm) 2.0 – 4.0 Current Adj. Range (A) 40 – 300 AUTO / HIGH Welding Rod (mm) 2.0 – 6.0...
Page 8: Parts
4. Parts CURRENT ADJUSTMENT MONITOR LAMP FUEL METER DIAL DISPLAY 1-PHASE ELCB DISPLAY CHANGE SWITCH REMOTE CONTROL 3-PHASE ELCB RECEPTACLE (BREAKER) STARTER SWITCH EMERGENCY IDLE CONTROL SWITCH STOP SWITCH WELDING OUTPUT 1-PHASE BREAKER TERMINAL FUSE (10A 5 0A) ， BATTERY UNDER PLATE SIDE DOOR 1-PHASE...
Page 9 FIXED SIDE PANEL REMOVED OIL FILTER MOUNTING FUEL INLET LIFTING EYE EXHAUST POSITIONING POSITIONING HANDLE TOP PLATE HANDLE (NOT TO BE USED (NOT TO BE USED FOR LIFTING) FOR LIFTING) - 7 -...
Page 10: Equipment
5. Equipment 5-1. Eco Welding The equipment is incorporates an Eco welding feature that provides lower noise levels, lower fuel consumption and lower gas emissions than conventional welder-generators. When you turn the idle control switch to Eco, you will be able to weld at Max. with a 4.0mm welding rod at the low speed.
Page 11 Caution: Burns Do not touch the engine or exhaust during operation or immediately after stopping the equipment, as the temperature will be extremely high. When the water temperature rises abnormally, the coolant/water temperature monitor lamp will flash, and the automatic engine shut-off will be engaged. When this symptom occurs, check the coolant sub tank, and replenish if needed.
Page 12: Remote Control
5-4. Remote Control The equipment incorporates a Remote Control receptacle. Remote control box is an optional part. Remote Control operation is available by connecting the compatible Remote Controller to the receptacle. REMOTE CONTROL RECEPTACLE REMOTE CONTROL BOX 5-5. Earth Leakage Relay and Grounding Danger: Electric Shock Ground the grounding terminal to the earth as set out in the manual.
Page 13: Auto Idle Feature
(2) Operation Check Before operating the equipment, always check if the safety shut-down device works as shown in the following procedure. 3-PHASE ELCB TEST BUTTON 1-PHASE ELCB LEAKAGE INDICATION WHITE LEVER BUTTON BLACK LEVER TEST BUTTON ① Ensure that the circuit breakers and load switches are positioned to [OFF].
Page 14: Emergency Stop Switch
<Caution> When the load of less than 0.5A is connected, the Auto Idle feature may not function. In this case, turn the switch to [HIGH]. When welding operation or electric supply performs alternately or intermittently, turn the switch to [HIGH]. 5-7.
Page 15: 6-3.Checking Fuel
Danger: Injuries Do not open the radiator cap while operating this equipment or immediately after stopping the equipment, to prevent burns from hot steam or water. Caution: Burns Do not touch the engine and muffler during operation and immediately after stopping the equipment, for the temperature could reach extremely high temperature.
Page 16: 6-5.Checking Battery
<Caution> Use Diesel fuel, ASTM D975 No.2-D in the event ambient temperature reaches down to -5 ℃ . The engine is designed to use either No.1-D or No.2-D Diesel fuel. However, for better economy, use No. 2-D Diesel Fuel whenever possible. At temperatures less than -7 ℃...
Page 17: Operation
① Check the fluid level. If the level is near or lower than LOWER level, add distilled water until the fluid level reaches UPPER level. ② Make sure that the battery cables are firmly secured to the posts. Tighten the clamps if necessary. <Caution>...
Page 18: Starting
7-1. Starting ① Turn the breakers (1-P, 3-P) to [OFF] ② Turn the Fuel lever to [OPEN]. ③ Turn the Idle Control Switch to [ECO] or [AUTO]. ④ Ensure the Emergency Stop Switch is in released position. ⑤ When the temperature is below -5 ℃ , t urn and keep the Starter switch to PREHEAT until the preheat lamp turns off (about 5 seconds).
Page 19: 7-3.Emergency Stop
<Caution> Do not attempt to turn to [STOP] position while actual welding or utilizing AC power source, it may cause the serious damage on the unit. 7-3. Emergency Stop An Emergency Stop feature is incorporated in the equipment. Push the Emergency Stop Switch in case of an emergency or if an equipment fault develops during operation.
Page 20: 8-3.Connection-Welding Cable
8-2. Polarity There are two welding output terminals, 『＋＋＋＋』 a nd 『－－－－』 . Select the polarity according to the operation, referring to the table below. <Caution> Follow the instruction of the welding rods, the polarity of which is specified. Application Connection Generals Welding, such as...
Page 21 8-5. Welding Caution: Suffocation from welding fumes Be sure to wear a fume proof mask during operation, because welding fumes contains poisonous gas and dust. Pay attention to the airflow direction and sufficient ventilation also in order to prevent from inhaling the fume. Caution: Injuries to eyes and skin Be sure to wear spark protection glasses (Refer to the table below), long-sleeve shirts, gloves, etc.
Page 22: Generator Operation
9. Generator Operation 9-1. Output Range (1) 3-Phase 415V Output Receptacle Maximum output from the 3-Phase receptacle is 7KVA. (2) 1-Phase110V Output Receptacles 1-Phase 110V CTE Output is available through 2 receptacles. Maximum 3.3kVA is available 1-PHASE RECEPTACLE through 1-Phase receptacle of SIDE A side A.
Page 23: Operation
9-3. Operation Danger: Electric Shock Do not operate the equipment, if the equipment or you are wet. Before connecting or disconnecting a load cable from the receptacles, always turn the circuit breakers (1-P, 3-P) to [OFF] position. Always stop engine, and remove the engine key. The person performing the maintenance must always keep the key.
Page 24 <Caution> The AC Volt meter reads 3-P output voltage, apart from the circuit breakers (1-P, 3-P) positions to [ON] or [OFF], when the engine is driving. After the engine starts (Refer to 『 7 -1. Starting 』 ) , operate the equipment as per the following procedures.
Page 25: Simultaneous Use Of Welding And
10. Simultaneous Use of Welding and Generating The circuit breakers (1-P, 3-P) react on the AC power supply circuit only. In the simultaneous use of welding and generating, overload to the engine may occur. Refer to the following table and limit the AC power use. Limitation of AC Power Supply in the simultaneous use of welding and generating Welding AC Power Output...
Page 26 To optimize the use of this welder-generator, we recommend periodical equipment checks and maintenance based on the following matrix. Use the hour meter as a guide for the operating time. Checking Time Pre- Every Every Every Every Every Checking Items Startup 1000 2000...
Page 27 Checking Time Startup Every Every Every Every Every Checking Items Check 1000 2000 50hrs after 13 Adjust V-Belt Tension ● ● ● or 14 Change V-Belt years 15 Clean Radiator Fin ● 16 Clean Radiator (inside) ● Change Fuel Hose, ●...
Page 28 (2) Oil Filter Change First Time 50 hour mark or after Every 200 hours OILFILTER ① Drain the engine oil completely, as described in 『 1 1 (1) Oil Change 』 . ② Loosen and remove the oil filter, using an oil filter wrench. ③...
Page 29 (4) Clean/Change Fuel Strainer Clean 50 hours and Every 100 hours afterwards Replace Every 400 hours ① Turn the fuel lever to [CLOSE]. FUEL LEVER CLOSE ② Unscrew the retainer ring counterclockwise, and remove the RETAINER cup and the filter element. RING ③...
Page 30: Long-Term Storage
<Caution> Change the seal, whenever changing coolant/water. Seal Part No. ： 6C090-58961 (Kubota) ⑤ Replace all the coolant/water in the engine/radiator and sub tank. ⑥ Fill the coolant/water to the MAX level (to the upper edge of the inlet). ⑦ Reinstall the radiator cap. ⑧...
Page 31 Caution: Injuries When performing equipment check and maintenance, always stop the engine. Caution : Fire ・・・・ B urns When checking engine, always stop the engine, and keep away from fire. Temperatures around engine, muffler and exhaust can get extremely high. Wait until the engine cools down, before performing any inspection.
Page 32: Engine Wiring Diagram
14. Engine Wiring Diagram - 30 -...
Page 33: Generator Wiring Diagram
15. Generator Wiring Diagram - 31 -...
