Program Up/Down Switch *optional*
Drill a 1/4" hole in the pick guard or guitar top and mount
the switch using the nuts and washers supplied. Orient the
switch as desired: pushing the toggle towards the violet
wire scrolls up, and towards the yellow wire scrolls down.
Plug the connector into the Hexpander on the rows marked
S1 and S2 with only the black wire on the ground row.
Down
Yellow
52
Up
Program
Up/Down
Switch
Violet
Hexpander
S1
S2
