Color code

The ghost saddle pickups are all identical and can be installed in
any string position. If you are installing the Hexpander and you
must feed the wires through a hole from one cavity to another,
you may need to mark the wire ends to be able to tell which is
which. When plugging into the Summing Board for Acousti-
phonic only installations, the pickups can go in any order.
Lo-E (6)
Hi-E (1)
A (5)
B (2)
D (4)
G (3)
42
