Models:
EXCLAIM-36
EXCLAIM-42
Wood Burning Fireplace
Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfi re. Overfi ring will void your
warranty.
• Comply with all minimum clearances to
combustibles as specifi ed. Failure to
comply may cause house fi re.
Installation and service of this fi replace
should be performed by qualifi ed personnel.
Hearth & Home Technologies suggests NFI
certifi ed or factory-trained professionals, or
technicians supervised by an
NFI certifi ed professional.
DO NOT DISCARD THIS MANUAL
Read, understand
and follow these
instructions for safe
i n s t a l l a t i o n a n d
operation.
Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09
NOTICE
Leave this manual with
party responsible for
use and operation.
Hot screen/mesh and glass doors will cause burns.
DO NOT touch screen/mesh or glass doors until
cooled
NEVER allow children to touch screen/mesh or glass
doors
Keep children away
CAREFULLY SUPERVISE children in same room as
fi replace.
Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other
fl ammable materials.
Keep clothing, furniture, draperies and other
fl ammable materials away.
Fire Risk
For use with solid wood fuel or decorative
gas appliance only.
DO NOT install unvented gas logs.
Owner's Manual
Installation and Operation
WARNING
HOT SURFACES!
Screen/mesh, glass doors
and other surfaces are hot
during operation AND cool
down.
WARNING
1

Advertisement

Table of Contents
loading

Summary of Contents for Heat & Glo EXCLAIM-36

  • Page 1 • For use with solid wood fuel or decorative technicians supervised by an gas appliance only. NFI certifi ed professional. • DO NOT install unvented gas logs. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 2: Congratulations

    ADJUST DAMPER TO THE FULLY OPEN POSITION. 1915 W. SAUNDERS ST., MT. PLEASANT, IA 52641. Note: An arrow ( ) found in the text signifi es change in content. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 3: Table Of Contents

    H. Inspect Fireplace and Components C. Chimney Components Framing & Clearances D. Service Parts A. Select Fireplace Location E. Contact Information B. Clearances C. Sidewalls/Surrounds D. Frame the Fireplace Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 4: Warranty

    Warranty Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 5 Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 6: Listing And Code Approvals

    NOTICE: This fireplace is tested and approved as a decorative fi replace. It should not be factored as a primary heat source in residential heating calculations. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 7: User Guide

    Section 2.J. Firescreen Wood Fuel (not shown) Section 2.M. Section 2.E. Hearth Glass Doors (not shown) Section 2.H., 3.E. Clear Space Section 2.L. Figure 2.1 General Operating Parts Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 8: Seasoned Wood

    fi rewood, placed to allow combustion air and fl ames between them. CAUTION! Odors and vapors released during initial operation may be irritating to sensitive individuals. Open windows for air circulation. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 9: Glass Doors

    BEFORE lighting fi re. 48 in. (1219 mm) Clear Space Front of Fireplace 12 in. (305 mm) Clear Space Sides of Fireplace (from the FP opening) Figure 2.3 Clear Space Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 10: Wood Fuel

    fi relogs that have been evaluated for the application in manufactured fi replaces and refer to fi relog warnings and caution markings on packaging prior to use. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 11: Maintainance And Service

    Chimney Slip Section TR11/TR11T TCT1175 ST1175 TR444/TR442 ST475 Terra Cotta Round Termination Cap Square Termination Cap Termination Cap Available US only Figure 3.1 Chimney & Termination Cap Cleaning Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 12: Check Firebox Refractory

    • Light deposits Use household glass cleaner • Heavy deposits Use wood ash on damp cloth or, Use commercial fi replace glass cleaner (consult with your dealer) Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 13: Troubleshooting Guide

    Add glass doors to slow down air fl ow. Overdrafting Check for correct vent height; too much vertical height creates overdrafting. Check location of vent termination (refer to chimney assembly section). Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 14: Getting Started

    (1.83m) off (Section 11) ground level. Hearth extension Outside (Section 11) combustion air Factory-built fireplace (Section 7) Protective metal hearth strip(s) (Section 7) Figure 5.1 Typical Fireplace System Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 15: Design And Installation Considerations

    Tight sealing construction of the structure • Mechanical exhausting devices NOTICE: Hearth & Home Technologies Inc. recommends • Improper location of the chimney the use of direct vent fi replaces in basements. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 16: Locating Fireplace & Chimney

    • Below adjacent structure • Lower roof line • Insulated exterior chase • Avoid outside wall in cooler climates Windward Leeward Multi-level Roofs Figure 5.2 Recommended Chimney Locations Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 17: Tools And Supplies Needed

    Misc. screws and nails G. Fireplace System Requirements This fi replace system requires: • Hearth Refractory • Grate Assembly • Outside Air Hood Duct must be installed, but sold separately. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 18: Framing & Clearances

    59 1/2 92 3/4 46 3/8 21 1/2 65 5/8 28 1/2 any perpendicular wall. EXCLAIM-42 1308 1511 2356 1178 1667 Figure 6.1 Fireplace Locations (Framing dimensions shown) Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 19: Clearances

    1/2 in. [13 mm]) to floor Figure 6.2 Clearances to Combustible Materials Note: Chimney air kit and 11-10 in./279-254 mm adapter are not shown, but are required in Canada. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 20: Sidewalls/Surrounds

    * If interior of chase will be drywalled, add the thickness to this measurement. ** Adjust header height for a raised floor under fireplace. Figure 6.4 Framing the Fireplace Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 21: Installation Of Fireplace

    Slide fi replace into position (brackets can be used to Figure 7.2 Bending Refractory Shipping Tabs anchor fi replace in position). Back Down • Skip to Section 7.G. for further EXCLAIM-36 instructions. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 22: Position The Fireplace (Exclaim-42 Only)

    fi t. Scrape away excess with a regular screwdriver. See Figure 7.8. Figure 7.5 Shipping Spacers Figure 7.6 Lifting Out the Hearth Stone Figure 7.8 Scrape Away Rough Edges Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 23: Install The Refractory (Exclaim-42 Only)

    Place grate into grate brackets. See Figure 7.13. Figure 7.10 Attaching Back Refractory • Replace smoke shield. GRATE BRACKET Figure 7.13 Grate Secured in Grate Bracket • Replace left and right screens. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 24: Place Protective Metal Hearth Strips

    Check fi replace opening for square to ensure proper fi t Figure 7.16 Possible Outside Air Inlet Locations of glass doors. Measure diagonals of fi replace opening to make sure they are equal. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 25: Install Outside Air Kit

    The outside air hood must be at least 3 ft (.91 m) below the top of the uppermost chimney section. Flexible Duct (not supplied) Outside Air Shield Inlet Ring 2 Wire Ties Figure 7.18 Outside Air Installation Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 26: Chimney Assembly

    Ceiling firestops are required where chimney passes through ceiling or floor Figure 8.1 Typical Chimney System - Guidelines for Chimney System Installation Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 27: Chimney Requirements

    SLA10 16-3/4 Effective Height 90 ft (27.4 m) max. height (bottom of fireplace * Dimensions refl ect effective height. to top of starter collar) Figure 8.2 Chimney Requirements Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 28: Using Offsets/Returns

    98 7/8 2511 Proper assembly of air cooled chimney parts results in an overlap of chimney joints of 1-1/4 in. (32 mm). Effective length is built into this table. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 29: Assemble Chimney Sections

    Vertical straight runs of chimney must be supported every 35 ft (10.7 m). D. Install Chimney Air Kit • Required in Canada. • Follow instructions provided with this accessory. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 30: Install Ceiling Firestops

    Note: Use same dimensional lumber for framing home (use 600° F sealant). ceiling firestop and joists. Catalog # FS538 FS540 Figure 8.5 Installing the Ceiling Firestop Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 31: Install Attic Insulation Shield

    17 in. (432 mm) diameter 6 Tabs bent in 90° Insulation Insulation 13 in. Ceiling Firestop Pipe (330 mm) Figure 8.8 Install Attic Insulation Shield (fi restop below ceiling) Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 32: Cut Out Hole In Roof

    Caulk the fl ashing plate and roof junction as well as the vertical seam on the fl ashing. All nail heads must be caulked with a roofi ng sealant. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 33: Chimney Termination Requirements

    In a staggered installation with both gas and wood terminations, the wood termination cap must be higher than the gas termination cap. Figure 8.10 Multiple Chimney Locations Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 34: Chase Installations

    Failure to prevent contact between insulation or other Insulation Insulation materials and chimney system may cause overheating False Ceiling False Ceiling and fi re. Chimney Figure 9.1 Chase Assembly Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 35: Install Fireplace & Chimney

    CAUTION! DO NOT caulk the pipe to the chase top Galvanized Chase Top collar. • Caulk all seams to prevent leaks. • Refer to Figure 9.4. Figure 9.3 Chase Top Construction Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 36: Install Termination Cap

    Installing a TR11/TR444 Round Termination Cap chimney section Chase Top Chase Chimney Pipe Termination cap pipe and chimney section must overlap 1-1/2 in. (38 mm) Figure 9.6 Installing an ST1175/ST475 Square Termination Cap Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 37 2 in. (51 mm) 7 in. (178 mm Chase Chimney Pipe Termination cap pipe and chimney section must overlap 1-1/2 in. (38 mm) Figure 9.7 Installing a TCT1175 Terra Cotta Cap Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 38: Shrouds

    23 x 23 737 x 737 584 x 584 Min. Opening Width 26 x 26 20 x 20 660 x 660 508 x 508 Figure 10.2 Open Top Shroud Dimensions Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 39 34 x 34 34 x 34 864 x 864 864 x 864 Min. Height Above Radiation Shield Min. Opening Width Min. Opening Height Figure 10.4 Roofed Style Shroud Dimensions Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 40: Finishing

    5-1/8 in. Common Brick 0.20 5-1/8 in. Ceramic Tile 12.50 0.08 12-1/4 in. Armstrong™ Privacy Guard Plus 0.46 2.18 1/2 in. Marble 14.3-20.0 0.07-0.05 14-5/8 in. - 20-3/8 in. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 41 Noncombustible Finishing Material Non-combustible Finishing Materials Noncombustible Framing Material Figure 11.5 Raised Platform Hearth Extension-Finishing Materi- Protective Metal Floor Hearth Strips Figure 11.3 Raised Platform Hearth Extension Detail Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 42 7-5/8 in. Finished Floor 30 in. Min. Hearth Extension Micore Noncombustible Material Protective Metal Hearth Strip Figure 11.8 Flush Hearth Extension Side View Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 43: Finishing Material

    2 in. (51 mm) Figure 11.10 Decorative Facing Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 44: Combustible Mantel

    Seal joint with Measured from top of fireplace opening non-combustible sealant EXCLAIM-36 Mantel Heights Figure 11.11 Clearances to Mantels or other Combustibles above Fireplace - I60 Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 45 Measured from top of fireplace opening Seal joint with non-combustible sealant Grid represents 1 in. squares EXCLAIM-42 Mantel Heights Figure 11.12 Clearances to Mantels or other Combustibles above Fireplace - I80 Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 46: Sidewalls/Surrounds

    Combustible or non-combustible mantel legs, surrounds and stub walls may be constructed per Figure 11.13. Figure 11.13 Mantel Leg or Wall Projections (acceptable on both sides of opening) Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 47: Accessories

    Repack beyond 4 in. (102 mm) insulation from fireplace side. knockout 4 in. (102 mm) Figure 12.1 Gas Line Installation Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 48: Reference Materials

    (219 mm) (219 mm) 9-5/8 in. 9-1/2 in. 18-1/2 in. 7-5/8 in. 42 in. (194 mm) (244 mm) (241 mm) (1067 mm) (470 mm) Figure 12.2 Dimensions - EXCLAIM-42 Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 49: Optional Components

    66 in. (1676 mm) 20 in. (508 mm) HX4 Hearth Extension 1/2 in. (13 mm) Bi-fold Glass Doors See your Heatilator dealer for a complete listing of optional components. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 50: Chimney Components

    4 in. (102 mm) (457 mm) Outside Diameter 13 in. 13 in. (330 mm) (330 mm) SLA10 Adaptor SL11/SL4 Vent Stabilizer (Required in Canada) CAK5A Chimney Air Kit Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 51 RF570 Roof Flashing 15-1/4in. JB577 Chimney Joint Band (387 mm) 28 in. 39-7/8 in. 13 in. (711 mm) (1013 mm) (330 mm) CB576 Chimney Joint Band RF571 Roof Flashing Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 52 (584 mm) ST1175/ST475 - Square Termination Cap 20 in. (508 mm) 17 in. (432 mm) 9-3/8 in. (238 mm) 9-1/4 in. (235 mm) TCT1175 - Terra Cotta Cap Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 53 (340 mm) 2 in. (51 mm) CT56 Chase Top LDS33/LDS46 Decorative Shroud Catalog # LDS33 8-1/2 LDS46 1219 1829 8-1/2 LDS-BV Decorative Shroud Catalog # 12-1/2 15-1/2 LDS-BV Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 54: Service Parts

    D. Service Parts Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 55 D. Service Parts (continued) Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
  • Page 56: Contact Information

    6748942, 6769426, 6774802, 6796302, 6840261, 6848441, 6863064, 6866205, 6869278, 6875012, 6880275, 6908039, 6919884, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408, 2313972; (Australia) 780250, 780403, 1418504 or other U.S. and foreign patents pending. Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev D • 03/09...
