Heat & Glo EXCLAIM-50 Owner's Manual

Woodburning fireplace
Hide thumbs Also See for EXCLAIM-50:
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions on installation, operation, or service.
NOTICE:
DO NOT discard this manual!
Model(s):
WOODBURNING FIREPLACE
Installation and service of this appliance should be performed by
Owner's Manual
Operation and Care
Heat & Glo • Exclaim-50 Owner's Manual • 4013-270 • Rev O • 04/21
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• DO NOT overfire. Overfiring will void your
warranty.
• Comply with all minimum clearances to com-
bustibles as specified. Failure to comply may
cause house fire.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fireplace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other flammable
materials.
• Keep clothing, furniture, draperies and other flammable
materials away.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may overfire and generate poisonous
gases (i.e. carbon monoxide).
1

Advertisement

Table of Contents
loading

Related Manuals for Heat & Glo EXCLAIM-50

Summary of Contents for Heat & Glo EXCLAIM-50

  • Page 1 • Keep clothing, furniture, draperies and other flammable materials away. WARNING Fire Risk. For use with solid wood fuel only. Other fuels may overfire and generate poisonous gases (i.e. carbon monoxide). Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 2: Table Of Contents

    1. Hardwood vs. Softwood 2. Moisture content 3. Seasoning 4. Storing Wood 5. Burning Process 6. Creosote Formation 7. Processed Solid Fuel Firelogs D. First Fire E. Lighting Instructions Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 3: Welcome

    DECORATIVE GAS APPLIANCE IN THE FIREPLACE, CONTACT: HEARTH & HOME TECHNOLOGIES. ADJUST DAMPER TO THE FULLY OPEN POSITION. 7571 215th Street West, Lakeville, MN 55044. P.N. 4021-956B Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 4: Limited Lifetime Warranty

    Firebox and heat exchanger, FlexBurn® System 3 years Lifetime (engine, inner cover, access cover and fireback) None 1 Year All purchased replacement parts Page 1 of 2 4021-645L 10/20 Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...
  • Page 5 EXPRESSED WARRANTY SPECIFIED ABOVE FOR THE APPLICABLE PRODUCT. Some States do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Page 2 of 2 4021-645L 10/20 Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 6: Product Specific And General Information

    Other fuels may overfire and generate WARNING! Do Not operate an unvented gas log set in this poisonous gases (i.e. carbon monoxide). fireplace with the chimney removed. Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 7: Important Safety And Operating Information

    24 in. (610 mm) Front of Fireplace Clear Space harm. For more information go to: www. Sides of Fireplace (from the FP P65Warnings.ca.gov. opening) Figure 3.1 Clear Space Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 8: Grate

    If doors are left partly open, gas and flame may be drawn out of the freplace opening. Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 9: General Operating Parts

    Flue Damper Outside Air Control Section 2.I. Section 2.F. UP to Open UP to Open DOWN to Close DOWN to Close Figure 3.2 General Operating Parts Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 10: Flue Damper

    Refer to Figure 3.3 for how to properly use them. FULLY OPEN PARTLY OPEN CORRECT INCORRECT FULLY CLOSED PARTLY CLOSED CORRECT INCORRECT Figure 3.3 Operating Positions of Bi-fold Doors Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 11: Fuel

    Seasoning time may vary depending on drying WARNING! Risk of Fire! conditions. • DO NOT burn wet or green wood. • Wet, unseasoned wood can cause accumulation of creosote. Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 12: Storing Wood

    • use gasoline, lantern fuel, kerosene, charcoal lighter fluid or similar liquids to start or “freshen up” a fire in this fireplace. Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 13: Maintenance And Service

    In the event of a chimney fire, Hearth & Home Tech- nologies recommends replacement of the chimney and inspection of the adjacent structure to the provisions of NFPA Level III inspection criteria. Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 14: Grate

    Frequency: Tools Needed: • Inspect condition of refractory. Replace if crumbly or otherwise deteriorated, or if cracks exceed 1/4 in. (6 mm). Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 15: Troubleshooting

    Add glass doors to slow down air flow. Overdrafting Check for correct vent height; too much vertical height creates overdrafting. Check location of vent termination (refer to chimney assembly section). Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 16: Faqs

    Visit www.heatilator.com to find a dealer. Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...
  • Page 17 Air register from furnace near fireplace? Doors opening and closing? Outside air Window closed Combustion closed? for start-up? air control Figure 5.1 Factory-built Fireplaces: Troubleshooting Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 18: Reference Materials

    Brick Refractory - Right Side, 33.75 H x 25.70 W SRV4013-065 Refractory Retainer Kit 34584 Refractory Retainer SRV11847 3 ea. Grate Retainer SRV4017-060 2 ea. Owner’s Manual 4013-270 Installation Manual 4013-269 Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 19: Accessories

    Doors DM100 Bi-fold Glass Doors with Black Trim Grand Vista Cabinet Style Mesh Doors, black GV100BK Gas Inserts Gas Log Sets Gas Log Lighters Wood-burning Inserts Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...

  • Page 20: Contact Information

    7216645, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408, 2313972; (Australia) 780250, 780403, 1418504 or other U.S. and foreign patents pending. Printed in U.S.A. - Copyright 2012 Heat & Glo • Exclaim-50 Owner’s Manual • 4013-270 • Rev O • 04/21...
