Models:
EXCLAIM-36

Woodburning Fireplace

Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfi re. Overfi ring will void your war-
ranty.
• Comply with all minimum clearances to
combustibles as specifi ed. Failure to comply
may cause house fi re.
Installation and service of this fi replace should
be performed by qualifi ed personnel. Hearth
& Home Technologies suggests NFI certifi ed
or factory-trained professionals, or technicians
supervised by an NFI certified
professional.
Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07
CAUTION
DO NOT DISCARD THIS MANUAL
Read, understand
and follow these
instructions for safe
i n s t a l l a t i o n a n d
operation.
Owner's Manual
Installation and Operation
Leave this manual with
party responsible for
use and operation.
WARNING
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot
during operation and cool down.
Keep children away.
CAREFULLY SUPERVISE children in same room
as fi replace.
Alert children and adults to hazards of high
temperatures.
Keep clothing, furniture, draperies and other
combustibles away.
WARNING
Fire Risk
For use with solid wood fuel or decorative
gas appliance only.
Do not install unvented gas logs.
1

Advertisement

Table of Contents
loading

Summary of Contents for Heat & Glo EXCLAIM-36

  • Page 1: Woodburning Fireplace

    For use with solid wood fuel or decorative or factory-trained professionals, or technicians gas appliance only. supervised by an NFI certified • Do not install unvented gas logs. professional. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 2 DECORATIVE GAS APPLIANCE IN THE FIREPLACE, CONTACT: HEARTH & HOME TECHNOLOGIES INC., ADJUST DAMPER TO THE FULLY OPEN POSITION. 1915 W. SAUNDERS ST., MT. PLEASANT, IA 52641. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 3: Table Of Contents

    A. Gas Log/Lighter Provisions ....25 Note: An arrow ( ) found in the text signifi es change in content. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 4: Listing And Code Approvals

    Hearth & Home Technologies. Hearth & Home Technologies disclaims any responsibility for, and the warranty and agency listing will be voided by the above actions. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 5: Getting Started

    Basement installations should be avoided due to stack effect. Stack effect creates negative pressure in lower levels. Hearth & Home Technologies recommends the use of direct vent fi replaces in basements. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 6 Consider the fi replace location relative to fl oor and ceiling and attic joists. Recommended Recommended Location Location Marginal Location Location Recommended Location Recommended Windward Outside Air Intake Leeward Multi-level Roofs Figure 2.1 Recommended Chimney Locations Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 7: Typical Fireplace System

    V-shaped standoffs (spacers) Mantel and surround Decorative facing and trim Hearth extension Outside combustion air Factory-built fireplace Protective metal hearth strip(s) Figure 2.2 Typical Fireplace System Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 8: Tools And Supplies Needed

    Follow these instructions carefully during the • Keep fi replace dry. installation to ensure maximum safety and benefi t. • Mold or rust may cause odors. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 9: A. Selecting Fireplace Location

    As a room divider 28 in. (711 mm) 48 in. (1219 mm) EXCLAIM-36 With Outside 49-1/2 1257 Without 45-1/2 Outside Air 1156 Figure 3.1 Fireplace Locations Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 10: Clearances

    (except at nailing flanges where it is 1/2 in. (13 mm)) Figure 3.2 Clearances to Combustible Materials Note: Chimney air kit and 11-10 in./279-254 mm adapter are not shown, but are required in Canada. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 11: Sidewalls/Surrounds

    Use only noncombustible material below the top of the front standoffs. 45-1/2 in. (1156 mm) 28 in. (711 mm) Figure 3.4 Framing the Fireplace Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 12: Construct The Chase

    fi replace Figure 3.5 Chase Assembly • Maximum unsupported chimney above 1.83 roof Note: A maximum of two pairs of offsets and returns may be used. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 13: Installation Of Fireplace

    fi replace. See Figure 4.4 for handle location/operation. Flexible Duct (not supplied) Outside Air Plate Outside Air Assembly Shield 2 Wire Ties Figure 4.1 Outside Air Installation Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 14 Figure 4.3 Outside Combustion Air Placement Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 15: Secure The Fireplace

    fi replace opening for square. Measure diagonal dis- tances of the opening to make sure they are equal. If they are not, continue to shim the fi replace until those diagonals are equal. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 16: Chimney Assembly

    • Chimney performance may vary. • Trees, buildings, roof lines and wind conditions affect performance. • Chimney height may need adjustment if smoking or overdraft occurs. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 17: Chimney Requirements

    • Do NOT connect to any air distribution duct or SL1148 SL448 46-3/4 1187 system. SLA10 16-3/4 * Dimensions refl ect effective height. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 18: Using Offsets/Returns

    Proper assembly of air cooled chimney parts results in an overlap of chimney joints of 1-1/4 in. (32 mm). Effective length is built into this table. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 19: Assemble The Chimney Sections

    fl oor or every 10 ft (3.05 m) of clear space. • Use same dimensional lumber as joists. Ceiling fi restop slows spread of fi re and reduces cold air infi ltration. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 20: Install The Attic Insulation Shield

    Maintain specifi ed cleaances around chimney. • Check instructions and local codes for further details. 3 in. (76 mm) overlap Figure 5.6 Prepare Attic Insulation Shield Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 21: Double-Check The Chimney Assembly

    Straight chimney sections may be secured with screws (not to exceed 3/4 in./19 mm in length) at the joints. Keep chimney sections from separating or twisting. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 22: Complete The Enclosure

    Refer to the installation instruc- 6 in. 20 in. (152 mm) min. (508 mm) min. tions supplied with the decorative cap cover. Figure 6.2 Multiple Chimneys Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 23 Install the Chimney Air Kit (required in Canada): When installing the chimney air kit, follow the instructions provided with this accessory. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 24: Chase Top

    2 in. (51 mm) min. 14-1/2 in. (368mm) max. Top of Pipe 1-1/2 in. (38 mm) min. overlap Figure 6.6 Installing a TR11T/TR442 Round Telescoping Termina- tion Cap Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 25 Installing a European Copper Series Termination Cap of the chase. Top of Pipe (CT11-King shown, available in US only) Figure 6.8 Installing a TCT1175 Terra Cotta Cap Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 26: Accessories

    Repack beyond 4 in. (102 mm) Insulation from fireplace side. Knockout 4 in. (102 mm) Figure 7.1 Gas Line Installation Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 27: Finishing

    Common Brick 0.20 5-1/8 in. Ceramic Tile 12.50 0.08 12-1/4 in. Armstrong™ Privacy Guard Plus 0.046 2.18 1/2 in. Marble 14.3-20.0 0.07-0.05 14-5/8 in. - 20-3/8 in. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 28 12 in. Hearth Extension (305 mm) 12 in. Min. (305 mm) 30 in. (762 mm) Min. min. Noncombustible Material Micore Hearth Strip Figure 8.5 Flush Hearth Extension Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 29: Finishing Material

    - use materi- Install protective als that meet or exceed minimum metal sealing strip(s) required insulating values Figure 8.6 Guidelines for Framing and Enclosing Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 30: Mantel

    This fi replace has been tested and listed for use with doors as specifi ed in Section 12.B. Fireplace Components. Please refer to the manual packed with each set of doors for instal- lation instructions. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 31: Operating Instructions

    Do not install unvented gas logs. maintain the system in top operating condition. open close Damper Handle Handle up - open Handle down - closed Figure 9.1 General Operating Parts Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 32: Outside Air

    • Doors must be fully opened or fully closed when operating fi replace. Partially opened doors may draw fl ame, smoke or heat from fi replace. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 33: Grate

    This sounds ridiculous but that is exactly what you are • Closer than required clearances to doing if you burn unseasoned wood. combustibles to fi replace. • Within space required for loading or ash removal. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 34: Starting A Fire

    fi replace and the refractory and paint to cure. You may Combustible materials may ignite. notice an industrial odor the fi rst few fi res. This is consid- ered normal. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 35: Troubleshooting

    Air register from furnace near fireplace? Damper closed? Doors opening and closing? Outside air Window closed closed? for start-up? Figure 10.1 Factory-built Fireplaces: Troubleshooting Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 36: Diagnostics And Problem Solving

    No: Need for all heat boosts possible How much heat output do you • Unrealistic expectations Explanation of decorative nature of fi replace; suggestion of expect? approved fi replace insert. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 37 Is the chimney clean? • No: Creosote odor Have chimney cleaned. • Yes: Damper closed too early Wait until fi re completely out before closing damper. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 38: Maintenance And Servicing The Fireplace

    ST475 Terra Cotta Round Termination Cap Termination Cap (CT11-King shown) Square Termination Cap Available US only Available US only Figure 11.1 Chimney & Termination Cap Cleaning Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 39: D. Maintenance Task List

    Failure to replace damaged components and make conduct a minimum of an NFPA 211 Level 2 inspection of proper repairs creates risk of fi re. the chimney. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 40: Reference Materials

    (219 mm) (235 mm) 9-5/8 in. 9-1/2 in. 18-1/2 in. 7-5/8 in. 36 in. (244 mm) (241 mm) (194 mm) (470 mm) (914 mm) Figure 16.1 Dimensions Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 41: Fireplace Components

    AK22 - Outside Air Kit Traditional Brick Pattern Refractory 66 in. (1676 mm) 20 in. (508 mm) HX4 - Hearth Extension 1/2 in. (13 mm) Herringbone Pattern Refractory Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 42: Chimney Components

    (457 mm) Outside Diameter 13 in. (330 mm) CAK5A - Chimney Air Kit SL11/SL4 - Chimney Stabilizer SL11/SL4 - Chimney Stabilizer (required in Canaga) (required in Canada) Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 43 RF571 - Roof Flashing 13 in. 2 in. (330 mm) (51 mm) JB577 - Chimney Joint Band 13 in. (330 mm) CB576 - Chimney Joint Band Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 44 (508 mm) LDS-BV Decorative Shroud 17 in. (432 mm) 9-3/8 in. Catalog # (238 mm) 12-1/2 15-1/2 LDS-BV 9-1/4 in. (235 mm) TCT1175 - Terra Cotta Cap Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 45 16 in. (406 mm) 21 in. (533 mm) 38-3/8 in. (975 mm) 25-3/4 in. (654 mm) 16 in. 20-5/8 in. (406 mm) (524 mm) CT11-Knight CT11-Pawn Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 46: Woodburning Termination Cap

    Minimum height is established with the bottom of the termination cap 7 in. (178 mm) above the chase top. Minimum height must increase accordingly for any height above 7 in. (178 mm). All dimensions are INSIDE dimensions. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 47 This page intentionally left blank. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 48: Service Parts

    D. Service Parts EXCLAIM-36 SERIES Service Parts Beginning Manufacturing Date: N/A Service Parts List Ending Manufacturing Date: Active 36 in. Woodburning Fireplace Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 49 Strip Protector 18320 18320 Side Trim 31326 31326 Screen Cover (top only) 31319 31319 Installation Instructions & Owner’s Manual 4013-204 4013-204 Powder Coat Touch-Up Paint 71479 71479 Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 50 This page intentionally left blank. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 51: Limited Warranty

    HHT reserves the right to make changes at anytime, without notice, in design, material, specifications and prices and the right to discontinue styles and products. Feb 2006 Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
  • Page 52: Contact Information

    6748942, 6769426, 6774802, 6796302, 6840261, 6848441, 6863064, 6866205, 6869278, 6875012, 6880275, 6908039, 6919884, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408, 2313972; (Australia) 780250, 780403, 1418504 or other U.S. and foreign patents pending. Heat & Glo • EXCLAIM-36 US-CAN Woodburning Fireplace • 4013-204 Rev D • 06/07...
