Heat & Glo EXCLAIM-36 Owner's Manual
Heat & Glo EXCLAIM-36 Owner's Manual

Heat & Glo EXCLAIM-36 Owner's Manual

Wood burning fireplace
Hide thumbs Also See for EXCLAIM-36:
Table of Contents

Advertisement

Models:
EXCLAIM-36
EXCLAIM-42
Wood Burning Fireplace
Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re may result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfi re. Overfi ring will void your
warranty.
• Comply with all minimum clearances to
combustibles as specifi ed. Failure to
comply may cause house fi re.
Installation and service of this fi replace
should be performed by qualifi ed personnel.
Hearth & Home Technologies suggests NFI
certifi ed or factory-trained professionals, or
technicians supervised by an
NFI certifi ed professional.
DO NOT DISCARD THIS MANUAL
Read, understand
and follow these
instructions for safe
i n s t a l l a t i o n a n d
operation.
Heat & Glo • EXCLAIM-36, EXCLAIM-42 • 4013-251 Rev H• 3/11
NOTICE
Leave this manual with
party responsible for
use and operation.
Hot screen/mesh and glass doors will cause burns.
DO NOT touch screen/mesh or glass doors until
cooled
NEVER allow children to touch screen/mesh or glass
doors
Keep children away
CAREFULLY SUPERVISE children in same room as
fi replace.
Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other
fl ammable materials.
Keep clothing, furniture, draperies and other
fl ammable materials away.
Fire Risk
Owner's Manual
Installation and Operation
WARNING
HOT SURFACES!
Screen/mesh, glass doors
and other surfaces are hot
during operation AND cool
down.
WARNING
For use with solid wood fuel or decorative
gas appliance only.
DO NOT install unvented gas logs.
1
