Rear side

31. Handle
32. IDT
33. Embroidery unit connection socket

Top parts

34. Pre-tension device for threading and bobbin
winding
35. Bobbin winder thread guide
36. Thread guide
37. Bobbin thread guides
38. Bobbin winder lever
39. Bobbin spindle
40. Bobbin thread cutter
41. Auxiliary spool pin
42. Spool caps
43. Spool pin
44. Thread tension
45. Take-up lever

Accessory tray

The accessory tray features special compartments
for presser feet and bobbins, plus space for needles
and other accessories. Store the accessories in the
tray so they are easily accessible.
46. Space for accessories
47. Removable tray for presser feet
48. Removable bobbin holder
34 35 36 37
45 44
46
47
48
Accessory tray
38 39 40
43 42 41
31
32
33
1:9
