QUICKSTART DISPLAY
easy reference
Sensitivity level. The sensitivity bar and
1
numbers indicate how responsive the detector is
to a target in the presence of ground noise and/or
electromagnetic interference. Numbers range
between 1 and 32. When the shift button next to
the number is pressed the detector moves
between semi-auto and manual sensitivity. See
page 49 for details.
Threshold level. The threshold setting controls
2
the audible level of threshold 'hum' during
detecting. When the shift button next to the
adjustment arrow is pressed, the threshold hum
increases or decreases. See page 50 for details.
Depth indicator. The clear portion of the depth
3
indicator represents the approximate distance of
a target below the coil. The top of the indicator
represents the position of the coil and the bottom
represents 300mm (12 inches) from the coil. The
bar will be clear if the target is too far from the
coil or its depth cannot be accurately gauged.
Iron Mask. This shaded block indicates whether
4
IRON MASK function is ON or OFF.
See page 45.
THE MINELAB EXPLORER II
Smartfind display. The shaded and unshaded
5
areas of the screen are Smartfind's preset
Discrimination setting. Smartfind also has an
alternative Iron Mask setting. See pages 42-43.
Pinpoint. This shaded block indicates whether
6
PINPOINT is ON or OFF. See page 59.
Battery life. This icon indicates the charge remaining
7
in the installed batteries. See page 27.
Adjustment arrows. Pressing shift buttons next to
8
these arrows increases or decreases preset
settings.
Full screen icon. Selection enlarges display to fill
9
screen. See page 48. This icon temporarily
changes to show the threshold level setting when
threshold is being adjusted.
Target crosshair. Represents the detected
10
object's properties on a two-dimensional scale of
discrimination. See page 42-43.
