Summary of Contents for ALLEN & HEATH Xone:3D
-
Page 1: User Guide
USER GUIDE Publication AP6388 Allen & Heath XONE:3D User Guide... -
Page 2: Warranty
EMC standards. Customers requiring more information about EMC and safety issues can contact Allen & Heath. XONE:3D User Guide AP6388 Issue 3 Copyright © 2006 Allen & Heath Limited. All rights reserved Allen & Heath Limited Kernick Industrial Estate, Penryn, Cornwall, TR10 9LU, UK http://www.allen-heath.com http://www.xone.co.uk... -
Page 3: Software Installation Pc
Software Installation (Windows 2000 and XP) Follow the procedure described below to install the USB audio and MIDI drivers: 1— Connect the Xone:3D to your mains electricity supply and switch it on. Do not connect the 3D to the PC at this time. -
Page 4: Software Installation Mac
Xone :3D is visible as a MIDI device. 6— Insert the Xone:3D CD-ROM and select the Configuration link. Now follow the instructions to install the Xone:3D Configuration Utility on your Mac. For further information on the Configuration Utility see Page 12. -
Page 5: Packed Items
Allen & Heath to Mains Lead Type A-B USB Lead register your product. Check that the correct To connect the Xone:3D mains plug is fitted. to your computer. 2x pairs of Overlay Sheets To identify MIDI control functions for popular DJ... -
Page 6: Specifications
The rack ears are fixed in place using the 6x M4 screws provided. Ensure that air vents are not obstructed. 465 rack ear fixings 483 with rack ears fitted Allen & Heath XONE:3D User Guide... -
Page 7: Table Of Contents
CONTENTS Congratulations on purchasing the Allen & Heath Xone:3D performance DJ mixer. To ensure that you get the maximum benefit from the unit please spare a few minutes familiarizing yourself with the controls and setup procedures outlined in this user guide. For further information please refer to the additional information available on our web site, or contact our technical support team. -
Page 8: Panel Drawings
JOG / SELECT JOG / SELECT + 10! + 10! + 10! + 10! FREQ FREQ 20Hz 20Hz 20kHz 20kHz XFADE CURVE FILTER 1 O N FILTER 2 O N LEVEL + 12 + 12 PHONES Allen & Heath XONE:3D User Guide... -
Page 9: Introduction
INTRODUCTION TO THE XONE:3D Welcome to the Allen & Heath Xone:3D digital DJ workstation. This system has been designed with the help of some of the world’s most cutting edge DJs to provide a seamless integration of traditional and computer based audio replay systems. -
Page 10: Description
DESCRIPTION The diagram below shows the signal flow through the Xone:3D system. MIXER— Each of the 4 channels can select one of 3 sources: phono, line or soundcard audio as shown. RIAA phono preamps are available on channels 2, 3 and 4. - Page 11 The BPM counter outputs MIDI clock so that a slave device such as a hardware or software sequencer can be synchronized to the timing of a track playing through the Xone:3D. To aid synchronization the MIDI clock can be momentarily speeded up or slowed down by operating the PUSH/PULL lever.
-
Page 12: Soundcard Operating Modes
SOUNDCARD OPERATING MODES The Xone:3D soundcard can be configured to operate in one of two modes. Choose the mode that best suits the audio requirement of the computer application you are running. Before starting make sure you have installed the ASIO drivers for your selected USB port as described at the start of this guide. - Page 13 SOUNDCARD OPERATING MODES To configure the soundcard operating mode and to select its sources, run the Configuration Utility software provided on the Xone:3D Utility CD. TO CHANGE THE SOUNDCARD MODE Important Note: Close all audio and MIDI applications running on your PC before starting the Configuration Utility.
-
Page 14: Channel Input
+6dB. Turn LEVEL down if the +10 peak meter starts flashing. Channel Equalizer/Isolator The Xone:3D is equipped with a very powerful 3 band EQ stage providing a controlled +6dB of boost when fully clockwise, but full isolation (cut) of each band for dramatic effect when fully anti- clockwise. - Page 15 ‘+6’. Turn down the level control if the +10 peak indicator lights. Channel Fader A high quality, smooth travel dual-rail fader adjusts the channel signal level from fully off to fully on. Allen & Heath XONE:3D User Guide...
-
Page 16: Mix And Monitor
Warning ! To avoid damage to your hearing do not operate the headphones or sound system at excessively high volume. Continued exposure to high volume sound can cause frequency selective or wide range hearing loss. Allen & Heath XONE:3D User Guide... -
Page 17: Filters And Lfo
It ranges from very low frequency (20Hz) to very high (20kHz). FILTER 1 ON Filter On Switch Switches the filter on and off. The light ring around the button illuminates when the filter is active. Allen & Heath XONE:3D User Guide... -
Page 18: Fx Returns And Crossfader
FREQ XFade Curve Control This control adjusts the crossfader curve between dipped response, ideal for seamless beat mixing, and fast-attack, suitable for scratch or cut mixing . 20Hz 20kHz XFADE CURVE FILTER 1 ON Allen & Heath XONE:3D User Guide... -
Page 19: Front Controls And Connectors
0dB operating level. When the Mic channel is not in use, always turn the level control fully anti-clockwise to prevent unwanted noise from this sensitive input entering the main Mix. Allen & Heath XONE:3D User Guide... -
Page 20: Rear Connectors
I N S T R U C T I O N S s h e e t other instruments. included with the Xone:3D and connect turntables which require printed on the rear panel. RIAA equalisation. Alternatively, Check that the correct mains lead... - Page 21 192kHz. samplers and other effects units, an Use the Xone:3D Configuration Utility additional monitor, zone or recorder. software to select which signals are routed to the SPDIF connectors.
- Page 22 LFO and Stop/Start. interface using general purpose switches You can connect the MIDI OUT of and potentiometers. We recommend 10k one Xone:3D to the MIDI IN of or 20k ohm linear law pots. A simple another. schematic is shown here.
-
Page 23: Bpm Counter
Stop/Start control. Pressing and holding this switch for approximately 5sec will turn off the Xone:3D internal MIDI clock and the BPM display will change to OFF. Pressing and hold the STOP/START... - Page 24 TEMPO If MIX is selected all music played through the main outputs of the Xone:3D will be analysed. This can be used to ensure that a mix compilation or DJ set is held at a strict DEPTH tempo.
-
Page 25: Lfo
In its left position Filter 1 only is modulated, in the right hand position Filter 2 only is modulated. In the centre position both Filter 1 and Filter 2 will be modulated by equal amounts. Allen & Heath XONE:3D User Guide... -
Page 26: Midi Control Section
Pressing a switch will send template depending upon the serial a “note on” MIDI message and turn on the number of the Xone:3D console. Please indicator. Pressing the switch again will refer to the User Options later in this send another “note on”... -
Page 27: Midi Messages
Use Map2 with Ableton Live 5 software. Map1 is recommended for use with Native Instruments Traktor software. MIDI Channel Number Run the Xone:3D Configuration Utility to select the required MIDI channel number from 1 to 16. Default is channel 16. FOOTSWITCH... -
Page 28: Midi Implementation Chart
Filter 2 Freq 8-45 Dedicated Controls Program Change System Exclusive System Common Song Position Song Select Tune Request System Real Time Clock Commands Aux Messages Local On/Off All Notes Off Active Sensing System Reset Allen & Heath XONE:3D User Guide... -
Page 29: Midi Note Chart
MIDI NOTE CHART Note No. Note No. Note No. Note No. (Hex) (Decimal) Note Name (Hex) (Decimal) Note Name C#-2 D#-2 F#-2 G#-2 A#-2 C#-1 D#-1 F#-1 G#-1 Allen & Heath XONE:3D User Guide... -
Page 30: Filter Reference
The vertical scale shows the amount of cut or boost around the normal 0dB operating level. The horizontal scale shows the change in frequency from low (bass) to high (treble). 1kHz Allen & Heath XONE:3D User Guide... -
Page 31: Operating Levels
! As the session wears on ear fatigue may set in, and the speaker cones may become hot so reducing the effectiveness of the system and listeners to gain any benefit from increased volume. Allen & Heath XONE:3D User Guide... -
Page 32: Earthing
Use good quality cables and connectors and check for correct wiring and reliable solder joints. Allow sufficient cable loop to prevent damage through stretching. If you are not sure ... Contact your service agent or local Allen & Heath dealer for advice. Allen & Heath XONE:3D User Guide... -
Page 33: Cables And Connections
UNBALANCED UNBALANCED XLR MALE CABLE I SPDIF OPTICAL - TOSLINK CABLE J MIDI - 5-pin DIN CABLE K SPDIF RCA - 75 ohm coax CABLE L USB TYPE A USB TYPE B MAX 2M Allen & Heath XONE:3D User Guide... -
Page 34: Faqs
When you change mode the soundcard has to disconnect from the computer, reconfigure itself, then reconnect. Occasionally the audio sub system does not restart after a mode change. Reboot your Xone:3D and it should work fine. Never change the soundcard mode while running an application as this may cause it to crash. -
Page 35: Setting Up Ableton Live Lite 5
‘Audio’ tab. Once the 3D is connected, change the driver type to ‘ASIO’ this will, in turn, set the Audio Device to ‘Xone:3D USB ASIO driver’ In the ‘Settings’ section click on the ‘Input Config’ button. 4— Select the ‘1/2 (stereo)’ op- tion and de-select the ‘1 (mono) - Page 36 Output 3/4 maps to Channel 1 on the Xone 3D (select the SC1-2 button). Output 5/6 maps to Channel 1 on the Xone 3D (select the SC1-2 button). Channel 4 on the Xone 3D will mirror Channel1. Allen & Heath XONE:3D User Guide...
-
Page 37: Mixer Troubleshooting
BPM processor not working. contact your service Try rebooting the mixer and agent if it still does not work con- tact your service agent Is there audio on the Does the Xone:3D Utility channels as shown by register that unit the meters? -
Page 38: Soundcard And Midi Troubleshooting
Are the supplied ASIO drivers properly installed? Are you plugged into the same USB port that you used when installing the drivers? With the Xone:3D powered up and connected to the correct USB port on your PC , click on START SETTINGS... - Page 39 SETTINGS CONTROL PANEL SOUNDS and AUDIO DEVICES Select the Audio Tab and using the drop down menu select the Xone:3D WDM Audio as the default device, shown below: Apply this setting and click OK. Close all other windows and open up Windows Media Player and try playing a file.
-
Page 40: Updating Firmware
UPDATING FIRMWARE Firmware is the built-in operating software which determines how the Xone:3D functions. Occasionally new firmware may be made available to add new functionality improve performance. Check Xone website www.xone.co.uk for the latest firmware download. WARNING Do not update your firmware unless absolutely necessary. - Page 41 Check that the utility shows that the 3D is connected. Your 3D will now be running with the updated firmware. The new firm- ware version is displayed at the bottom of the configuration utility’s screen. Allen & Heath XONE:3D User Guide...
-
Page 42: User Options
Allen and Heath approved service centre to undertake crossfader replacement. Overlay Sheets There are two versions of template depending upon the serial number of the Xone:3D console. These versions have slightly different control layout. For Serial numbers starting X3D: replacement templates kit: 003-536 •...
