I I n n s s t t a a l l l l a a t t i i o o n n
Caution: It is advisable to remove all possible static discharge potential from
any objects that the ExpressCard may come in contact with before installation.
This can be accomplished by touching a grounded metal object, prior to
insertion.
1. With the notebook PC powered on and fully booted, insert the PCMCIA Card into an
available CardBus slot on the host computer.
2. Connect the 15-pin connector of the cable to your PC card, then connect the DB9
connector to your serial device.
3. The Add New Hardware Wizard will launch and will guide you through the driver
installation process.
D D r r i i v v e e r r I I n n s s t t a a l l l l a a t t i i o o n n
Windows 98, ME, 2000, XP, 2003
The necessary driver files are in ZIP format (e.g. V6515_RS422_485.ZIP) and are
located in E:\IO\OXFORD\RS422_485 (where E: denotes the CD/DVD-ROM drive.
Please copy the file to your local hard drive (presumably C:) and unzip it before
proceeding with installation.
1. When the Found New Hardware Wizard appears, click Next to continue.
2. Select Install from a list or specific location (advanced) and
click Next.
3. Select Include this location in the search and click Browse to
specify the driver's location.
4. Click Next to continue, then click on Finish to complete installation.
Windows NT
Because Windows NT does not support plug and play, you will need to locate the
Install_Serial.exe file (in the E:\IO\OXFORD\WinNT4 folder, where E designates the
location of the CD/DVD-ROM drive), and double click on the executable file. Follow the
prompts to complete installation.
Instruction Manual
4
