Instruction Manual
1.8in Micro SATA to Compact Flash Solid State Drive Adapter
CF2USAT18E
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Packaging Contents
• CF2USAT18E enclosure
• Mini Screwdrivers
• Installation Guide
System Requirement
• 3.3V Compact Flash card
Installation
Hardware Installation
1. Remove the 4 small screws on the underside of the enclosure, and
remove the cover plate.
2. Remove the circuit board and insert the Compact Flash card into
the CF card slot.
3. Reinstall the circuit board into the enclosure.
4. Place the metal cover back on and replace the 4 screws.
Driver Installation
No drivers should need to be installed for this enclosure, as the
enclosure appears as a standard SATA hard drive.
For the most up-to-date information, please visit: www.startech.com
Specifications
Bus Interface
Connectors
Power Consumption
CF Compatibility
*actual product may vary from photos
SATA rev 2.x
Micro SATA connector (7+9 pin)
5V / 150mA
3.3V CF type I and II (SLC/MLC)*
Manual Revision: 02/10/2012
Advertisement
Table of Contents
Related Manuals for StarTech.com CF2USAT18E
Summary of Contents for StarTech.com CF2USAT18E
- Page 1 Installation Specifications Hardware Installation Bus Interface SATA rev 2.x 1. Remove the 4 small screws on the underside of the enclosure, and Connectors Micro SATA connector (7+9 pin) remove the cover plate. Power Consumption 5V / 150mA 2. Remove the circuit board and insert the Compact Flash card into CF Compatibility 3.3V CF type I and II (SLC/MLC)* the CF card slot. 3. Reinstall the circuit board into the enclosure. 4. Place the metal cover back on and replace the 4 screws. Driver Installation No drivers should need to be installed for this enclosure, as the enclosure appears as a standard SATA hard drive. For the most up-to-date information, please visit: www.startech.com Manual Revision: 02/10/2012...
