Chapter 5

Introduction

Logging onto the Web Manager

Web-based User Interface
Web Pages
Introduction
Most software functions of the Switch can be managed, configured, and monitored via the embedded Web-based (HTML)
interface. Manage the Switch from remote stations anywhere on the network through a standard browser, such as Internet
Explorer (version 5.5 and later), Netscape (version 8.0 and later), Mozilla Firefox (version 2.0 and later), or Safari (version
4.0 and later). The browser acts as a universal access tool and can communicate directly with the Switch using the HTTP
protocol.
Logging onto the Web Manager
To begin managing the Switch, simply run the browser installed on your computer and point it to the IP address you have
defined for the device. The URL in the address bar should read something like: http://123.123.123.123, where the
numbers 123 represent the IP address of the Switch.
NOTE: The factory default IP address, for a normal port, is 10.90.90.90. The factory default IP address, for
the management port, is 192.168.0.1.
The Web User Interface's authentication window can be accessed using the IP address of 10.90.90.90 (normal port), as
seen below.
Leave the User Name field and the Password field blank and click OK. This will open the Web-based user interface. The
Switch management features available in the web-based manager are explained below.
Web-based Switch Configuration
Figure 5–1 Enter Network Password Window
36
