xStack® DGS-3420 Series Layer 2+ Managed Stackable Gigabit Switch Hardware Installation Reference Guide
•
Select Terminal keys for Function, Arrow and Ctrl keys. Make sure to use Terminal keys (not Windows keys) are
selected.
NOTE: When using HyperTerminal with the Microsoft® Windows® 2000 operating system, ensure that
Windows 2000 Service Pack 2 or later is installed. Windows 2000 Service Pack 2 allows the use of arrow
keys in HyperTerminal's VT100 emulation. See www.microsoft.com for information on Windows 2000
service packs.
•
After you have correctly set up the terminal, plug the power cable into the power socket on the back of the DGS-
3420 Series switch. The boot sequence appears in the terminal.
•
After the boot sequence completes, the console login screen displays.
•
If the user has not logged into the command line interface (CLI) program, press the Enter key at the User name
and password prompts. There is no default user name and password for the Switch. The administrator must first
create user names and passwords. If user accounts have been previously set up, log in and continue to configure
the Switch.
•
Enter the commands to complete desired tasks. Many commands require administrator-level access privileges.
Read the next section for more information on setting up user accounts. See the DGS-3420 Series CLI
Reference Guide on the documentation CD for a list of all commands and additional information on using the
CLI.
•
To end a management session, use the logout command or close the emulator program.
If you experience problems while making a connection, make sure the emulation is set to VT-100. The emulation settings
can be configured by:
1. Click File Menu in HyperTerminal
2. Click Properties from the drop-down menu
3. Click the Settings Tab
This is where you will find the Emulation options. If you still do not see anything, try rebooting the Switch by disconnecting
its power supply.
Once connected to the console, the following image appears. This is where the user will enter commands to perform all
the available management functions. The Switch will prompt the user to enter a user name and password. Logging on at
the beginning requires no username or password. Just press the Enter key twice to access the command line interface.
Boot Procedure
-------------------------------------------------------------------------------
Power On Self Test ........................................
MAC Address : 00-01-02-03-04-00
H/W Version : B1
Please Wait, Loading V1.50.010 Runtime Image ..............
UART init .................................................
Starting runtime image
Device Discovery ..........................................
Configuration init ........................................
Figure 4–1 Boot up display in console screen
30
V1.00.003
100 %
100 %
100 %
100 %
100 %
