xStack® DGS-3420 Series Layer 2+ Managed Stackable Gigabit Switch Hardware Installation Reference Guide
DGS-3420-28SC:admin#show switch
Command: show switch
Device Type
MAC Address
IP Address
VLAN Name
Subnet Mask
Default Gateway
Boot PROM Version
Firmware Version
Hardware Version
System Name
System Location
System Uptime
System Contact
Spanning Tree
GVRP
IGMP Snooping
MLD Snooping
RIP
RIPng
VLAN Trunk
Telnet
Web
CTRL+C ESC q Quit SPACE n Next Page ENTER Next Entry a All
The Switch's MAC address can also be found from the Web management program on the System Information window
in the Configuration folder.
The IP address for the Switch must be set before it can be managed with the Web-based manager. The Switch IP
address can be automatically set using BOOTP or DHCP protocols, in which case the actual address assigned to the
Switch must be known.
The IP address may be set using the Command Line Interface (CLI) over the console serial port as follows:
Starting at the command line prompt, enter the commands
config ipif System ipaddress xxx.xxx.xxx.xxx/yyy.yyy.yyy.yyy
Where the x's represent the IP address to be assigned to the IP interface named System and the y's represent the
corresponding subnet mask.
Alternatively, you can enter
address to be assigned to the IP interface named System and the z represents the corresponding number of subnets in
CIDR notation.
The IP interface named System on the Switch can be assigned an IP address and subnet mask, and then be used to
connect a management station to the Switch's Telnet or Web-based management agent.
: DGS-3420-28SC Gigabit Ethernet Switch
: 00-01-02-03-04-00
: 10.90.90.90 (Manual)
: default
: 255.0.0.0
: 0.0.0.0
: Build 1.00.003
: Build 1.50.010
: B1
:
:
: 0 days, 0 hours, 21 minutes, 21 seconds
:
: Disabled
: Disabled
: Disabled
: Disabled
: Disabled
: Disabled
: Disabled
: Enabled (TCP 23)
: Enabled (TCP 80)
Figure 4–4 Show switch command
config ipif System ipaddress xxx.xxx.xxx.xxx/z
. Where the x's represent the IP
