9. Locate the Upper Wires (68) inside the
Handlebar (7).
While a second person holds the Console (9)
near the Handlebar (7), connect the wires on
the Console to the Upper Wires (68). Then,
insert the wires into the Handlebar.
Tip: Avoid pinching the wires. Slide the
Console (9) onto the Handlebar (7).
Attach the Console (9) with four #8 x 3/4"
Screws (94).
10. Make sure that all parts are properly tightened before you use the exercise bike. Note: After assembly
is completed, some extra parts may be left over. Place a mat beneath the exercise bike to protect the floor.
If you purchase the optional heart rate monitor (see page 22), follow the additional step below to install
the receiver included with the heart rate monitor.
11. Remove the screw and the cover from the back
of the Console (9).
Remove the paper from the adhesive pad on
the back of the receiver. Press the receiver onto
the indicated location inside the cover.
Connect the wire on the receiver to the wire in
the Console (9). Then, reattach the cover with
the screw.
Note: Discard any other wires that are included
with the heart rate monitor.
9
9
68
94
Avoid pinching
the wires
11
Screw
9
Cover
Attach
receiver
here
Receiver
10
7
68
Cover
Cover
Wires
9
