Summary of Contents for Zte Unite

  • Page 2: Legal Information

    ZTE Corporation. The guide is published by ZTE Corporation. We reserve the right to make modifi- cations on print errors or update specifications without prior notice.

  • Page 3: Getting Started

    Getting Started The following figure shows the appearance of your ZTE Unite, it is only for your reference. The actual device may be different.         SCREEN  UP BUTTON  DOWN BUTTON  OK BUTTON ...

  • Page 4: Screen Indicators

    Screen Indicators Icon Description Icon Description Battery Status 4G LTE Network 3G Network CDMA 1X Network Data Connected Signal Strength Roaming Signal Roaming Strength No SIM Card In- PIN enabled SIM card or serted Incorrect SIM card inserted Number of current No Network Service Wi-Fi connections Text Message...

  • Page 5: About Your Sim Card

    About Your SIM Card Your ZTE Unite requires a SIM card. Prior to turning on your ZTE Unite please insert the SIM card included in the package into the device. This SIM card will only work with your ZTE Unite. Once the SIM card has been inserted, do not remove! If your SIM card is ever separated from your ZTE Unite or damaged, the device will not function.

  • Page 6: Inserting And Charging The Battery

    Inserting and Charging the Battery 1. Use the thumb catch at the bottom of your ZTE Unite to open the battery cover and align the battery contacts with the terminals in the battery compartment as...
  • Page 7 2. Place the battery cover over the battery compartment and press it downward until it clicks into place. 3. Your ZTE Unite comes with a wall charger. To charge: Plug one end of the wall charger into an electrical outlet and the the other end into the ZTE Unite’s MI-...

  • Page 8: Removing The 4G Lte Sim Card

    NOTE: The charge time varies depending upon the battery level. The device will stop charging if the temperature of the battery exceeds 113 °F/45 °C. Removing the 4G LTE SIM Card 1. Turn the power off. Remove the battery cover and take out the battery. 2.

  • Page 9: Sim Card Limited Warranty

    SIM Card Limited Warranty Subject to the exclusions contained below, United States Cellular Corporation ® (“U.S. Cellular ”) warrants to the original purchaser (“You” or “Your”) of the handset with which the SIM card was provided that the SIM card will be free from defects in material and workmanship for a period of one (1) year from the date You purchased the handset (the “Warranty Period”).
  • Page 10 AFFILIATES OR RETAILERS SHALL BE LIABLE TO YOU FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, ECONOMIC, EXEMPLARY, PUNITIVE OR CONSEQUENTIAL DAMAGES (INCLUDING, WITHOUT LIMITATION, LOSS OF DATA, LOSS OF REVENUE OR PROFITS, DAMAGE TO PROPERTY OR LOSS OF USE). IN NO EVENT SHALL U.S. CELLULAR’S, ITS AFFILIATES’ OR RE- TAILERS’...

  • Page 11: Connecting To The Internet

    ZTE Unite. The following should occur once you power on your ZTE Unite:  Your ZTE Unite is powered on as soon as you slide the Power Switch to On and the display lights up.

  • Page 12: Device Customization And Configuration

    3. Click Connect and enter the default password printed beside the battery com- partment of your ZTE Unite. NOTE: Your password will also be displayed on the ZTE Unite screen each time the ZTE Unite is powered on. Device Customization And Configuration...
  • Page 13 Input the default password which is printed beside the battery compartment of your ZTE Unite, and then click Login to access the Web User Interface. Now, you can customize your ZTE Unite, such as the configuration on Internet connection, net- work selection, WLAN settings, password and security settings, data usage, etc.

  • Page 14: Navigating The Device

    Navigating the Device Slide the Power Switch to the ON position to turn on the ZTE Unite. The screen lights up. After the initialization of the ZTE Unite, the SSID and default password will display on the screen. Press the OK button, the following icons will appear: NOTES: ...

  • Page 15: Wan Info

    WAN settings:  Network Provider: Displays the name of your service provider.  Network type: Displays your network type.  Roam: Displays whether or not your ZTE Unite is roaming.  WAN Connection: Check your connection status. WLAN Info...
  • Page 16 MIN, SIM ID, MEID, SW Version, PRI Version and RSSI.  Data Connection: Connect or disconnect the WAN connection.  Data Roaming: Enable or disable the WAN connection when your ZTE Unite is roaming.  Network Select: Choose the desired network from the following options: 4G LTE/CDMA Mode and CDMA Only Mode.

  • Page 17: Text Message

     Button Lock: Set the lock duration for your device by selecting on of the fol- lowing options: 30Secs/15Secs/Never.  Sound Alert: Mute or unmute the system alert.  Dial *228: Activate your ZTE Unite manually. Text Message Select using the UP and DOWN buttons and press the OK button to check messages.
  • Page 18 QSG891US...
