MF971V
Quick Start Guide
ZTE CORPORATION
NO. 55, Hi-tech Road South, Shenzhen, P.R.China
Postcode: 518057
1

Advertisement

Table of Contents
loading

Related Manuals for Zte MF971V

Summary of Contents for Zte MF971V

  • Page 1 MF971V Quick Start Guide ZTE CORPORATION NO. 55, Hi-tech Road South, Shenzhen, P.R.China Postcode: 518057...

  • Page 2: Getting To Know Your Device

    Getting to Know Your Device Appearance The following figure is for your reference only. 1. Power key  Press and hold for about 1.5 seconds to power on/off your device.  Press and hold for about 8 seconds to restart your device.

  • Page 3: Indicator Lights

    Getting to Know Your Device Indicator lights Indicator Status Description Red solid / The battery is low. Please blinking charge the battery. Green The battery is being Battery blinking charged. Green The battery level is middle solid or high. Light off Your device is powered off and not being charged Blue solid...
  • Page 4 The device is in error status.  The device is not Network registered to the mobile network.  There is no micro-SIM card inserted.  There is no network service available. Green The device is registered to solid the 2G/3G mobile network. Green The device is connected to blinking...

  • Page 5: Connection Scenarios

    Getting to Know Your Device Connection Scenarios The device allows multiple clients to surf on the Internet at the same time. The following figure is for your reference only. A micro-SIM card can be used to access the Internet.

  • Page 6: Installing The Micro-Sim Card

    Installing the micro-SIM Card 1. Open the micro-SIM card slot cover. NOTE: Do not remove the cover rudely, because it is connected with the device. 2. Install a micro-SIM card to the micro-SIM card slot. WARNING! To avoid damage to the device, do not use any other kind of SIM cards, or any non-standard micro-SIM card cut from a SIM card.
  • Page 7 3. Close the micro-SIM card slot cover.

  • Page 8: Connecting To Your Device

    Connecting to Your Device Using Wi-Fi 1. Power on your device. 2. Ensure that your computer or other client devices have enabled Wi-Fi, and search for available wireless networks. NOTE: Refer to your Wi-Fi-enabled client device manual for further details on how to search for wireless networks. If you use a computer, you need to set your computer to obtain an IP address automatically.
  • Page 9 NOTE: If the system does not automatically launch installation, you can double-click the device installation icon in My Computer > PERSONAL MODEM to install the software. 3. Wait until the computer is connected to your device successfully.
  • Page 10 Getting to Know the Wi-Fi SSID and Password You can view the label on the device to get the default Wi-Fi SSID and password.
  • Page 11 Logging in to the Personal 4G Mobile Hotspot Configuration Page 1. Ensure that the connection between your device and the client device is correct. 2. Launch the Internet browser and enter http://192.168.8.1 or http://www.personalinternetmovil.com/ in the address bar. 3. Enter the password to log in to the Personal 4G Mobile Hotspot configuration page.
  • Page 12 Changing Wi-Fi SSID Password 1. Log in to the Personal 4G Mobile Hotspot configuration page. 2. Select Wi-Fi Settings. 3. Change the Network Name (SSID) or the Password in the Main SSID area. 4. Click Apply.

  • Page 13: Accessing The Internet

    Accessing the Internet After a client device is successfully connected to your device, you can access the Internet in Automatic or Manual mode. The default mode is Automatic. Mode Operation Automatic Your device is automatically connected to the Internet, and you can surf on the Internet through the client.

  • Page 14: Configuring Your Pc

    Configuring Your PC The following describes how to configure the Internet Protocol in Windows 7 for your Wi-Fi connection. 1. Right-click Network and select Properties. 2. Select Change adapter settings. 3. Right-click Wireless Network Connection and select Properties. 4. Select Internet Protocol Version 4 (TCP/IPv4), and click Properties.

  • Page 15: Legal Information

    ZTE Corporation. The manual is published by ZTE Corporation. We reserve the right to make modifications on print errors or update specifications without prior notice.

  • Page 16: Troubleshooting

    Troubleshooting Problem Recommended Action  Install the software manually. Please connection run the installation program in the between your path of My Computer > PERSONAL device and a MODEM.  PC through a If the driver of your device is cable abnormal, reinstall the software.
  • Page 17 Troubleshooting Problem Recommended Action  client Ensure that your micro-SIM card is connected to available.  device Change the location and find a place cannot access with good signal.  the Internet. Check the settings of the WAN connection mode. ...

  • Page 18: Getting More Help

    Getting More Help You can get help by: • Sending an email to mobile@zte.com.cn • Visiting www.ztedevices.com...

  • Page 19: Fcc Regulations

    FCC Regulations: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 20 installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ...

  • Page 21: Fcc Rf Exposure Information (Sar)

    FCC RF Exposure Information (SAR) This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the United States. During SAR testing, this device is set to transmit at its highest certified power level in all tested frequency bands, and placed in positions that simulate RF exposure in usage near the body with the separation of 10 mm.
  • Page 22 measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands. The FCC has granted an Equipment Authorization for this model device with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines.
  • Page 23 SAR compliance for body operation is based on a separation distance of 10 mm between the unit and the human body. Carry this device, at least 10 mm away from your body to ensure RF exposure level compliant or lower to the reported level. To support body operation, choose the belt clips or holsters that do not contain metallic components to maintain a separation of 10 mm between this device and your body.
