- Page 2 This will help insure compliance with the Directive(s). For more information about other Rocktron products, please see your local dealer or one of our importers closest to you (listed on the Rocktron website - www.rocktron.com). Precautions Read all instructions contained in this manual.
- Page 3 Precautions Continued..Do not block any ventilation openings (if applicable). Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that produce heat. This product is supplied with and runs on a 9VDC adapter. Only used attachments/accessories specified by the manufacturer.
- Page 4 Introduction Congratulations on your purchase of the Rocktron Cyborg Digital Reverb. The Cyborg Digital Reverb is one of a series of “Digital Destiny” stomp boxes that break new ground in the world of floor effects excellence. Simple to use, while...
- Page 5 Connection 1 - Standard Connection...
- Page 6 Connection 2 - Effects Loop...
- Page 7 Connection 3 - with a Noisy Distortion Pedal...
- Page 9 LEDs will turn off from right to left. DC OnTap Power input. Use the supplied Rocktron DC OnTap 9V adapter to power your Cyborg pedal. Plug into a standard wall outlet and follow all safety precautions. Input Jack - plug your guitar into this jack. See preceeding pages for standard connections.
- Page 10 On/Off Footswitch and LED - this footswitch is used to turn “ON” or “OFF” the Cyborg Reverb. When the LED is lit , the reverb is “ON” Output Jack - Using a standard guitar cable with a 1/4” jack, plug into your amplifier or the next effect pedal in your signal chain.
- Page 11 HUSH is Rocktron's patented single-ended noise reduction system, and is available in all presets. The HUSH system provided in the Cyborg is a fully digital implemen- tation, modeled after the latest analog HUSH design, achieved through Digital Signal Processing (DSP).
-
Page 12: Led Display
LED Display The Cyborg’s LED Display consists of 8 LEDs that are used to visually show the user: 1) The PRESET selected 2) The REVERB TYPEs available to any preset. 3) The LEVEL setting (MIN through MAX) of each of the preset’s parameters for the Decay knob (point 4) and the Level Control knob (point 5). - Page 13 o The Level Control Knob (point 5). Turning the Level Control knob will light LEDs in the display to show you level of the reverb of the preset relative to the unaffected dry signal. To see the current level for this preset, turn the knob only one click.
-
Page 14: Reverb Type
LED Display...continued... Reverb Type The top line in the LED display is the REVERB TYPES that are available for each preset. Preset 1 reverb is called PLATE A. This reverb is a Plate reverb Preset 2 reverb is called PLATE B. This reverb is a Plate reverb. Preset 3 reverb is called ROOM A. - Page 15 MIDI The Cyborg pedal has a MIDI jack that allows you to access an additional 56 user presets. Using the Rocktron MIDI Breakout cable (sold separately) you can access these additional 56 presets (64 total) by using a Rocktron MIDI Controller such as the Rocktron MIDI XChange, MIDI Mate or All Access.
-
Page 16: Midi Connection
MIDI - Connection 1... - Page 17 MIDI - Connection 2...
-
Page 18: Specifications
Specifications Maximum Input +3dBu Input Impedance Current Consumption 1000ma Freq. Response 20Hz-16Khz +-3dBu Dynamic Range 93dBu Power Requirements Rocktron DC OnTap 9V Adapter Dimensions 10.5” x 6” x 2.25”... - Page 19 Notes:...
- Page 20 Email: info@rocktron.com www.rocktron.com The Rocktron, Cyborg, Digital Destiny names and logos, this pedal’s shape, design and graphics and this manual’s layout, descriptions and designs are TM, C and R - GHS Corporation, Battle Creek, MI 49015 - - All Rights Reserved 2006-0001 Rev.
