Wireless Speaker – Rear
1 CHANNEL INDICATORS
Light to indicate the selected channel
2 CHANNEL
The default setting is CH1. In case of poor
reception due to interference from other
electrical devices, you can improve reception
by selecting another channel. Each time you
press the button, the channel changes
sequentially:
CH 1 CH 2 CH 3
Each of the 4 channels is allocated a
frequency as follows:
• CHANNEL 1 - 2.414GHz
• CHANNEL 2 - 2.432GHz
• CHANNEL 3 - 2.450GHz
• CHANNEL 4 - 2.468GHz
Controls and Displays
12 13
SPEAKER
SURROUND
SELECTOR
STEREO
SPEAKER
INTERNAL EXTERNAL
SPEAKER SPEAKER
R L
LS RS
Note:
Poor reception may cause the audio to be
interrupted or stopped. This is not
malfunction. Try changing the location or
orientation of the transmitter and/or the
wireless speaker to improve reception.
3 Antenna
Transmits signals to the wireless speaker
4 POWER
CH 4
Press to switch the unit on or off.
5 TUNED
Lights when the signal from the transmitter is
properly received.
6 WIRELESS MODE
Slide to select either
mode.
STEREO
•
SURROUND
surround left and right channels are heard
through the wireless speakers.
11
or
SURROUND
— Sounds going to the
29
