Asante IntraCore IC3624 Specifications

A Communication Division of UIC Corporation
IntraCore ® IC3624
24-Port FE + 2 Gigabit Combo
High Performace 10/100 + Giga Edge IntraCore Switching
IC3624 is an excellent enterprise or SME network edge aggregator switch. It is a layer 2+ manage
switch with very simple and straightforward installation procedure for any end users. Just plug
in the network connections (10, 100 Mbps) and you'll be up and running within minutes. IC3624
switch automatically negotiates the best speed, duplex (full or half) and wiring (Auto-Uplink™)
for optimal performance. All 24 ports RJ45, 2 ports Giga RJ45 and shared 2 port of ber optics
are all runtime swappable.
IC3624 ts pecfectly in SME, corporate edge network, small business/enterprise, or
workgroup network. Built around a very sophisticated single-chip architecture, the
IC3624 delivers true non-blocking, wire-speed performance on all ports with transport
cabilility to deliver in realtime deliver bulk data from multimedia, le transfer, image and video
information.
The IC3624 gives you exible choices of either copper cable or ber optical cable on
ports G0 and G1 to uplink to core or backbone network. Using SFP MiniGBIC modules
you can connect the network to a ber optical network backbone, or extend the
transmission distance with the use of single-mode or multi-mode Gigabit ber cables.
The L2+ management feature tap into the IC3624's on-board Command Line Interface and
web con guration to enable Professional IT and regular user to maximize the bene ts of
L2+ switch capability. With additional L2+ features on ACL on IP and MAC layer, IC3624 gives
full control for LAN users to access the network and information.
Superior Performance
- 25 Gbps bandwidth non-blocking
- Rate Limiting
- Storm Control
- Link Aggregation (IEEE 802.3ad)
- QoS (IEEE 802.1p/ToS/DSCP)
- Rapid Spanning Tree Protocol (IEEE802.1w)
- Multiple Spanning Tree Protocol(IEEE802.1s)
- IGMP Snooping and IGMP Proxy
- Flow Control (IEEE 802.3x)
- Jumbo fream support(up to 9216 bytes)
Simple
- True Plug and Play
- Auto MDI/MDI-X Detection
- Auto-UpLink Sense
- E ortless Installation
- RJ45 and SFP MiniGBIC cabling
Free telephone technical support for connecting to Mac OS, Linux and Windows
clients and servers.
IntraCore
24-Port FastEthernet + 2 Gigabit Combo
L2+ Management Switch
Smart Management
- Full L2+ Management CLI + Web (SSL/SSH)
- VLAN Tagging (IEEE802.11Q)
- Port mirroring
- Performance Monitor
- VLAN control
- GVRP management
- SNMP management
- 802.1X port based access control
(MD5 Encryption)
- Radius Authentication
- Access list for IP and MAC address based
Filtering
Safe Choise
- Best price performance Enterprise/SME
Network Edge Switch
- Scalable and Manageable
- All runtime swappable
- Secure Long term Investment
- Upgradeable rmware
®
IC3624
