StarTech.com 35BAYUSB3S4 Spec Sheet

USB 3.0 Front Panel 4 Port Hub – 3.5in or 5.25in Bay
StarTech ID: 35BAYUSB3S4
The 35BAYUSB3S4 3.5-inch Front Bay to 4-Port USB 3.0 Panel Hub turns any available 3.5-inch computer case
front bay into a 4-Port USB 3.0 hub.
Using only a single USB connection, this front panel hub adds four easily accessible USB ports to the front of
your computer case through a 3.5-inch bay, or through a 5.25-inch bay using the optional
Adapter (BRACKETFDBK) accessory. Each of the added ports is compliant with the USB 3.0 standard which
supports up to 5 Gbps of bandwidth (10x faster than the USB 2.0 standard) and up to 900mA of power.
Accessorize with the PEXUSB3S11 PCI Express card to provide an internal USB 3.0 port, so as to keep the
external ports free for external devices. Backed by a StarTech.com 2-year warranty and free lifetime technical
support.

Applications

Expand your system's USB 3.0 capabilities with additional ports for connecting high speed external
storage devices
Add easier to access USB ports to the front of a computer system instead of the rear
Make use of an internal USB port and unused 3.5" front bay to increase the system's expandability

Features

Four front accessible USB type-A ports
Fits into any 3.5" computer case front bay
SuperSpeed USB 3.0 compliant, supporting data transfer rates up to 5 Gbps
Backward compatible with USB 2.0 and USB 1.0/1.1 specifications and devices
Provides up to 900mA of power per port
USB Link LED indicator for each port
Front Bay Bracket
