- Page 1 U S B H U B 2 Firewire 4 USB 3.5 Bay Front Panel Hub 35BAYFWUSB Instruction Guide * Actual product may vary from photo The Professionals’ Source For Hard-to-Find Computer Parts...
- Page 2 Table of Contents Introduction ............2 Installation .
-
Page 3: Getting Started
Tired of the hassle and inconvenience of connecting your favorite USB and FireWire device to the back of your PC? Then the StarTech.com 35BAYFWUSB FireWire/USB 3.5” internal bay hub device is the right product for you. It has a unique panel design that allows it to be simply inserted into a front 3.5"... - Page 4 Power Jack 2. Remove the computer case and remove a 3.5” front bay cover. 3. Insert the 35BAYFWUSB panel into the empty slot and secure it into place using the 4 small screws provided. 4. Follow the cable connection instructions listed below.
- Page 5 Cable Connection Caution!!! Please take special care when inserting the cables onto the internal connectors at the back of the panel. It is very important that the instructions below are followed carefully. Incorrect insertion could lead to a device or motherboard short circuit. Cable Color Diagram 1.
-
Page 6: Software Installation
Software Installation 1. After you have turned on the computer, Windows will automatically detect that a Generic USB hub has been added and the Add New Hardware Wizard will appear. Press “Next.” 2. The Add New Hardware Wizard will suggest that it searches for the most suitable driver. -
Page 7: Technical Support
Limitation of Liability In no event shall the liability to StarTech.com Ltd. (or its officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of related to the use of the product exceed the actual price paid for the product. - Page 8 Revised: June 11, 2003...
