Leviton MC 6300 Features

Memory Lighting Control Console
10
9
8
7
6
5
4
3
2
1
0
MC 6300
MEMORY LIGHTING CONSOLE
1
With programming capabilities including softpatch
and cue stacking, the MC 6300 offers power and
Features previously found only on premium
theatrical consoles.
Features such as audio sync, MIDI, programmable
chase effects, pile-on scenes, and blind-mode
operation for live scene modification make the MC
6300 one of the highest performance consoles
available in it's class.
Leviton Mfg. Co., Inc. P. O. Box 2210, Tualatin, OR 97062 Phone: (503) 404-5500 • Fax: (503) 404-5594
MICROPLEX OUT
MIDI CONNECTORS
THRU OUT IN AUDIO POWER
IN IN
NSI CORPORATION
+15
WILSONVILLE, OR GND
VDC
TECH SUPPORT 1-503-682-6228
15.18"
2 3 4 5 6 7 8 9 10
2 3 4 5 6 7 8 9 10
AUDIO
LEVEL
GO CLEAR MODIFY
10
SNAPSHOT
9
8
7
6
5
4
3
PAGE SELECT NEXT PREV
2
1
0
PILE TOGGLE PROG CONFIG AUDIO
2 3 4 5
Copyright © 1995, 2001, 2002, Leviton Mfg. Co., Inc.
DMX512 OUT
PUSH
11 12 13 14 15 16
10
9
8
7
6
5
4
3
2
1
0
11 12 13 14 15 16
CHASE FADE MASTER
RATE STACK RATE LEVEL
10
9
8
7
6
5
4
3
2
1
0
CHASE GO BLIND BLACKOUT
6 7 8

Applications

• Theater
• Houses of Worship
• Elementary and Middle Schools

Dimensional Data

Width
Depth
Height
Shipping Weight
MC 6300
3.75"
Shown with optional
DMX512 Protocol Kit
15.00"
• Rentals
• Clubs/Bars
– in.[cm]/lbs.[kg]
15.20 [38.6]
15.00 [38.1]
3.75 [9.7]
13.00 [5.9]
