3Com Router 3000 Ethernet Family
Installation Guide

1.2.2 System specifications

Table 1-1 System specifications of the 3Com Router 3000 Ethernet
Item
Interface
Processor
SDRAM
Flash
Hardware encryption
Max. power
Input
Power supply
(external)
Output
Dimensions (W x H x D)
Weight
Operating temperature
Relative humidity (non-condensing)

1.2.3 LEDs

You can gather information about the status of the 3Com Router 3000 Ethernet Family and its
interfaces by reading the seven LEDs on its cover, as shown in Table 1-2.
Table 1-2 LEDs on the cover of the 3Com Router 3000 Ethernet
LED
LAN0/LAN1/LAN2/LAN3/WAN
SYS
PWR
1 console port
1 x 10 Mbps Ethernet interface (WAN)
4 x 10/100 Mbps Ethernet interfaces (LAN)
MPC859
64 MB
8 MB
––
10 W
Rated voltage: 100 to 240 V a.c.; 50 to 60 Hz
Max. tolerance: 90 to 264 V a.c.; 50 to 60 Hz
Current: 0.5 to 1 A
Voltage: 12 V d.c.
Current: 4 A
300 x 180 x 45 mm (11.81 x 7.09 x 1.77 in.)
(the maximum measurements, including the bulge)
1kg (2.20 lb)
0 to 40 C (32 to 104 F)
10 to 90%
OFF means no link is present.
ON means a link is present.
Blinking means data is being sent or/and received on the AUX port.
Blinking means the system is operating normally.
Steady ON or OFF means the system is improperly operating.
OFF means no power is being supplied.
ON means power is being supplied.
1-3
1. Product Overview
3036
Description
