3Com Router 3000 Ethernet Family
Installation Guide

1.2 Hardware Features of the 3Com Router 3000 Ethernet Family

1.2.1 Appearance

1) Ethernet LED LAN3
3) Ethernet LED LAN1
5) WAN LED
7) POWER LED (PWR)
Figure 1-1 Front view of the 3Com Router 3000 Ethernet
1) Power switch
3) Console port (CONSOLE)
5) Ethernet interface 1(LAN1)
7) Ethernet interface 3 (LAN3)
9) WAN interface
Figure 1-2 Rear view of the 3Com Router 3000 Ethernet
2) Ethernet LED LAN2
4) Ethernet LED LAN0
6) SYSTEM LED (SYS)
2) Power socket
4) Ethernet interface 0 (LAN0)
6) Ethernet interface 2 (LAN2)
8) Grounding screw
1-2
1. Product Overview
