- Page 1 Premier SerieS FOR MODEL: B701 HY B RID B IK E U S ER ’ S G U I DE B701_Rev.1.4.indd 1 7/29/08 9:21:14 AM...
-
Page 2: Table Of Contents
B701_Rev.1.4.indd 2-3 INT RODU CTI ON CONGRATULATIONS and THANK YOU for your purchase of this Premier Series hybrid bike! Whether your goal is to win races or simply enjoy a fuller, healthier lifestyle, a Premier Series hybrid bike can help you attain it – adding club-quality performance to your at-home workouts, with the ergonomics and innovative features you need to get stronger and healthier, faster. -
Page 3: Important Precautions
IMPO R TA N T PRECAUT I ON S SAVE THESE INSTRUCTIONS Read all instructions before using this bike. When using an electrical product, basic precautions should always be followed, including the following: Read all instructions before using this bike. It is the responsibility of the owner to ensure that all users of this bike are adequately informed of all warnings and precautions. -
Page 4: Assembly Step
UPPER HANDLEBAR SEAT BACK HANDLEBAR SET SEAT MECHANISM SEAT ADJUSTMENT LEVER SEAT BASE MAIN FRAME REAR STABILIZER TUBE MAIN FRAME TOOLS INCLUDED PARTS INCLUDED Phillips Screwdriver 1 Console 5mm T Wrench 1 Console Mast 6mm T Wrench 1 Main Frame 1 Front Stabilizer Tube 13/15mm Flat Wrench 1 Rear Stabilizer Tube... - Page 5 ASS E MB LY ST EP 2 ASSEMBLY STEP 2: LEFT PEDAL LEFT CRANK ARM MAIN FRAME NOTe: There is no hardware bag for this step. NOTe: The PeDALS will have stickers specifying which is left and right. Match LeFT PeDAL with left FOOT STrAP. With “L”...
- Page 6 AS SE MB LY ST EP ASSEMBLY STEP : ARC WASHERS (F) BOLTS (E) SEAT MECHANISM BOLT (E) ARC WASHER (F) 45 mm 15 mm Qty: 8 Qty: 8 HARDWARE BAG CONTENTS: BOLT (E) 45 mm Qty: 8 Open HArDWAre BAG 3.
-
Page 7: Before You Begin
ASS E MB LY ST EP ASSEMBLY STEP : CONSOLE WIRES WIRES BOLT (J) 12 mm Qty: 4 HARDWARE BAG CONTENTS: BOLT (J) 12 mm Qty: 4 Open HArDWAre BAG 5. Attach the CONSOLe WireS to the WireS running through the CONSOLe mAST as shown in illustration. Discard rOUTiNG Wire when finished. -
Page 8: Bike Operation
(one that keeps a slight bend in your knee while your legs are in the extended position). Lock the mechanism by releasing the spring loaded lever. B701_Rev.1.4.indd 14-15 B701 CONSOLE DISPLAY MOVING Your bike has a pair of transport wheels built into the FRONT STABILIZER TUBE. - Page 9 C O N S OL E O PE RAT I O N WO RKO U T P RO F I L E S MANUAL Allows you to adjust the resistance level to your preference, without a preset program. WEIGHT LOSS Promotes weight loss by raising and lowering the resistance level, while keeping you in your fat burning zone.
-
Page 10: Heart Rate
W O R KOU T IN FO R MAT I ON USING iPod® AUDIO PLAYER The Horizon Fitness iPod Docking Station is the entertainment solution for your workouts. Various models of iPod with a dock connector can fit with the use of the included inserts. -
Page 11: Conditioning Guidelines
CO ND I T I O NI NG GUI DE L I NE S ALWAYS CONSULT YOUR PHYSICIAN BEFORE BEGINNING AN ExERCISE PROGRAM. HOW OFTEN? (Frequency of Workouts) The American Heart Association recommends that you exercise at least 3 to 4 days per week to maintain cardiovascular fitness. - Page 12 STRETCHING T I P S STRETCH FIRST Before using your product, it is best to take a few minutes to do a few gentle stretching exercises. Stretching prior to exercise will improve flexibility and reduce chances of exercise related injury. Ease into each of these stretches with a slow gentle motion.
-
Page 13: Common Product Questions
T R O UB L E S H OOT ING Your Horizon Fitness hybrid bike is designed to be reliable. However, if you do experience problems with your bike, please reference the troubleshooting guide listed below. PROBLEM: The console does not turn on. -
Page 14: Maintenance
• Any attempt to repair this equipment creates a risk of injury. Horizon Fitness is not responsible or liable for any damage, loss or liability arising from any personal injury incurred during the course of, or as a result of any repair or attempted repair of your fitness equipment by other than an authorized service technician. -
Page 15: B701_Rev.1.4.Indd
NOTE: Please read the TROUBLESHOOTING section before contacting Customer Tech Support. To receive additional product information, visit us at www.horizonfitness.com B701 Rev. 1.4 | © 2008 Horizon Fitness Products | Designed & Engineered in the U.S.A. | Made in China B701_Rev.1.4.indd 28...
